android httpClient (https/http) 的优化构建方式二

由于时间原因，这里只构建所有请求 https 都能通过的请求 client

首先定义（重写）信任管理器

    public class SSLTrustManager implements javax.net.ssl.TrustManager,
            javax.net.ssl.X509TrustManager ,HostnameVerifier{
        public java.security.cert.X509Certificate[] getAcceptedIssuers() {
            return null;
        }

        public boolean isServerTrusted(
                java.security.cert.X509Certificate[] certs) {
            return true;
        }

        public boolean isClientTrusted(
                java.security.cert.X509Certificate[] certs) {
            return true;
        }

        public void checkServerTrusted(
                java.security.cert.X509Certificate[] certs, String authType)
                throws java.security.cert.CertificateException {
            return;
        }

        public void checkClientTrusted(
                java.security.cert.X509Certificate[] certs, String authType)
                throws java.security.cert.CertificateException {
            return;
        }

        	@Override
		public boolean verify(String urlHostName, SSLSession session) { //允许所有主机
			return true;
		}
    }

然后封装

 public static HttpURLConnection connect(String strUrl) throws Exception {

    	 javax.net.ssl.TrustManager[] trustAllCerts = new javax.net.ssl.TrustManager[1];
         javax.net.ssl.TrustManager tm = new SSLTrustManager();
         trustAllCerts[0] = tm;
         javax.net.ssl.SSLContext sc = javax.net.ssl.SSLContext
                 .getInstance("SSL");
         sc.init(null, trustAllCerts, null);
         javax.net.ssl.HttpsURLConnection.setDefaultSSLSocketFactory(sc
                 .getSocketFactory());

         HttpsURLConnection.setDefaultHostnameVerifier((HostnameVerifier) tm);

        URL url = new URL(strUrl);
        HttpURLConnection urlConn = (HttpURLConnection) url.openConnection();

        return urlConn;
    }

测试一下

public void unitest()
{
     HttpURLConnection urlConn = connect(''https://github.com/'');
        urlConn.setDoInput(true);
        urlConn.setRequestMethod("GET");
        urlConn.connect();
        InputStream is = urlConn.getInputStream();
        StringBuffer sb = new StringBuffer();
        if(is!=null)
        {
        	BufferedReader br = new BufferedReader(new InputStreamReader(is));
        	String s = null;
        	while ((s=br.readLine())!=null)
        	{
				sb.append(s).append("\n");
			}
        }
        System.out.println("Content:\n"+sb.toString());
}

try do it!

android httpClient(https/http)的优化构建方式一

参考:基于java的https双向认证,android上亦可用

Android Https相关完全解析 当OkHttp遇到Https

在android中，经常不可避免的的使用https和http访问网络数据，因此需要先构建一个网络访问client

其中https的访问需要使用SSLSocket，但对于一般安全性要求不是很高的通信，一般设置SSLSocket是允许所有主机通过，下面给出2中，一种是允许所有主机通过的https通信，另一种是加密传输，需要使用cert证书。

允许所有主机通过

public class GlobalUtils
{

     public static HttpClient getAndroidHttpClient(int connTimeout, String userAgent,int retryTimes)
     {
              AbstractHttpClient httpClient = null;
	      //设置请求控制参数
	      HttpParams params = new BasicHttpParams();
	      ConnManagerParams.setTimeout(params, connTimeout);
	      HttpConnectionParams.setSoTimeout(params, connTimeout);
	      HttpConnectionParams.setConnectionTimeout(params, connTimeout);

	        if (TextUtils.isEmpty(userAgent)) {
	            userAgent = System.getProperty("http.agents", "Mozilla/5.0 (Windows NT 6.1; WOW64) AppleWebKit/537.36 (KHTML, like Gecko) Chrome/37.0.2062.124 Safari/537.36");
	        }
	        HttpProtocolParams.setUserAgent(params, userAgent);
               //设置最大的连接数
	        ConnManagerParams.setMaxConnectionsPerRoute(params, new ConnPerRouteBean(10));
	        ConnManagerParams.setMaxTotalConnections(params, 10);

	        HttpConnectionParams.setTcpNoDelay(params, true); //关闭Socket缓冲

	        HttpConnectionParams.setSocketBufferSize(params, 1024 * 8);//本方法与setTcpNoDelay冲突

	        HttpProtocolParams.setVersion(params, HttpVersion.HTTP_1_1);

	        SchemeRegistry schemeRegistry = new SchemeRegistry();
	        schemeRegistry.register(new Scheme("http", PlainSocketFactory.getSocketFactory(), 80));
	        schemeRegistry.register(new Scheme("https", DefaultSSLSocketFactory.getSocketFactory(), 443));

	        httpClient = new DefaultHttpClient(new ThreadSafeClientConnManager(params, schemeRegistry), params);
	        httpClient.setHttpRequestRetryHandler(new RetryHandler(retryTimes));

	        httpClient.addRequestInterceptor(new HttpRequestInterceptor() {
	            @Override
	            public void process(org.apache.http.HttpRequest httpRequest, HttpContext httpContext) throws org.apache.http.HttpException, IOException {
	                if (!httpRequest.containsHeader("Accept-Encoding")) {
	                    httpRequest.addHeader("Accept-Encoding", "gzip");
	                }
	            }
	        });

	        httpClient.addResponseInterceptor(new HttpResponseInterceptor() {
	            @Override
	            public void process(HttpResponse response, HttpContext httpContext) throws org.apache.http.HttpException, IOException {
	                final HttpEntity entity = response.getEntity();
	                if (entity == null) {
	                    return;
	                }
	                final Header encoding = entity.getContentEncoding();
	                if (encoding != null) {
	                    for (HeaderElement element : encoding.getElements()) {
	                        if (element.getName().equalsIgnoreCase("gzip")) {
	                            response.setEntity(new GZipDecompressingEntity(response.getEntity()));
	                            return;
	                        }
	                    }
	                }
	            }
	        });
			return httpClient;
	    }

}

上面的重试RetryHandler是请求失败后重试的规则

public class RetryHandler implements HttpRequestRetryHandler {  //需要实现HttpRequestRetryHandler

    private static final int RETRY_SLEEP_INTERVAL = 500;

    private static HashSet<Class<?>> exceptionWhiteList = new HashSet<Class<?>>();

    private static HashSet<Class<?>> exceptionBlackList = new HashSet<Class<?>>();

    static {
        exceptionWhiteList.add(NoHttpResponseException.class);
        exceptionWhiteList.add(UnknownHostException.class);
        exceptionWhiteList.add(SocketException.class);

        exceptionBlackList.add(InterruptedIOException.class);
        exceptionBlackList.add(SSLHandshakeException.class);
    }

    private final int maxRetries;

    public RetryHandler(int maxRetries) {
        this.maxRetries = maxRetries;
    }

    @Override
    public boolean retryRequest(IOException exception, int retriedTimes, HttpContext context) {
        boolean retry = true;

        if (exception == null || context == null) {
            return false;
        }

        Object isReqSent = context.getAttribute(ExecutionContext.HTTP_REQ_SENT);
        boolean sent = isReqSent == null ? false : (Boolean) isReqSent;

        if (retriedTimes > maxRetries) {
            retry = false;
        } else if (exceptionBlackList.contains(exception.getClass())) {
            retry = false;
        } else if (exceptionWhiteList.contains(exception.getClass())) {
            retry = true;
        } else if (!sent) {
            retry = true;
        }

        if (retry) {
            try {
                Object currRequest = context.getAttribute(ExecutionContext.HTTP_REQUEST);
                if (currRequest != null) {
                //这里只允许GET请求的重试，因为在一般访问中POST重试会造成重复提交问题，因此不宜使用
                    if (currRequest instanceof HttpRequestBase) {
                        HttpRequestBase requestBase = (HttpRequestBase) currRequest;
                        retry = "GET".equals(requestBase.getMethod());
                    } else if (currRequest instanceof RequestWrapper) {
                        RequestWrapper requestWrapper = (RequestWrapper) currRequest;
                        retry = "GET".equals(requestWrapper.getMethod());
                    }
                } else {
                    retry = false;
                    LogUtils.e("retry error, curr request is null");
                }
            } catch (Throwable e) {
                retry = false;
                LogUtils.e("retry error", e);
            }
        }

        if (retry) {
            SystemClock.sleep(RETRY_SLEEP_INTERVAL); // sleep a while and retry http request again.
        }

        return retry;
    }

}

需要重写SSLSocketFactory来支持所有主机通过

public class DefaultSSLSocketFactory extends SSLSocketFactory {
    //ssl上下文环境
    private SSLContext sslContext = SSLContext.getInstance("TLS");
    //证书保存对象
    private static KeyStore trustStore;

    static {
        try {
            trustStore = KeyStore.getInstance(KeyStore.getDefaultType());
            //通常这里需要加载证书
            trustStore.load(null, null);
        } catch (Throwable e) {
           e.printStackTrace();
        }
    }

    private static DefaultSSLSocketFactory instance;

    public static DefaultSSLSocketFactory getSocketFactory() {
        if (instance == null) {
            try {
                instance = new DefaultSSLSocketFactory();
            } catch (Throwable e) {
                LogUtils.e(e.getMessage(), e);
            }
        }
        return instance;
    }

    private DefaultSSLSocketFactory()
            throws UnrecoverableKeyException,
            NoSuchAlgorithmException,
            KeyStoreException,
            KeyManagementException {
        super(trustStore);

        TrustManager trustAllCerts = new X509TrustManager() {
            public java.security.cert.X509Certificate[] getAcceptedIssuers() {
                return null;
            }

            @Override
            public void checkClientTrusted(
                    java.security.cert.X509Certificate[] chain, String authType)
                    throws java.security.cert.CertificateException {
            }

            @Override
            public void checkServerTrusted(
                    java.security.cert.X509Certificate[] chain, String authType)
                    throws java.security.cert.CertificateException {
            }
        };
        //初始化509凭证信任管理器
        sslContext.init(null, new TrustManager[]{trustAllCerts}, null);
        //设置所有请求都会得到客户端的信任
        this.setHostnameVerifier(SSLSocketFactory.ALLOW_ALL_HOSTNAME_VERIFIER);
    }

    @Override
    public Socket createSocket(Socket socket, String host, int port, boolean autoClose) throws IOException {
        //连接SSL Socket
        return sslContext.getSocketFactory().createSocket(socket, host, port, autoClose);
    }

    @Override
    public Socket createSocket() throws IOException {
        return sslContext.getSocketFactory().createSocket();
    }
}

当然上面的通信谈不上SSL加密，因此使用了https和没使用https请求没啥区别，就像http一样。

对于https安全请求的的加密过程，我们需要充分的认识，简单的说他是一个加密的过程。

对于这个过程的请求才叫安全请求，那么这个请求是怎么构建的呢

一般来说证书放在assets或者raw资源文件下(以下代码来自互联网，用户可以再第一段代码中稍作修改，便可使用)

public void getHttpsKeyStore(){
    AssetManager am = context.getAssets();
    InputStream ins = am.open("robusoft.cer");
    try {
            //读取证书
            CertificateFactory cerFactory = CertificateFactory.getInstance("X.509");  //问1
            Certificate cer = cerFactory.generateCertificate(ins);
            //创建一个证书库，并将证书导入证书库
            KeyStore keyStore = KeyStore.getInstance("PKCS12", "BC");   //问2
            keyStore.load(null, null);
            keyStore.setCertificateEntry("trust", cer);
            return keyStore;
    } finally {
            ins.close();
    }

}

将这里代码整合到第一段代码中，形成https安全请求，当然也可以单独使用，

public static HttpClient getAndroidHttpClient(int connTimeout, String userAgent,int retryTimes)
{
//......
   AssetManager am = context.getAssets();
    InputStream ins = am.open("robusoft.cer");
    try {
            //读取证书
            CertificateFactory cerFactory = CertificateFactory.getInstance("X.509");  //问1
            Certificate cer = cerFactory.generateCertificate(ins);
            //创建一个证书库，并将证书导入证书库
            KeyStore keyStore = KeyStore.getInstance("PKCS12", "BC");   //问2
            keyStore.load(null, null);
            keyStore.setCertificateEntry("trust", cer);
             //把咱的证书库作为信任证书库
            SSLSocketFactory socketFactory = new SSLSocketFactory(keystore);
            schemeRegistry.register(new Scheme("https", socketFactory , 443));
    } finally {
            ins.close();
    }
  //  ......

  }

Android HttpClient,DefaultHttpClient,HttpPost

package my.package;
import my.package.exceptions.CustomException;

import java.io.BufferedReader;
import java.io.InputStream;
import java.io.InputStreamReader;
import java.net.URLDecoder;

import org.apache.http.httpentity;
import org.apache.http.HttpResponse;
import org.apache.http.client.HttpClient;
import org.apache.http.client.methods.HttpGet;
import org.apache.http.client.methods.HttpPost;
import org.apache.http.entity.StringEntity;
import org.apache.http.impl.client.DefaultHttpClient;


 public class ConnectionUtil {

 public static String postData(String url,String postData)
        throws CustomException {

    // Create a new HttpClient and Post Header
    InputStream is = null;
    StringBuilder sb = null;
    String result = "";
    HttpClient httpclient = new DefaultHttpClient();

HttpPost httppost = new HttpPost();
    httppost.setHeader("host",url);

    Log.v("ConnectionUtil","opening POST connection to URI = " + httppost.getURI() + " url = " + URLDecoder.decode(url));

    try {
        httppost.setEntity(new StringEntity(postData));

        // Execute HTTP Post Request
        HttpResponse response = httpclient.execute(httppost);
        httpentity entity = response.getEntity();
        is = entity.getContent();

    } catch (Exception e) {
        Log.e("log_tag","Error in http connection " + e.toString());
        e.printstacktrace();
        throw new CustomException("Could not establish network connection");
    }
    try {
        BufferedReader reader = new BufferedReader(new InputStreamReader(
                is,"utf-8"),8);
        sb = new StringBuilder();
        sb.append(reader.readLine() + "\n");
        String line = "0";

        while ((line = reader.readLine()) != null) {
            sb.append(line + "\n");
        }

        is.close();
        result = sb.toString();

    } catch (Exception e) {
        Log.e("log_tag","Error converting result " + e.toString());
        throw new CustomException("Error parsing the response");
    }
    Log.v("ConnectionUtil","Sent: "+postData);
    Log.v("ConnectionUtil","Got result "+result);
    return result;

}

}

// Build the JSON object to pass parameters
    JSONObject jsonObj = new JSONObject();
    jsonObj.put("username",username);
    jsonObj.put("data",dataValue);

    // Create the POST object and add the parameters
    HttpPost httpPost = new HttpPost(url);
    StringEntity entity = new StringEntity(jsonObj.toString(),HTTP.UTF_8);
    entity.setContentType("application/json");
    httpPost.setEntity(entity);

    HttpClient client = new DefaultHttpClient();
    HttpResponse response = client.execute(httpPost);

Android无法访问org.apache.http.client.HttpClient

import org.apache.http.client.methods.CloseableHttpResponse;
import org.apache.http.client.methods.HttpGetHC4;
import org.apache.http.impl.client.CloseableHttpClient;
import org.apache.http.impl.client.HttpClientBuilder;

public class HTTPHelper
{
    private String base;

    public HTTPHelper (String base)
    {
        this.base = base;
    }

    public String doGet (String path)
    {
        try
        {
            CloseableHttpClient client = HttpClientBuilder.create().build();
            HttpGetHC4 get = new HttpGetHC4(path);
            CloseableHttpResponse response = client.execute(get);

            return "";
        }
        catch (Exception e)
        {
            return null;
        }
    }
}

client.execute(get);

apply plugin: 'com.android.application'

android {
    compileSdkVersion 23
    buildToolsversion "23.0.0"

    defaultConfig {
        applicationId "principal.halloween"
        minSdkVersion 16
        targetSdkVersion 23
        versionCode 1
        versionName "1.0"
    }
    buildTypes {
        release {
            minifyEnabled false
            proguardFiles getDefaultProguardFile('proguard-android.txt'),'proguard-rules.pro'
        }
    }
}

dependencies {
    compile filetree(dir: 'libs',include: ['*.jar'])
    compile 'com.android.support:appcompat-v7:23.0.0'
    compile 'com.pubnub:pubnub-android:3.7.5'
    compile 'com.google.code.gson:gson:2.3.1'
    compile group: 'org.apache.httpcomponents',name: 'httpclient-android',version: '4.3.5.1'
    compile 'org.apache.httpcomponents:httpclient:4.3.6'

}

android {
    useLibrary 'org.apache.http.legacy'
}

URL url = new URL(urlString);
HttpURLConnection connection = (HttpURLConnection)url.openConnection();
connection.setRequestMethod("GET");
connection.setDoInput(true);
connection.connect();

我们今天的关于无法使用 HTTPClient Arduino 库中的 http.begin() 打开我的 IP和无法使用com.mysql.jdbc.driver的分享已经告一段落，感谢您的关注，如果您想了解更多关于android httpClient (https/http) 的优化构建方式二、android httpClient(https/http)的优化构建方式一、Android HttpClient,DefaultHttpClient,HttpPost、Android无法访问org.apache.http.client.HttpClient的相关信息，请在本站查询。
