将实时Android音频流传输到服务器（将实时android音频流传输到服务器上）
我目前正在尝试将直播麦克风音频从Android设备流式传输到Java程序。我首先在两个Android设备之间发送实时音频，以确认我的方法正确。在接收设备上几乎没有任何延迟地可以完美地听到音频。接下来，我将相同的音频流发送到一个小型Java程序，并验证了数据也已正确发送到此处。现在，我想要做的是对这些数据进行编码，并以某种方式在运行Java程序的服务器上对其进行回放。我宁愿在使用HTML5或JavaScript的网络浏览器中播放它，但可以使用VLC等替代方法。
这是发送实时麦克风音频的Android应用的代码
public class MainActivity extends Activity {private Button startButton,stopButton;public byte[] buffer;public static DatagramSocket socket; AudioRecord recorder;private int sampleRate = 44100; private int channelConfig = AudioFormat.CHANNEL_CONFIGURATION_MONO; private int audioFormat = AudioFormat.ENCODING_PCM_16BIT; int minBufSize = AudioRecord.getMinBufferSize(sampleRate, channelConfig, audioFormat); private boolean status = true;@Overrideprotected void onCreate(Bundle savedInstanceState) { super.onCreate(savedInstanceState); setContentView(R.layout.activity_main); startButton = (Button) findViewById (R.id.start_button); stopButton = (Button) findViewById (R.id.stop_button); startButton.setOnClickListener(startListener); stopButton.setOnClickListener(stopListener); minBufSize += 2048;}@Overridepublic boolean onCreateOptionsMenu(Menu menu) { getMenuInflater().inflate(R.menu.main, menu); return true;}private final OnClickListener stopListener = new OnClickListener() { @Override public void onClick(View arg0) { status = false; recorder.release(); Log.d("VS","Recorder released"); }};private final OnClickListener startListener = new OnClickListener() { @Override public void onClick(View arg0) { status = true; startStreaming(); }};public void startStreaming(){ Thread streamThread = new Thread(new Runnable(){ @Override public void run() { try{ DatagramSocket socket = new DatagramSocket(); Log.d("VS", "Socket Created"); byte[] buffer = new byte[minBufSize]; Log.d("VS","Buffer created of size " + minBufSize); Log.d("VS", "Address retrieved"); recorder = new AudioRecord(MediaRecorder.AudioSource.MIC,sampleRate,channelConfig,audioFormat,minBufSize); Log.d("VS", "Recorder initialized"); recorder.startRecording(); InetAddress IPAddress = InetAddress.getByName("192.168.1.5"); byte[] sendData = new byte[1024]; byte[] receiveData = new byte[1024]; while (status == true) { DatagramPacket sendPacket = new DatagramPacket(sendData, sendData.length, IPAddress, 50005); socket.send(sendPacket); } } catch(UnknownHostException e) { Log.e("VS", "UnknownHostException"); } catch (IOException e) { Log.e("VS", "IOException"); e.printStackTrace(); } } }); streamThread.start();}}这是Java程序读取数据的代码。
class Server{ public static void main(String args[]) throws Exception { DatagramSocket serverSocket = new DatagramSocket(50005); byte[] receiveData = new byte[1024]; byte[] sendData = new byte[1024]; while(true) { DatagramPacket receivePacket = new DatagramPacket(receiveData, receiveData.length); serverSocket.receive(receivePacket); String sentence = new String( receivePacket.getData().toString()); System.out.println("RECEIVED: " + sentence); } }}我知道在将音频发送到Java程序之前，应该先在应用程序端对音频进行编码，但是我不确定在使用AudioRecorder时如何进行编码。我宁愿不使用NDK，因为我没有使用它的经验，也没有时间去学习如何使用它。
答案1
小编典典所以我解决了我的问题。问题主要在接收方。接收器接收音频流，并将其推送到PC的扬声器。产生的声音仍然很漫长和破碎，但是仍然有效。尝试使用缓冲区大小可以改善这一点。
编辑：您可以使用线程读取音频，以免产生延迟。另外，最好使用16 000的采样大小，因为这样可以进行语音处理。
Android代码：
package com.example.mictest2;import java.io.IOException;import java.net.DatagramPacket;import java.net.DatagramSocket;import java.net.InetAddress;import java.net.UnknownHostException;import android.app.Activity;import android.media.AudioFormat;import android.media.AudioRecord;import android.media.MediaRecorder;import android.os.Bundle;import android.util.Log;import android.view.View;import android.view.View.OnClickListener;import android.widget.Button;public class Send extends Activity {private Button startButton,stopButton;public byte[] buffer;public static DatagramSocket socket;private int port=50005;AudioRecord recorder;private int sampleRate = 16000 ; // 44100 for musicprivate int channelConfig = AudioFormat.CHANNEL_CONFIGURATION_MONO; private int audioFormat = AudioFormat.ENCODING_PCM_16BIT; int minBufSize = AudioRecord.getMinBufferSize(sampleRate, channelConfig, audioFormat);private boolean status = true;@Overridepublic void onCreate(Bundle savedInstanceState) { super.onCreate(savedInstanceState); setContentView(R.layout.activity_main); startButton = (Button) findViewById (R.id.start_button); stopButton = (Button) findViewById (R.id.stop_button); startButton.setOnClickListener (startListener); stopButton.setOnClickListener (stopListener);}private final OnClickListener stopListener = new OnClickListener() { @Override public void onClick(View arg0) { status = false; recorder.release(); Log.d("VS","Recorder released"); }};private final OnClickListener startListener = new OnClickListener() { @Override public void onClick(View arg0) { status = true; startStreaming(); }};public void startStreaming() { Thread streamThread = new Thread(new Runnable() { @Override public void run() { try { DatagramSocket socket = new DatagramSocket(); Log.d("VS", "Socket Created"); byte[] buffer = new byte[minBufSize]; Log.d("VS","Buffer created of size " + minBufSize); DatagramPacket packet; final InetAddress destination = InetAddress.getByName("192.168.1.5"); Log.d("VS", "Address retrieved"); recorder = new AudioRecord(MediaRecorder.AudioSource.MIC,sampleRate,channelConfig,audioFormat,minBufSize*10); Log.d("VS", "Recorder initialized"); recorder.startRecording(); while(status == true) { //reading data from MIC into buffer minBufSize = recorder.read(buffer, 0, buffer.length); //putting buffer in the packet packet = new DatagramPacket (buffer,buffer.length,destination,port); socket.send(packet); System.out.println("MinBufferSize: " +minBufSize); } } catch(UnknownHostException e) { Log.e("VS", "UnknownHostException"); } catch (IOException e) { e.printStackTrace(); Log.e("VS", "IOException"); } } }); streamThread.start(); } }Android XML：
<RelativeLayout xmlns:android="http://schemas.android.com/apk/res/android"xmlns:tools="http://schemas.android.com/tools"android:layout_width="match_parent"android:layout_height="match_parent"android:paddingBottom="@dimen/activity_vertical_margin"android:paddingLeft="@dimen/activity_horizontal_margin"android:paddingRight="@dimen/activity_horizontal_margin"android:paddingTop="@dimen/activity_vertical_margin"tools:context=".MainActivity" ><TextView android:id="@+id/textView1" android:layout_width="wrap_content" android:layout_height="wrap_content" android:text="@string/hello_world" /><Button android:id="@+id/start_button" android:layout_width="wrap_content" android:layout_height="wrap_content" android:layout_below="@+id/textView1" android:layout_centerHorizontal="true" android:layout_marginTop="130dp" android:text="Start" /><Button android:id="@+id/stop_button" android:layout_width="wrap_content" android:layout_height="wrap_content" android:layout_alignLeft="@+id/button1" android:layout_below="@+id/button1" android:layout_marginTop="64dp" android:text="Stop" /></RelativeLayout>服务器代码：
package com.datagram;import java.io.ByteArrayInputStream;import java.net.DatagramPacket;import java.net.DatagramSocket;import javax.sound.sampled.AudioFormat;import javax.sound.sampled.AudioInputStream;import javax.sound.sampled.AudioSystem;import javax.sound.sampled.DataLine;import javax.sound.sampled.FloatControl;import javax.sound.sampled.SourceDataLine;class Server {AudioInputStream audioInputStream;static AudioInputStream ais;static AudioFormat format;static boolean status = true;static int port = 50005;static int sampleRate = 44100;public static void main(String args[]) throws Exception { DatagramSocket serverSocket = new DatagramSocket(50005); byte[] receiveData = new byte[1280]; // ( 1280 for 16 000Hz and 3584 for 44 100Hz (use AudioRecord.getMinBufferSize(sampleRate, channelConfig, audioFormat) to get the correct size) format = new AudioFormat(sampleRate, 16, 1, true, false); while (status == true) { DatagramPacket receivePacket = new DatagramPacket(receiveData, receiveData.length); serverSocket.receive(receivePacket); ByteArrayInputStream baiss = new ByteArrayInputStream( receivePacket.getData()); ais = new AudioInputStream(baiss, format, receivePacket.getLength()); // A thread solve the problem of chunky audio new Thread(new Runnable() { @Override public void run() { toSpeaker(receivePacket.getData()); } }).start(); }}public static void toSpeaker(byte soundbytes[]) { try { DataLine.Info dataLineInfo = new DataLine.Info(SourceDataLine.class, format); SourceDataLine sourceDataLine = (SourceDataLine) AudioSystem.getLine(dataLineInfo); sourceDataLine.open(format); FloatControl volumeControl = (FloatControl) sourceDataLine.getControl(FloatControl.Type.MASTER_GAIN); volumeControl.setValue(100.0f); sourceDataLine.start(); sourceDataLine.open(format); sourceDataLine.start(); System.out.println("format? :" + sourceDataLine.getFormat()); sourceDataLine.write(soundbytes, 0, soundbytes.length); System.out.println(soundbytes.toString()); sourceDataLine.drain(); sourceDataLine.close(); } catch (Exception e) { System.out.println("Not working in speakers..."); e.printStackTrace(); }}}我希望这可以帮助某人节省几个小时的痛苦:)
android – 如何获取音频流的持续时间,并从任何点继续音频流
描述：
我有一个音频播放器的以下代码.我可以通过点击进度栏(0到to-mediaplayer.getDuration())之间的任何时间段继续音频播放.它对于音频播放工作正常.
音频流中的问题：
>当我从互联网服务器(比如s3-bucket)流式传输音频文件时
它开始流正确.
>但是mediaPlayer.getDuration()和mediaPlayer.getCurrentPosition()
返回错误的值.在流媒体开始
mediaPlayer.getCurrentPosition()返回5小时.
>由于这个原因,我无法继续音频流
流(0到流持续时间)的指定持续时间.
问题：
>如何获取音频流的持续时间
>如何从指定的持续时间继续音频流.对于
例如,为10分钟的文件,我想从6开始流式传输
分钟.
码：
public class MyAudioPlayer extends Activity
implements OnClickListener{
MediaPlayer mediaPlayer = null;
private boolean isPaused=false;
private boolean isstop = true;
String filePath = null;
String productName = null;
ImageButton btnPlay = null;
ImageButton btnPause = null;
ImageButton btnReset = null;
ImageButton btnStop = null;
AudioManager audioManager = null;
SeekBar volControl = null;
SeekBar progressControl = null;
TextView progresstext = null;
long durationInMillis = -1;
@Override
public void onCreate(Bundle savedInstanceState) {
super.onCreate(savedInstanceState);
setContentView(R.layout.ltd_audio_player);
volControl = (SeekBar)findViewById(R.id.player_volume);
progressControl = (SeekBar)findViewById(R.id.player_seekbar);
progresstext = (TextView) findViewById(R.id.player_progress_text);
btnPlay = (ImageButton) findViewById(R.id.ic_player_play);
btnPause = (ImageButton) findViewById(R.id.ic_player_pause);
btnReset = (ImageButton) findViewById(R.id.ic_player_reset);
btnStop = (ImageButton) findViewById(R.id.ic_player_stop);
btnPlay.setonClickListener(this);
btnPause.setonClickListener(this);
btnReset.setonClickListener(this);
btnStop.setonClickListener(this);
filePath = getIntent().getExtras().getString("localPath");
this.setPlayer();
this.resetAndStartPlayer();
}
@Override
protected void onResume() {
super.onResume();
isPaused=false;
progresstext.postDelayed(onEverySecond,1000);
}
@Override
protected void onPause() {
super.onPause();
isPaused=true;
}
private void setProgressControl() {
int maxVolume = mediaPlayer.getDuration();
int curVolume = mediaPlayer.getCurrentPosition();
progressControl.setMax(maxVolume);
progressControl.setProgress(curVolume);
progressControl.setonSeekBarchangelistener(new SeekBar.OnSeekBarchangelistener() {
@Override
public void onProgressChanged(SeekBar seekbar,int progress,boolean fromUser) {
mediaPlayer.seekTo(progress);
}
@Override
public void onStartTrackingTouch(SeekBar seekBar) {
// Todo Auto-generated method stub
}
@Override
public void onStopTrackingTouch(SeekBar seekBar) {
// Todo Auto-generated method stub
}
});
}
@Override
public void onClick(View v) {
switch(v.getId()){
case R.id.ic_player_play:
if(isstop==true){
try {
mediaPlayer.prepareAsync();
} catch (Exception e) {
e.printstacktrace();
}
}else{
mediaPlayer.start();
isstop = true;
}
break;
case R.id.ic_player_pause:
mediaPlayer.pause();
break;
case R.id.ic_player_reset:
mediaPlayer.seekTo(0);
break;
case R.id.ic_player_stop:
isstop = true;
progressControl.setProgress(0);
mediaPlayer.stop();
break;
}
}
private void resetAndStartPlayer(){
try {
if(filePath!=null){
mediaPlayer.setDataSource(filePath);
mediaPlayer.prepareAsync();
}
} catch (Exception e) {
e.printstacktrace();
}
}
private void setPlayer(){
getwindow().setFormat(PixelFormat.UNKNowN);
mediaPlayer = new MediaPlayer();
mediaPlayer.setonBufferingUpdateListener(new OnBufferingUpdateListener() {
@Override
public void onBufferingUpdate(MediaPlayer mp,int percent) {
progressControl.setSecondaryProgress((progressControl.getMax()/100)*percent);
}
});
mediaPlayer.setonPreparedListener(new OnPreparedListener() {
@Override
public void onPrepared(MediaPlayer mp) {
mediaPlayer.start();
isstop=false;
durationInMillis = mediaPlayer.getDuration();
MyAudioPlayer.this.setProgressControl();
}
});
mediaPlayer.setAudioStreamType(AudioManager.STREAM_MUSIC);
}
@Override
protected void onDestroy() {
// Todo Auto-generated method stub
mediaPlayer.release();
super.onDestroy();
}
protected void setProgresstext() {
durationInMillis = mediaPlayer.getDuration();
int curVolume = mediaPlayer.getCurrentPosition();
long HOUR = 60*60*1000;
if(progresstext!=null){
if(durationInMillis>HOUR){
progresstext.setText(String.format("%1$tH:%1$tM:%1$tS",new Date(curVolume))
+" / "+String.format("%1$tH:%1$tM:%1$tS",new Date(durationInMillis)));
}else{
progresstext.setText(String.format("%1$tM:%1$tS",new Date(curVolume))
+" / "+String.format("%1$tM:%1$tS",new Date(durationInMillis)));
}
}
}
private Runnable onEverySecond=new Runnable() {
public void run() {
if (mediaPlayer!=null) {
progressControl.setProgress(mediaPlayer.getCurrentPosition());
MyAudioPlayer.this.setProgresstext();
}
if (!isPaused) {
progresstext.postDelayed(onEverySecond,1000);
}
}
};
}
时间显示在进度条上方.
时间：’当前持续时间’/’总持续时间’
解决方法
希望它可以解决你的问题.
1)音频流的持续时间和进度
我已经查看了你的代码,你的代码中有一个重大错误来计算时间.您创建新的Date(durationInMillis).日期增加您的地点,即GMT XX小时,这就是为什么您在开始流式传播时间达到5个小时.您应该使用以下方法来计算currentProgress / duration.
protected void setProgresstext() {
final int HOUR = 60*60*1000;
final int MINUTE = 60*1000;
final int SECOND = 1000;
int durationInMillis = mediaPlayer.getDuration();
int curVolume = mediaPlayer.getCurrentPosition();
int durationHour = durationInMillis/HOUR;
int durationMint = (durationInMillis%HOUR)/MINUTE;
int durationSec = (durationInMillis%MINUTE)/SECOND;
int currentHour = curVolume/HOUR;
int currentMint = (curVolume%HOUR)/MINUTE;
int currentSec = (curVolume%MINUTE)/SECOND;
if(durationHour>0){
System.out.println(" 1 = "+String.format("%02d:%02d:%02d/%02d:%02d:%02d",currentHour,currentMint,currentSec,durationHour,durationMint,durationSec));
}else{
System.out.println(" 1 = "+String.format("%02d:%02d/%02d:%02d",durationSec));
}
}
2)擦洗流.
MediaPlayer允许擦除音频流.我已经在我的一个项目中实施了它,但需要一些时间.从另一个位置恢复音频流需要一些时间.
android – 通过MediaRouter将音频流式传输到设备
我想通过MediaRouter类将音频文件从我的
Android设备流式传输到另一个.据我所知,我需要的
mediarouter.addCallback(MediaRouter.ROUTE_TYPE_LIVE_AUdio,mCallback);
用于监听连接的设备是否正在播放音频.但是我不确定.
我的问题是我如何获得音频流？
解决方法
如果您使用AudioTrack播放音频,则需要确保streamType与路径的streamType匹配.要获取路径的streamType,只需执行以下操作：
private final MediaRouter.Callback mMediaRouterCallback =
new MediaRouter.Callback() {
@Override
public void onRouteSelected(MediaRouter router,MediaRouter.RouteInfo route) {
Log.i(TAG,"streamType = " + route.getPlaybackStream());
}
};
通常它将是AudioManager.STREAM_MUSIC.因此,当您初始化AudioTrack时,请确保：
_audioTrack = new AudioTrack(
AudioManager.STREAM_MUSIC,sampleRate,channelConfig,audioFormat,bufferSize,mode);
android-以最小的延迟播放实时音频流
我们正在开发某种对讲系统.我们需要使用RTSP或HTTP协议在Android应用程序中播放实时音频流,并且延迟最小.使用MediaPlayer.setDataSource(URL)的标准方法会产生太大的延迟(大约2-3秒)；我们正在使用android 2.2.据我了解,媒体播放器中缓冲区的大小只能在固件级别上设置.您能给我一些建议如何实现这一点,还是应该深入了解真正的VoIP？
解决方法:
我找到了灵活的解决方案-使用AudioTrack API.关于Android中可用的音频API的另一篇有趣的文章：http://www.wiseandroid.com/post/2010/07/13/Intro-to-the-three-Android-Audio-APIs.aspx
android-如何使用翻新之类的文件流式传输到服务器？
我可以使用Retrofit的MultiPart注释将文件顺利上传到服务器.
但是,我想要的是将仍在写入磁盘的文件流式传输到服务器.可以使用翻新吗？
解决方法:
多部分请求的改进使用okhttp3.RequestBody.因此,您必须创建自己的RequestBody来生成数据.
这是取自OkHttp食谱(https://github.com/square/okhttp/wiki/Recipes#post-streaming)的示例
public static final MediaType MEDIA_TYPE_MARKDOWN
= MediaType.parse("text/x-markdown; charset=utf-8");
RequestBody requestBody = new RequestBody() {
@Override public MediaType contentType() {
return MEDIA_TYPE_MARKDOWN;
}
@Override public void writeto(BufferedSink sink) throws IOException {
sink.writeUtf8("Numbers\n");
sink.writeUtf8("-------\n");
for (int i = 2; i <= 997; i++) {
sink.writeUtf8(String.format(" * %s = %s\n", i, factor(i)));
}
}
private String factor(int n) {
for (int i = 2; i < n; i++) {
int x = n / i;
if (x * i == n) return factor(x) + " × " + i;
}
return Integer.toString(n);
}
};
