• 参考官网：https://docs.docker.com/compose/install/

[HttpGet("{name}")]
    public ActionResult<string> Get(string name)
    {
        var connection = _httpContextAccessor.HttpContext.Connection;
        var ipv4 = connection.LocalIpAddress.MapToIPv4().ToString();
        var cacheKey = $"test:{name}";
        _distributedCache.SetString(cacheKey, $"{ipv4}  {name}");
        var message = _distributedCache.GetString(cacheKey);

        return message;
    }

• 查看 `version` 地址：https://docs.docker.com/compose/compose-file/compose-versioning/ 里面有 docker 与 compose 对应关系

• `docker-compose` 配置可以参考：https://docs.docker.com/compose/compose-file/

• 3 个 webapi 服务（由于 webapi 服务所依赖的镜像都是一样的，所以后面 2 个我直接使用第一个服务创建出来的镜像，`docker-compose` 创建出来的镜像名称格式 `project_service`）

• 1 个 redis 服务，直接使用 redis 镜像

•  1 个 nginx 服务，直接使用 nginx 镜像（反向代理 3 个 webapi 服务，实现负载均衡）

• 在上一步 `docker-compose.yml` 文件中我们看到，需要将 `./conf/nginx.conf` 文件映射到容器的 nginx 默认配置文件，方便后续维护 nginx 配置，不然每次修改配置文件都需要进入 docker 容器再修改比较麻烦。

•  上面的结果每次刷新都会循环显示

public void ConfigureServices(IServiceCollection services)
        {
            services.Configure<CookiePolicyOptions>(options =>
            {
                // This lambda determines whether user consent for non-essential cookies is needed for a given request.
                options.CheckConsentNeeded = context => false; //这里要改为false，默认是true，true的时候session无效
                options.MinimumSameSitePolicy = Microsoft.AspNetCore.Http.SameSiteMode.None;
            });

            services.AddDataProtection(configure =>
            {
                configure.ApplicationDiscriminator = "commonweb1";
            })
            .SetApplicationName("commonweb1")
            .AddKeyManagementOptions(options =>
            {
                //配置自定义XmlRepository
                options.XmlRepository = new SessionShare();
            });

            //services.AddSession();
            #region 使用Redis保存Session
            // 这里取连接字符串
            services.AddDistributedRedisCache(option =>
            {
                //redis 连接字符串
                option.Configuration = "";
                //redis 实例名
                option.InstanceName = "Test_Session";
            });

            //添加session 设置过期时长分钟
            //var sessionOutTime = con.ConnectionConfig.ConnectionRedis.SessionTimeOut;
            services.AddSession(options =>
            {
                options.IdleTimeout = TimeSpan.FromSeconds(Convert.ToDouble(3 * 60 * 60)); //session活期时间
                options.Cookie.HttpOnly = true;//设为httponly
            });
            #endregion

            services.AddMvc().SetCompatibilityVersion(CompatibilityVersion.Version_2_2);
        }


        public void Configure(IApplicationBuilder app, IHostingEnvironment env)
        {
            if (env.IsDevelopment())
            {
                app.UseDeveloperExceptionPage();
            }
            app.UseSession();
            app.UseMiddleware<RequestMiddleware>();
            app.UseCookiePolicy();
            app.UseMvc();
        }

public class RequestMiddleware
    {
        private readonly RequestDelegate _next;

        public RequestMiddleware(RequestDelegate next)
        {
            this._next = next;
        }

        public Task Invoke(HttpContext context)
        {
            context.Request.EnableRewind(); //支持context.Request.Body重复读取，内部调用了EnableBuffering方法，否则在使用部分方法或属性时会报错误System.NotSupportedException: Specified method is not supported，例如context.Request.Body.Position
            if (context.Request.ContentLength == null)
            {
                return this._next(context);
            }

            string sessionPhone = context.Session.GetString("phone");
            if (string.IsNullOrEmpty(sessionPhone))
            {
                context.Session.SetString("phone", DateTime.Now.ToString("yyyy-MM-dd HH:mm:ss"));
            }
            return this._next(context);
        }
    }

[HttpPost]
        public string PostTest(dynamic @param)
        {
            string phone = HttpContext.Session.GetString("phone");
            return JsonConvert.SerializeObject(@param) + phone;
        }

[HttpPost]
        public string PostTestNew(dynamic @param)
        {
            string phone = HttpContext.Session.GetString("phone");
            return JsonConvert.SerializeObject(@param) + phone;
        }

前言

上一章介绍了Docker通过多条命令创建启动运行Docker容器,由此可见这样一个个去创建单独的容器也是相当麻烦的,比如要在某个复杂项目中用DB、缓存、消息等等,这样我们还要去一个个再创建,为此这时候需要用上我们三剑客中的一员大将自动挡的(DockerCompose).Compose是一个用于定义和应用多个容器的工具（镜像、启动命令、端口映射等），一条命令便可配置我们引用中的所有服务.

Base


指定镜像名称或者镜像Id，如果该镜像不存在，会尝试pull下来。

build

指定Dockerfile文件的路径

build: ./dir

也可以是一个对象。

build: context: ./dir dockerfile: Dockerfile-alternate args: buildno: 1

command

覆盖容器启动后默认执行的命令。

command: bundle exec thin -p 3000

该命令也可以是列表，类似于 dockerfile：

command: ["bundle","exec","thin","-p","3000"]

links

链接到其他服务器中的容器，可以指定服务名称和链接的别名使用SERVICE:ALIAS的形式，或者只指定服务名称

links:
   - db
   - db:database
   - redis

external_links

表示链接到docker-compose.yml外部的容器，甚至并非Compose管理的容器，特别是对于那些提供共享容器或共同服务。格式跟links类似

external_links:
  - redis_1
  - project_db_1:MysqL
  - project_db_1:postgresql

ports

暴露端口信息。使用宿主端口:容器端口的格式，或者仅仅指定容器的端口（此时宿主机将会随机指定端口），类似于docker run -p

ports:
 - "3000"
 - "3000-3005"
 - "8000:8000"
 - "9090-9091:8080-8081"
 - "49100:22"
 - "127.0.0.1:8001:8001"
 - "127.0.0.1:5000-5010:5000-5010"

expose

暴露端口，只将端口暴露给连接的服务，而不暴露给宿主机

expose:
 - "3000"
 - "8000"

volumes

卷挂载路径设置。可以设置宿主机路径 （HOST:CONTAINER） 或加上访问模式 （HOST:CONTAINER:ro）

volumes:
  # Just specify a path and let the Engine create a volume
  - /var/lib/MysqL

  # Specify an absolute path mapping
  - /opt/data:/var/lib/MysqL

  # Path on the host,relative to the Compose file
  - ./cache:/tmp/cache

  # User-relative path
  - ~/configs:/etc/configs/:ro

  # Named volume
  - datavolume:/var/lib/MysqL

volumes_from

从另一个服务或者容器挂载卷。可以指定只读或者可读写，如果访问模式没有指定，则默认是可读写。

volumes_from:
 - service_name
 - service_name:ro
 - container:container_name
 - container:container_name:rw

environment

设置环境变量。可以使用数组或者字典两种方式。只有一个key的环境变量可以在运行Compose的机器上找到对应的值，这有助于加密的或者特殊主机的值。

environment:
  RACK_ENV: development
  SHOW: 'true'
  SESSION_SECRET:

environment:
  - RACK_ENV=development
  - SHOW=true
  - SESSION_SECRET

env_file

从文件中获取环境变量，可以为单独的文件路径或列表。如果通过 docker-compose -f FILE 指定了模板文件，则 env_file 中路径会基于模板文件路径。如果有变量名称与 environment 指令冲突，则以envirment 为准。

env_file: .env

env_file:
  - ./common.env
  - ./apps/web.env
  - /opt/secrets.env

extends

继承另一个服务，基于已有的服务进行扩展。

net

设置网络模式。

net: "bridge"
net: "host"
net: "none"
net: "container:[service name or container name/id]"

dns

配置DNS服务器。可以是一个值，也可以是一个列表。

dns: 8.8.8.8
dns:
  - 8.8.8.8
  - 9.9.9.9

dns_search

配置DNS的搜索域，可以是一个值，可以是一个列表。

dns_search: example.com
dns_search:
  - dc1.example.com
  - dc2.example.com

Dockerfile

FROM mcr.microsoft.com/dotnet/core/aspnet:2.2-stretch-slim AS base
workdir /app
EXPOSE 80

FROM mcr.microsoft.com/dotnet/core/sdk:2.2-stretch AS build
workdir /src
copY DockerComposeDemo/DockerComposeDemo.csproj DockerComposeDemo/
RUN dotnet restore "DockerComposeDemo/DockerComposeDemo.csproj"
copY . .
workdir "/src/DockerComposeDemo"
RUN dotnet build "DockerComposeDemo.csproj" -c Release -o /app

FROM build AS publish
RUN dotnet publish "DockerComposeDemo.csproj" -c Release -o /app

FROM base AS final
workdir /app
copY --from=publish /app .
ENTRYPOINT ["dotnet","DockerComposeDemo.dll"]

编辑 docker-compose.yml

version: '3.4'

services:
  dockercomposedemoo:
    image: ${DOCKER_REGISTRY-}dockercomposedemo
    build:
      context: .
      dockerfile: DockerComposeDemo/Dockerfile

  redis:
   container_name: redis
   image: redis
   ports:
      # 端口映射
      - 6379:6379

  Nginx:
   container_name: Nginx
   image: Nginx
   ports:
      # 端口映射
      - 8081:80
   volumes:
      - /Users/fenghui/projects/Nginx/Nginx.conf:/etc/Nginx/Nginx.conf

加入了redis和Nginx镜像，直接用Nginx进行部署该项目。
上面也体现了端口的映射以及文件的映射，演示的示例是Nginx.conf文件映射（切记一定要共享文件夹）

Nginx.conf

user  Nginx;
worker_processes  1;

error_log  /var/log/Nginx/error.log warn;
pid        /var/run/Nginx.pid;


events {
    worker_connections  1024;
}


http {
    include       /etc/Nginx/mime.types;
    default_type  application/octet-stream;

    log_format  main  '$remote_addr - $remote_user [$time_local] "$request" '
                      '$status $body_bytes_sent "$http_referer" '
                      '"$http_user_agent" "$http_x_forwarded_for"';

    access_log  /var/log/Nginx/access.log  main;

    sendfile        on;
    #tcp_nopush     on;

    keepalive_timeout  65;

    #gzip  on;

    #include /etc/Nginx/conf.d/*.conf;

        server {
        listen       80;
        server_name  localhost;

        #charset koi8-r;

        #access_log  logs/host.access.log  main;
        #access_log logs/access.log main;
        #error_log logs/error.log;
     location / {

             proxy_pass http://172.17.0.1:8082;

             proxy_http_version 1.1;

             proxy_set_header Upgrade $http_upgrade;

             proxy_set_header Connection keep-alive;

             proxy_set_header Host $http_host;

             proxy_cache_bypass $http_upgrade;
             proxy_set_header X-Real-IP $remote_addr;
             proxy_set_header REMOTE-HOST $remote_addr;
             proxy_set_header X-Forwarded-For $proxy_add_x_forwarded_for;

         }


    }

}

创建一个项目,演示访问次数,存储直接用redis存储

package

using ServiceStack.Redis;

redis test

private readonly RedisManagerPool redismanger = new RedisManagerPool("172.17.0.1:6379");
        public void OnGet()
        {
            using (var db = redismanger.GetClient()) {
                ViewData["num"] = db.IncrementValue("count");
            }
        }

aspx

@ViewData["num"]

Run

构建容器

然后打开浏览器输入8081，8081为Nginx代理的端口，同时可以通过wappalyzer看见我们的web服务器是Nginx。

redis测试成功没问题

使用dockercompose编排工具进行构建容器是不是方便了好多。

概要

参考：https://docs.docker.com/compose/compose-file/

Demo: https://github.com/fhcodegit/DockerCompose

PS C:\Users\Administrator> docker-compose version
docker-compose version 1.23.2, build 1110ad01
docker-py version: 3.6.0
CPython version: 3.6.6
OpenSSL version: OpenSSL 1.0.2o  27 Mar 2018

root@VM-16-9-ubuntu:~# apt install docker-compose

version: ''3.4''

services:
  helloworld:
    image: helloworld:v2.0
    build: #镜像构建
      context: . #工作目录
      dockerfile: HelloWorld/Dockerfile #Dockerfile位置
    environment: #环境变量
      - ASPNETCORE_ENVIRONMENT=Development
    ports: #端口映射
      - "81:80"
    container_name: netcore_helloworld #容器名
    deploy:
      restart_policy: #重启策略
        condition: on-failure
        delay: 5s
        max_attempts: 3
    networks: #指定network
      - default
      - newbridge

  mynginx:
    image: mynginx:v2.0
    build:
      context: MyNginx
      dockerfile: Dockerfile
    ports:
      - "80:80"
      - "801:801"
    container_name: mynginx
    deploy:
      restart_policy:
        condition: on-failure
        delay: 5s
        max_attempts: 3
    networks:
      - default

networks:
  default: #定义一个docker中已存在的network
    external:
      name: mybridge
  newbridge: #新的network
    #name: newbridge  #compose版本3.5开始才支持自定义名称

PS C:\Users\Administrator> cd C:\Users\Administrator\source\repos\AspNetCore_Docker
PS C:\Users\Administrator\source\repos\AspNetCore_Docker> docker-compose up -d
WARNING: Some services (helloworld, mynginx) use the ''deploy'' key, which will be ignored. Compose does not support ''deploy'' configuration - use `docker stack deploy` to deploy to a swarm.
Creating network "aspnetcore_docker_newbridge" with the default driver
Creating netcore_helloworld ... done
Creating mynginx            ... done

PS C:\Users\Administrator\source\repos\AspNetCore_Docker> docker images
REPOSITORY                             TAG                 IMAGE ID            CREATED             SIZE
mynginx                                v2.0                9c18561d7ab3        27 minutes ago      109MB
helloworld                             v2.0                c42e9f575fc4        24 hours ago        265MB
nginx                                  latest              62c261073ecf        9 days ago          109MB
mcr.microsoft.com/dotnet/core/sdk      2.2-stretch         e4747ec2aaff        3 weeks ago         1.74GB
mcr.microsoft.com/dotnet/core/aspnet   2.2-stretch-slim    f6d51449c477        3 weeks ago         260MB
docker4w/nsenter-dockerd               latest              2f1c802f322f        8 months ago        187kB
PS C:\Users\Administrator\source\repos\AspNetCore_Docker> docker ps -a
CONTAINER ID        IMAGE               COMMAND                  CREATED             STATUS              PORTS                                      NAMES
66ff08eda2ae        helloworld:v2.0     "dotnet HelloWorld.d…"   11 minutes ago      Up 11 minutes       0.0.0.0:81->80/tcp                         netcore_helloworld
5357b641a7b1        mynginx:v2.0        "nginx -g ''daemon of…"   11 minutes ago      Up 11 minutes       0.0.0.0:80->80/tcp, 0.0.0.0:801->801/tcp   mynginx

PS C:\Users\Administrator\source\repos\AspNetCore_Docker> docker-compose down
WARNING: Some services (helloworld, mynginx) use the ''deploy'' key, which will be ignored. Compose does not support ''deploy'' configuration - use `docker stack deploy` to deploy to a swarm.
Stopping mynginx            ... done
Stopping netcore_helloworld ... done
Removing mynginx            ... done
Removing netcore_helloworld ... done
Network mybridge is external, skipping   #外部的bridge不会被删除，直接跳过
Removing network aspnetcore_docker_newbridge

PS C:\Users\Administrator> docker login --username=你的用户名 ccr.ccs.tencentyun.com
Password:
Login Succeeded

PS C:\Users\Administrator> docker tag c42e9f575fc4 ccr.ccs.tencentyun.com/wuuu/helloworld
PS C:\Users\Administrator> docker tag 9c18561d7ab3 ccr.ccs.tencentyun.com/wuuu/mynginx
PS C:\Users\Administrator> docker images
REPOSITORY                               TAG                 IMAGE ID            CREATED             SIZE
ccr.ccs.tencentyun.com/wuuu/mynginx      latest              9c18561d7ab3        2 days ago          109MB
mynginx                                  v2.0                9c18561d7ab3        2 days ago          109MB
ccr.ccs.tencentyun.com/wuuu/helloworld   latest              c42e9f575fc4        3 days ago          265MB
helloworld                               v2.0                c42e9f575fc4        3 days ago          265MB
nginx                                    latest              62c261073ecf        12 days ago         109MB
mcr.microsoft.com/dotnet/core/sdk        2.2-stretch         e4747ec2aaff        3 weeks ago         1.74GB
mcr.microsoft.com/dotnet/core/aspnet     2.2-stretch-slim    f6d51449c477        3 weeks ago         260MB
docker4w/nsenter-dockerd                 latest              2f1c802f322f        8 months ago        187kB
PS C:\Users\Administrator>

PS C:\Users\Administrator> docker push ccr.ccs.tencentyun.com/wuuu/helloworld
The push refers to repository [ccr.ccs.tencentyun.com/wuuu/helloworld]
...
latest: digest: sha256:d991fe759257905f727593cc09d8299462e20e31ada3a92023a48fbc130f7484 size: 1581
PS C:\Users\Administrator> docker push ccr.ccs.tencentyun.com/wuuu/mynginx
The push refers to repository [ccr.ccs.tencentyun.com/wuuu/mynginx]
...
latest: digest: sha256:0eda000278411f5b6e034944993f6f5b94825125124f67cc7caf4e684aad5a85 size: 1155
PS C:\Users\Administrator>

version: ''3.4''

services:
  helloworld:
    image: ccr.ccs.tencentyun.com/wuuu/helloworld
    environment: #环境变量
      - ASPNETCORE_ENVIRONMENT=Development
    ports: #端口映射
      - "81:80"
    container_name: netcore_helloworld #容器名
    deploy:
      restart_policy: #重启策略
        condition: on-failure
        delay: 5s
        max_attempts: 3
    networks: #指定network
      - default
      - newbridge

  mynginx:
    image: ccr.ccs.tencentyun.com/wuuu/mynginx
    ports:
      - "80:80"
      - "801:801"
    container_name: mynginx
    deploy:
      restart_policy:
        condition: on-failure
        delay: 5s
        max_attempts: 3
    networks:
      - default

networks:
  default: #定义一个docker中已存在的network
    external:
      name: mybridge
  newbridge: #新的network
    #name: newbridge  #compose版本3.5开始才支持自定义名称
