本文目录一览：- binary,varbinary,image的区别（binary和varbinary）
- .net – SQL Server Varbinary(max)：从varbinary字段中选择一个字节子集
- c# – 如何将图像存储到varbinary(max)列？
- C#二进制读写BinaryReader、BinaryWriter、BinaryFormatter
- edu.wpi.first.wpilibj.image.BinaryImage的实例源码
binary,varbinary,image的区别（binary和varbinary）
binary
固定长度的二进制数据，其最大长度为 8,000 个字节。
varbinary
可变长度的二进制数据，其最大长度为 8,000 个字节。
可变长度的二进制数据，其最大长度为 2^31 - 1 (2,147,483,647) 个字节
在 Microsoft sql Server 的未来版本中将删除 ntext、text 和 image 数据类型。请避免在新开发工作中使用这些数据类型，
并考虑修改当前使用这些数据类型的应用程序。请改用 nvarchar(max)、varchar(max) 和 varbinary(max)。
ntext 长度可变的 Unicode 数据，最大长度为 2^30 - 1 (1,073,741,823) 个字符。存储大小是所输入字符个数的两倍(以字节为单位)。ntext 的 sql 2003 同义词为 national text。text 服务器代码页中长度可变的非 Unicode 数据，最大长度为 2^31-1 (2,647) 个字符。当服务器代码页使用双字节字符时，存储仍是 2,647 字节。根据字符串，存储大小可能小于 2,647 字节。image 长度可变的二进制数据，从 0 到 2^31-1 (2,647) 个字节。--------------------- 作者：fox123871 来源：CSDN 原文：https://blog.csdn.net/fox123871/article/details/7667154 版权声明：本文为博主原创文章，转载请附上博文链接！
.net – SQL Server Varbinary(max)：从varbinary字段中选择一个字节子集
在sql Server 2008中,从varbinary(MAX)字段(不使用FileStreams)读取部分二进制数据的最有效方式是什么？
当向数据库中写入数据时,T-sql中有可用的VarBinary.Write()函数,允许字节递增地写入字段,但是似乎没有类似的功能可用于读取数据.
我知道.Net中的DataReader.GetBytes()方法,它将只选择您要求的字节,但是会带来性能开销吗？即,sqlserver中的select将会读取数据库中的所有字节,然后给出getBytes()方法所有这些字节,以便从它们请求的字节的子集？
感谢任何帮助.
解决方法
您使用
SUBSTRING.这从服务器上的varbinary数据中读取一段代码段,并且只将代码段返回给客户端.
c# – 如何将图像存储到varbinary(max)列？
我在将一个
Image插入sql server 2008时遇到了这个以下的sql异常.
Implicit conversion from data type nvarchar to varbinary(max) is not
allowed. Use the CONVERT function to run this query
在数据库中,Image列的数据类型是Varbinary(MAX).
编辑
代码解除了评论
paramaters.Add(getParam("@imageFilePath",DbType.AnsiString,imageFilePath));
解决方法
使用它将文件读入字节数组：
// Old fashioned way
public static byte[] ReadFile(string filePath)
{
byte[] buffer;
FileStream fileStream = new FileStream(filePath,FileMode.Open,FileAccess.Read);
try
{
int length = (int)fileStream.Length; // get file length
buffer = new byte[length]; // create buffer
int count; // actual number of bytes read
int sum = 0; // total number of bytes read
// read until Read method returns 0 (end of the stream has been reached)
while ((count = fileStream.Read(buffer,sum,length - sum)) > 0)
sum += count; // sum is a buffer offset for next reading
}
finally
{
fileStream.Close();
}
return buffer;
}
要么
// Thanks Magnus!
byte[] data = System.IO.File.ReadAllBytes(filePath);
然后使用此保存图像数据(我使用的图像类“实例”包含我在instance.Data中的图像信息和字节数组)：
using(sqlCommand cm = new sqlCommand("SaveImage",connection,transaction)){
cm.CommandType = CommandType.StoredProcedure;
cm.Parameters.Add(new sqlParameter("@Id",sqlDbType.Int,ParameterDirection.InputOutput,false,10,"Id",DaTarowVersion.Current,(sqlInt32)instance.Id));
cm.Parameters.Add(new sqlParameter("@Title",sqlDbType.NVarChar,50,ParameterDirection.Input,"Title",(sqlString)instance.Title));
if (instance.Data.Length > 0)
{
cm.Parameters.Add(new sqlParameter("@Data",sqlDbType.VarBinary,instance.Data.Length,"Data",(sqlBinary)instance.Data));
}
else
{
cm.Parameters.Add(new sqlParameter("@Data",dbnull.Value));
}
cm.ExecuteNonQuery();
)
这是一个示例存储过程：
CREATE PROCEDURE SaveImage ( @Id int OUTPUT,@Title nvarchar(50),@Data varbinary(MAX) ) AS SET NOCOUNT ON SET XACT_ABORT ON IF @Id IS NULL OR @Id <= 0 BEGIN SELECT @Id = ISNULL(MAX([Id]),0) + 1 FROM [dbo].[Images] END INSERT INTO [dbo].[Images] ( [Id],[Title],[Data] ) VALUES ( @Id,@Title,@Data )
C#二进制读写BinaryReader、BinaryWriter、BinaryFormatter
一、二进制读写类：
1、BinaryReader/BinaryWriter:二进制读写
- BinaryReader：用特定的编码将基元数据类型读作二进制值。
- BinaryWriter：以二进制形式将基元类型写入流，并支持用特定的编码写入字符串。
2、XmlReader/XmlWriter :XML读写
见：C#使⽤XmlReader和XmlWriter操作XML⽂件
二、BinaryReader/BinaryWriter
读写流的基元数据类型。可以操作图像、压缩文件等二进制文件。也可以是MemoryStream等。
不需要一个字节一个字节进行操作，可以是2个、4个、或8个字节这样操作。
可以将一个字符或数字按指定数量的字节进行写入。
1、写入：
using (BinaryWriter writer = new BinaryWriter(File.Open(fileName, FileMode.Create)))
{
writer.Write(1.250F);
writer.Write(@"c:\Temp");
writer.Write(10);
writer.Write(true);
}Response.BinaryWrite()方法输出二进制图像
FileStream fs = new FileStream(Server.MapPath("未命名.jpg"), FileMode.Open);//将图片文件存在文件流中
long fslength = fs.Length;//流长度
byte[] b=new byte[(int)fslength];//定义二进制数组
fs.Read(b, 0, (int)fslength);//将流中字节写入二进制数组中
fs.Close();//关闭流
Response.ContentType = "image/jpg";//没有这个会出现乱码
Response.BinaryWrite(b);//将图片输出在页面2、读取：
每次读取都回提升流中的当前位置相应数量的字节。
下面的代码示例演示了如何存储和检索文件中的应用程序设置。
const string fileName = "AppSettings.dat";
float aspectRatio;
string tempDirectory;
int autoSaveTime;
bool showStatusBar;
if (File.Exists(fileName))
{
using (BinaryReader reader = new BinaryReader(File.Open(fileName, FileMode.Open)))
{
aspectRatio = reader.ReadSingle();
tempDirectory = reader.ReadString();
autoSaveTime = reader.ReadInt32();
showStatusBar = reader.ReadBoolean();
}
Console.WriteLine("Aspect ratio set to: " + aspectRatio);
Console.WriteLine("Temp directory is: " + tempDirectory);
Console.WriteLine("Auto save time set to: " + autoSaveTime);
Console.WriteLine("Show status bar: " + showStatusBar);
}BinaryReader读取图片：
using (FileStream fs = new FileStream("1.jpg", FileMode.Open, FileAccess.Read))
{
//将图片以文件流的形式进行保存
using (BinaryReader br = new BinaryReader(fs))
{
byte[] imgBytesIn = br.ReadBytes((int)fs.Length); //将流读入到字节数组中
br.Close();
}
}三、以二进制格式序列化对象BinaryFormatter
1、SoapFormatter（用于HTTP中）和BinaryFormatter（用于TCP中）类实现了IFormatter接口 (由继承IRemotingFormatter，支持远程过程调用 (Rpc))
- Deserialize(Stream) 反序列化所提供流中的数据并重新组成对象图形。
- Serialize(Stream, Object) 将对象或具有给定根的对象图形序列化为所提供的流。
XML序列化见：https://www.jb51.net/article/250477.htm
2、举例：
[Serializable]
public class Product //实体类
{
public long Id;
[NonSerialized]//标识不序列化此成员Name
public string Name;
public Product(long Id, string Name)
{
this.Id = Id;
this.Name = Name;
}
}
static void Main()
{
//序列化（对象保存到文件）
List<Product> Products = new List<Product> {
new Product(1,"a"),new Product(2,"b")
};
FileStream fs = new FileStream("DataFile.dat", FileMode.Create);
IFormatter formatter = new BinaryFormatter();
formatter.Serialize(fs, Products);
fs.Close();
//反序列化（文件内容转成对象）
FileStream fs1 = new FileStream("DataFile.dat", FileMode.Open);
BinaryFormatter formatter1 = new BinaryFormatter();
List<Product> addresses = (List<Product>)formatter1.Deserialize(fs1);
fs1.Close();
foreach (Product de in addresses)
{
Console.WriteLine("{0} lives at {1}.", de.Id, de.Name);
}
}以上就是本文的全部内容，希望对大家的学习有所帮助，也希望大家多多支持。
您可能感兴趣的文章:
- C# BinaryReader实现读取二进制文件
- C# 进制转换的实现（二进制、十六进制、十进制互转）
- C#中图片、二进制与字符串的相互转换方法
- C#实现文件与二进制互转并存入数据库
- C#读取二进制文件方法分析
- c#二进制逆序方法详解
- C# 图片与二进制转换的简单实例
- C# 向二进制文件进行读写的操作方法
- c# 以二进制读取文本文件
edu.wpi.first.wpilibj.image.BinaryImage的实例源码
项目：2014CataBot
文件：ImagingUtils.java
/**
* Computes a score (0-100) comparing the aspect ratio to the ideal aspect
* ratio for the target. This method uses the equivalent rectangle sides to
* determine aspect ratio as it performs better as the target gets skewed by
* moving to the left or right. The equivalent rectangle is the rectangle
* with sides x and y where particle area= x*y and particle perimeter= 2x+2y
*
* @param image The image containing the particle to score,needed to
* performa additional measurements
* @param report The Particle Analysis Report for the particle,used for the
* width,height,and particle number
* @param outer Indicates whether the particle aspect ratio should be
* compared to the ratio for the inner target or the outer
* @return The aspect ratio score (0-100)
*/
public static double scoreAspectRatio(BinaryImage image,ParticleAnalysisReport report,int particleNumber,boolean outer) throws NIVisionException {
double rectLong,rectShort,aspectRatio,idealAspectRatio;
rectLong = NIVision.MeasureParticle(image.image,particleNumber,false,NIVision.MeasurementType.IMAQ_MT_EQUIVALENT_RECT_LONG_SIDE);
rectShort = NIVision.MeasureParticle(image.image,NIVision.MeasurementType.IMAQ_MT_EQUIVALENT_RECT_SHORT_SIDE);
//idealAspectRatio = outer ? (62/29) : (62/20); //Dimensions of goal opening + 4 inches on all 4 sides for reflective tape
idealAspectRatio = outer ? (43 / 32) : (39 / 28);
//Divide width by height to measure aspect ratio
aspectRatio = report.boundingRectWidth / (double) report.boundingRectHeight;
/*if(report.boundingRectWidth > report.boundingRectHeight){
//particle is wider than it is tall,divide long by short
aspectRatio = 100*(1-Math.abs((1-((rectLong/rectShort)/idealAspectRatio))));
} else {
//particle is taller than it is wide,divide short by long
aspectRatio = 100*(1-Math.abs((1-((rectShort/rectLong)/idealAspectRatio))));
}*/
return aspectRatio;
//return (Math.max(0,Math.min(aspectRatio,100.0))); //force to be in range 0-100
}
项目：2014CataBot
文件：ImagingUtils.java
/**
* Computes a score based on the match between a template profile and the
* particle profile in the X direction. This method uses the the column
* averages and the profile defined at the top of the sample to look for the
* solid vertical edges with a hollow center.
*
* @param image The image to use,should be the image before the convex hull
* is performed
* @param report The Particle Analysis Report for the particle
*
* @return The X Edge score (0-100)
*/
public static double scoreXEdge(BinaryImage image,ParticleAnalysisReport report) throws NIVisionException {
double total = 0;
Linearaverages averages;
NIVision.Rect rect = new NIVision.Rect(report.boundingRectTop,report.boundingRectLeft,report.boundingRectHeight,report.boundingRectWidth);
averages = NIVision.getLinearaverages(image.image,Linearaverages.LinearaveragesMode.IMAQ_COLUMN_AVERAGES,rect);
float columnAverages[] = averages.getColumnAverages();
for (int i = 0; i < (columnAverages.length); i++) {
if (xMin[(i * (XMINSIZE - 1) / columnAverages.length)] < columnAverages[i]
&& columnAverages[i] < xMax[i * (XMAXSIZE - 1) / columnAverages.length]) {
totaL++;
}
}
total = 100 * total / (columnAverages.length);
return total;
}
项目：2014CataBot
文件：ImagingUtils.java
/**
* Computes a score based on the match between a template profile and the
* particle profile in the Y direction. This method uses the the row
* averages and the profile defined at the top of the sample to look for the
* solid horizontal edges with a hollow center
*
* @param image The image to use,should be the image before the convex hull
* is performed
* @param report The Particle Analysis Report for the particle
*
* @return The Y Edge score (0-100)
*
*/
public static double scoreYEdge(BinaryImage image,Linearaverages.LinearaveragesMode.IMAQ_ROW_AVERAGES,rect);
float rowAverages[] = averages.getRowAverages();
for (int i = 0; i < (rowAverages.length); i++) {
if (yMin[(i * (YMINSIZE - 1) / rowAverages.length)] < rowAverages[i]
&& rowAverages[i] < yMax[i * (YMAXSIZE - 1) / rowAverages.length]) {
totaL++;
}
}
total = 100 * total / (rowAverages.length);
return total;
}
项目：Aerial-Assist
文件：AxisCameraM1101.java
/**
* Computes a score (0-100) comparing the aspect ratio to the ideal aspect
* ratio for the target. This method uses the equivalent rectangle sides to
* determine aspect ratio as it performs better as the target gets skewed by
* moving to the left or right. The equivalent rectangle is the rectangle
* with sides x and y where particle area,xy and particle perimeter,2x+2y
*
* @param image The image containing the particle to score,needed to
* perform additional measurements
* @param report The Particle Analysis Report for the particle,and particle number
* @param outer Indicates whether the particle aspect ratio should be
* compared to the ratio for the inner target or the outer
* @return The aspect ratio score (0-100)
*/
private double scoreAspectRatio(BinaryImage image,ParticleAnalysisReport
report,boolean vertical) throws
NIVisionException {
double rectLong,MeasurementType.IMAQ_MT_EQUIVALENT_RECT_LONG_SIDE);
rectShort = NIVision.MeasureParticle(image.image,MeasurementType.IMAQ_MT_EQUIVALENT_RECT_SHORT_SIDE);
idealAspectRatio = vertical ? (4.0 / 32) : (23.5 / 4);
if (report.boundingRectWidth > report.boundingRectHeight) {
aspectRatio = ratioToscore((rectLong / rectShort)/idealAspectRatio);
} else {
aspectRatio = ratioToscore((rectShort / rectLong)/idealAspectRatio);
}
return aspectRatio;
}
项目：2014RobotCode
文件：CameraDetection.java
public double scoreAspectRatio(BinaryImage image,boolean vertical) throws NIVisionException
{
double rectLong,idealAspectRatio;
rectLong = NIVision.MeasureParticle(image.image,NIVision.MeasurementType.IMAQ_MT_EQUIVALENT_RECT_LONG_SIDE);
rectShort = NIVision.MeasureParticle(image.image,NIVision.MeasurementType.IMAQ_MT_EQUIVALENT_RECT_SHORT_SIDE);
idealAspectRatio = vertical ? (4.0/32) : (23.5/4); //Vertical reflector 4" wide x 32" tall,horizontal 23.5" wide x 4" tall
//Divide width by height to measure aspect ratio
if(report.boundingRectWidth > report.boundingRectHeight){
//particle is wider than it is tall,divide long by short
aspectRatio = ratioToscore((rectLong/rectShort)/idealAspectRatio);
} else {
//particle is taller than it is wide,divide short by long
aspectRatio = ratioToscore((rectShort/rectLong)/idealAspectRatio);
}
return aspectRatio;
}
项目：649code2014
文件：HottargetVision.java
/**
* Computes a score (0-100) comparing the aspect ratio to the ideal aspect
* ratio for the target. This method uses the equivalent rectangle sides to
* determine aspect ratio as it performs better as the target gets skewed by
* moving to the left or right. The equivalent rectangle is the rectangle
* with sides x and y where particle area= x*y and particle perimeter= 2x+2y
*
* @param image The image containing the particle to score,and particle number
* @param outer Indicates whether the particle aspect ratio should be
* compared to the ratio for the inner target or the outer
* @return The aspect ratio score (0-100)
*/
private static double scoreAspectRatio(BinaryImage image,boolean vertical) throws NIVisionException {
double rectLong,NIVision.MeasurementType.IMAQ_MT_EQUIVALENT_RECT_SHORT_SIDE);
idealAspectRatio = vertical ? (4.0 / 32) : (23.5 / 4); //Vertical reflector 4" wide x 32" tall,horizontal 23.5" wide x 4" tall
//Divide width by height to measure aspect ratio
if (report.boundingRectWidth > report.boundingRectHeight) {
//particle is wider than it is tall,divide long by short
aspectRatio = ratioToscore((rectLong / rectShort) / idealAspectRatio);
} else {
//particle is taller than it is wide,divide short by long
aspectRatio = ratioToscore((rectShort / rectLong) / idealAspectRatio);
}
return aspectRatio;
}
项目：FRCTesting
文件：ImageUtils.java
/** * Computes a score (0-100) comparing the aspect ratio to the ideal aspect * ratio for the target. This method uses the equivalent rectangle sides to * determine aspect ratio as it performs better as the target gets skewed by * moving to the left or right. The equivalent rectangle is the rectangle * with sides x and y where particle area= x*y and particle perimeter= 2x+2y * * @param image The image containing the particle to score,100.0))); //force to be in range 0-100 }
项目：FRCTesting
文件：ImageUtils.java
/**
* Computes a score based on the match between a template profile and the
* particle profile in the X direction. This method uses the the column
* averages and the profile defined at the top of the sample to look for the
* solid vertical edges with a hollow center.
*
* @param image The image to use,rect);
float columnAverages[] = averages.getColumnAverages();
for (int i = 0; i < (columnAverages.length); i++) {
if (xMin[(i * (XMINSIZE - 1) / columnAverages.length)] < columnAverages[i]
&& columnAverages[i] < xMax[i * (XMAXSIZE - 1) / columnAverages.length]) {
totaL++;
}
}
total = 100 * total / (columnAverages.length);
return total;
}
项目：FRCTesting
文件：ImageUtils.java
/**
* Computes a score based on the match between a template profile and the
* particle profile in the Y direction. This method uses the the row
* averages and the profile defined at the top of the sample to look for the
* solid horizontal edges with a hollow center
*
* @param image The image to use,rect);
float rowAverages[] = averages.getRowAverages();
for (int i = 0; i < (rowAverages.length); i++) {
if (yMin[(i * (YMINSIZE - 1) / rowAverages.length)] < rowAverages[i]
&& rowAverages[i] < yMax[i * (YMAXSIZE - 1) / rowAverages.length]) {
totaL++;
}
}
total = 100 * total / (rowAverages.length);
return total;
}
项目：2014_software
文件：HotGoalDetector.java
public double scoreAspectRatio(BinaryImage image,boolean vertical) throws NIVisionException
{
double rectLong,horizontal 23.5" wide x 4" tall
if (report.boundingRectWidth > report.boundingRectHeight)
{
aspectRatio = ratioToscore((rectLong / rectShort) / idealAspectRatio);
}
else
{
aspectRatio = ratioToscore((rectShort / rectLong) / idealAspectRatio);
}
return aspectRatio;
}
项目：2014_software
文件：HotGoalDetector.java
public double scoreAspectRatioOnRotatedImage(BinaryImage image,NIVision.MeasurementType.IMAQ_MT_EQUIVALENT_RECT_SHORT_SIDE);
idealAspectRatio = vertical ? (32.0 / 4) : (4/23.5); //Vertical reflector 4" wide x 32" tall,horizontal 23.5" wide x 4" tall
if (report.boundingRectWidth > report.boundingRectHeight)
{
aspectRatio = ratioToscore((rectLong / rectShort) / idealAspectRatio);
}
else
{
aspectRatio = ratioToscore((rectShort / rectLong) / idealAspectRatio);
}
return aspectRatio;
}
项目：FRC623Robot2014
文件：VisionController.java
/**
* Computes a score (0-100) comparing the aspect ratio to the ideal aspect
* ratio for the target. This method uses the equivalent rectangle sides to
* determine aspect ratio as it performs better as the target gets skewed by
* moving to the left or right. The equivalent rectangle is the rectangle
* with sides x and y where particle area= x*y and particle perimeter= 2x+2y
*
* @param image The image containing the particle to score,divide short by long
aspectRatio = ratioToscore((rectShort / rectLong) / idealAspectRatio);
}
return aspectRatio;
}
项目：2013ultimate-ascent
文件：GRTVisionTracker.java
/**
* Computes a score (0-100) comparing the aspect ratio to the ideal aspect ratio for the target. This method uses
* the equivalent rectangle sides to determine aspect ratio as it performs better as the target gets skewed by moving
* to the left or right. The equivalent rectangle is the rectangle with sides x and y where particle area= x*y
* and particle perimeter= 2x+2y
*
* @param image The image containing the particle to score,needed to performa additional measurements
* @param report The Particle Analysis Report for the particle,used for the width,and particle number
* @param outer Indicates whether the particle aspect ratio should be compared to the ratio for the inner target or the outer
* @return The aspect ratio score (0-100)
*/
public double scoreAspectRatio(BinaryImage image,boolean outer) throws NIVisionException
{
double rectLong,NIVision.MeasurementType.IMAQ_MT_EQUIVALENT_RECT_SHORT_SIDE);
//idealAspectRatio = outer ? (62/29) : (62/20); //Dimensions of goal opening + 4 inches on all 4 sides for reflective tape
//yonatan - change back
idealAspectRatio = outer ? (62/29) : (62/40); //Dimensions of goal opening + 4 inches on all 4 sides for reflective tape
//Divide width by height to measure aspect ratio
if(report.boundingRectWidth > report.boundingRectHeight){
//particle is wider than it is tall,divide long by short
aspectRatio = 100*(1-Math.abs((1-((rectLong/rectShort)/idealAspectRatio))));
} else {
//particle is taller than it is wide,divide short by long
aspectRatio = 100*(1-Math.abs((1-((rectShort/rectLong)/idealAspectRatio))));
}
return (Math.max(0,100.0))); //force to be in range 0-100
}
项目：2013ultimate-ascent
文件：GRTVisionTracker.java
/**
* Computes a score based on the match between a template profile and the particle profile in the X direction. This method uses the
* the column averages and the profile defined at the top of the sample to look for the solid vertical edges with
* a hollow center.
*
* @param image The image to use,should be the image before the convex hull is performed
* @param report The Particle Analysis Report for the particle
*
* @return The X Edge score (0-100)
*/
public double scoreXEdge(BinaryImage image,ParticleAnalysisReport report) throws NIVisionException
{
double total = 0;
Linearaverages averages;
NIVision.Rect rect = new NIVision.Rect(report.boundingRectTop,rect);
float columnAverages[] = averages.getColumnAverages();
for(int i=0; i < (columnAverages.length); i++){
if(xMin[(i*(XMINSIZE-1)/columnAverages.length)] < columnAverages[i]
&& columnAverages[i] < xMax[i*(XMAXSIZE-1)/columnAverages.length]){
totaL++;
}
}
total = 100*total/(columnAverages.length);
return total;
}
项目：2013ultimate-ascent
文件：GRTVisionTracker.java
/**
* Computes a score based on the match between a template profile and the particle profile in the Y direction. This method uses the
* the row averages and the profile defined at the top of the sample to look for the solid horizontal edges with
* a hollow center
*
* @param image The image to use,should be the image before the convex hull is performed
* @param report The Particle Analysis Report for the particle
*
* @return The Y Edge score (0-100)
*
*/
public double scoreYEdge(BinaryImage image,rect);
float rowAverages[] = averages.getRowAverages();
for(int i=0; i < (rowAverages.length); i++){
if(yMin[(i*(YMINSIZE-1)/rowAverages.length)] < rowAverages[i]
&& rowAverages[i] < yMax[i*(YMAXSIZE-1)/rowAverages.length]){
totaL++;
}
}
total = 100*total/(rowAverages.length);
return total;
}
项目：grtframeworkv7
文件：GRTVisionTracker.java
/** * Computes a score (0-100) comparing the aspect ratio to the ideal aspect ratio for the target. This method uses * the equivalent rectangle sides to determine aspect ratio as it performs better as the target gets skewed by moving * to the left or right. The equivalent rectangle is the rectangle with sides x and y where particle area= x*y * and particle perimeter= 2x+2y * * @param image The image containing the particle to score,100.0))); //force to be in range 0-100 }
项目：grtframeworkv7
文件：GRTVisionTracker.java
/**
* Computes a score based on the match between a template profile and the particle profile in the X direction. This method uses the
* the column averages and the profile defined at the top of the sample to look for the solid vertical edges with
* a hollow center.
*
* @param image The image to use,rect);
float columnAverages[] = averages.getColumnAverages();
for(int i=0; i < (columnAverages.length); i++){
if(xMin[(i*(XMINSIZE-1)/columnAverages.length)] < columnAverages[i]
&& columnAverages[i] < xMax[i*(XMAXSIZE-1)/columnAverages.length]){
totaL++;
}
}
total = 100*total/(columnAverages.length);
return total;
}
项目：grtframeworkv7
文件：GRTVisionTracker.java
/**
* Computes a score based on the match between a template profile and the particle profile in the Y direction. This method uses the
* the row averages and the profile defined at the top of the sample to look for the solid horizontal edges with
* a hollow center
*
* @param image The image to use,rect);
float rowAverages[] = averages.getRowAverages();
for(int i=0; i < (rowAverages.length); i++){
if(yMin[(i*(YMINSIZE-1)/rowAverages.length)] < rowAverages[i]
&& rowAverages[i] < yMax[i*(YMAXSIZE-1)/rowAverages.length]){
totaL++;
}
}
total = 100*total/(rowAverages.length);
return total;
}
项目：Team_1482_2013
文件：vision.java
/**
* Computes a score (0-100) comparing the aspect ratio to the ideal aspect ratio for the target. This method uses
* the equivalent rectangle sides to determine aspect ratio as it performs better as the target gets skewed by moving
* to the left or right. The equivalent rectangle is the rectangle with sides x and y where particle area= x*y
* and particle perimeter= 2x+2y
*
* @param image The image containing the particle to score,needed to perform additional measurements
* @param report The Particle Analysis Report for the particle,and particle number
* @param outer Indicates whether the particle aspect ratio should be compared to the ratio for the inner target or the outer
* @return The aspect ratio score (0-100)
*/
public double scoreAspectRatio(BinaryImage image,divide short by long
aspectRatio = ratioToscore((rectShort/rectLong)/idealAspectRatio);
}
return aspectRatio;
}
项目：Aerial-Assist
文件：AxisCameraM1101.java
/**
* Computes the estimated distance to a target using the height of the
* particle in the image. For more information and graphics showing the math
* behind this approach see the Vision Processing section of the
* ScreenStepsLive documentation.
*
* @param image The image to use for measuring the particle estimated
* rectangle.
* @param report The particle analysis report for the particle.
* @param outer True if the particle should be treated as an outer target,* false to treat it as a center target.
* @return The estimated distance to the target in inches.
*/
private double computedistance(BinaryImage image,int particleNumber) throws NIVisionException {
double rectLong,height;
int targetHeight;
rectLong = NIVision.MeasureParticle(image.image,MeasurementType.IMAQ_MT_EQUIVALENT_RECT_LONG_SIDE);
height = Math.min(report.boundingRectHeight,rectLong);
targetHeight = 32;
return Y_IMAGE_RES * targetHeight / (height * 12 * 2
* Math.tan(VIEW_ANGLE * Math.PI / (180 * 2)));
}
项目：2014RobotCode
文件：CameraDetection.java
double computedistance (BinaryImage image,int particleNumber) throws NIVisionException {
double rectLong,height;
int targetHeight;
rectLong = NIVision.MeasureParticle(image.image,NIVision.MeasurementType.IMAQ_MT_EQUIVALENT_RECT_LONG_SIDE);
//using the smaller of the estimated rectangle long side and the bounding rectangle height results in better performance
//on skewed rectangles
height = Math.min(report.boundingRectHeight,rectLong);
targetHeight = 32;
return Y_IMAGE_RES * targetHeight / (height * 12 * 2 * Math.tan(VIEW_ANGLE*Math.PI/(180*2)));
}
项目：2014_software
文件：HotGoalDetector.java
double computedistance(BinaryImage image,int particleNumber) throws NIVisionException
{
double rectLong,NIVision.MeasurementType.IMAQ_MT_EQUIVALENT_RECT_LONG_SIDE);
height = Math.min(report.boundingRectHeight,rectLong);
targetHeight = 32;
return Y_IMAGE_RES * targetHeight / (height * 12 * 2 * Math.tan(VIEW_ANGLE * Math.PI / (180 * 2)));
}
项目：2014_software
文件：HotGoalDetector.java
double computedistanceOnRotatedImage(BinaryImage image,NIVision.MeasurementType.IMAQ_MT_EQUIVALENT_RECT_LONG_SIDE);
height = Math.min(report.boundingRectWidth,rectLong);
targetHeight = 32;
return X_IMAGE_RES * targetHeight / (height * 12 * 2 * Math.tan(HORIZ_VIEW_ANGLE * Math.PI / (180 * 2)));
}
项目：RobotCode2013
文件：Vision.java
public VisionTarget [] processFrame() {
if (enableVision) {
lastFrame = System.currentTimeMillis();
try {
ColorImage image = camera.getimage();
BinaryImage bImage = image.thresholdRGB(
redLow,redHigh,greenLow,greenHigh,blueLow,blueHigh);
BinaryImage fImage = bImage.particleFilter(cc);
ParticleAnalysisReport [] report = fImage.getorderedParticleAnalysisReports();
VisionTarget [] targets = new VisionTarget[report.length];
for (int i = 0; i < report.length; i++) {
double centerX = report[i].center_mass_x;
double centerY = report[i].center_mass_y;
double width = report[i].boundingRectWidth;
double height = report[i].boundingRectHeight;
int area = (int)report[i].particleArea;
targets[i] = new VisionTarget(centerX,centerY,width,area);
}
frameProcess = System.currentTimeMillis() - lastFrame;
image.free();
bImage.free();
fImage.free();
return targets;
} catch (AxisCameraException e) {
System.out.println("No Image From Camera: ");
frameProcess = System.currentTimeMillis() - lastFrame;
return new VisionTarget[0];
} catch (Exception ex) {
System.out.println("Camera Exception Thrown: " + ex.getMessage());
frameProcess = System.currentTimeMillis() - lastFrame;
return new VisionTarget[0];
}
} else { // Vision is not enabled
return new VisionTarget[0];
}
}
项目：2013ultimate-ascent
文件：GRTVisionTracker.java
/**
* Computes the estimated distance to a target using the height of the particle in the image. For more information and graphics
* showing the math behind this approach see the Vision Processing section of the ScreenStepsLive documentation.
*
* @param image The image to use for measuring the particle estimated rectangle
* @param report The Particle Analysis Report for the particle
* @param outer True if the particle should be treated as an outer target,false to treat it as a center target
* @return The estimated distance to the target in Inches.
*/
double computedistance (BinaryImage image,boolean outer) throws NIVisionException {
double rectShort,height;
double targetWidth,targetHeight;
rectShort = NIVision.MeasureParticle(image.image,NIVision.MeasurementType.IMAQ_MT_EQUIVALENT_RECT_SHORT_SIDE);
//using the smaller of the estimated rectangle short side and the bounding rectangle height results in better performance
//on skewed rectangles
//height = Math.min(report.boundingRectHeight,rectShort);
width = report.boundingRectWidth;
height = report.boundingRectHeight;
//targetHeight = outer ? 29 : 21;
//changed by Yonatan Oren//
//need to change this back to 29/21 for for real ultimate ascent//
targetWidth = 16;
targetHeight = 9.75;
////
// System.out.println("rectShort: " + rectShort);
// System.out.println("height: " + height);
// System.out.println("boundingRectHeight: " + report.boundingRectHeight);
//changed by Yonatan Oren//
//return X_IMAGE_RES * targetHeight / (height * 12 * 2 * Math.tan(VIEW_ANGLE*Math.PI/(180*2)));
//return 240.0 * targetWidth / (width * Math.tan(VIEW_ANGLE*Math.PI/(180*2)));
return 360.0 * targetHeight / (height * Math.tan(VIEW_ANGLE*Math.PI/(180*2)));
//4800 / 62 * tan(
}
项目：grtframeworkv7
文件：GRTVisionTracker.java
/**
* Computes the estimated distance to a target using the height of the particle in the image. For more information and graphics
* showing the math behind this approach see the Vision Processing section of the ScreenStepsLive documentation.
*
* @param image The image to use for measuring the particle estimated rectangle
* @param report The Particle Analysis Report for the particle
* @param outer True if the particle should be treated as an outer target,rectShort);
width = report.boundingRectWidth;
height = report.boundingRectHeight;
//targetHeight = outer ? 29 : 21;
//changed by Yonatan Oren//
//need to change this back to 29/21 for for real ultimate ascent//
targetWidth = 16;
targetHeight = 9.75;
////
// System.out.println("rectShort: " + rectShort);
// System.out.println("height: " + height);
// System.out.println("boundingRectHeight: " + report.boundingRectHeight);
//changed by Yonatan Oren//
//return X_IMAGE_RES * targetHeight / (height * 12 * 2 * Math.tan(VIEW_ANGLE*Math.PI/(180*2)));
//return 240.0 * targetWidth / (width * Math.tan(VIEW_ANGLE*Math.PI/(180*2)));
return 360.0 * targetHeight / (height * Math.tan(VIEW_ANGLE*Math.PI/(180*2)));
//4800 / 62 * tan(
}
项目：Robot-Code-2013
文件：CameraSubsystem.java
public BinaryImage getFilteredImage() throws Exception {
ColorImage ci = getimage();
bi = ci.thresholdRGB(RED_LOW,RED_HIGH,GREEN_LOW,GREEN_HIGH,BLUE_LOW,BLUE_HIGH);
bi = bi.convexHull(false);
bi = bi.removeSmallObjects(true,3);
bi = bi.particleFilter(cc);
ci.free();
return bi;
}
项目：Team_1482_2013
文件：vision.java
public BinaryImage getHSVimage(ColorImage image){
try{
this.HSVimage = image.thresholdHSV(92,196,19,100,30,100);
} catch (NIVisionException ex) {
ex.printstacktrace();
}
System.out.println("Processed HSV image");
return this.HSVimage;
}
项目：Team_1482_2013
文件：vision.java
public BinaryImage getRGBimage(ColorImage image) {
try{
this.RGBimage = image.thresholdRGB(0,150,145,230,120,225);
} catch (NIVisionException ex) {
ex.printstacktrace();
}
System.out.println("Processing RGB image");
return this.RGBimage;
}
项目：Team_1482_2013
文件：vision.java
/**
* Computes the estimated distance to a target using the height of the particle in the image. For more information and graphics
* showing the math behind this approach see the Vision Processing section of the ScreenStepsLive documentation.
*
* @param image The image to use for measuring the particle estimated rectangle
* @param report The Particle Analysis Report for the particle
* @param outer True if the particle should be treated as an outer target,false to treat it as a center target
* @return The estimated distance to the target in Inches.
*/
double computedistance (BinaryImage image,rectLong);
targetHeight = 32;
return Y_IMAGE_RES * targetHeight / (height * 12 * 2 * Math.tan(VIEW_ANGLE*Math.PI/(180*2)));
}
项目：2014CataBot
文件：ImagingUtils.java
/**
* Computes the estimated distance to a target using the height of the
* particle in the image. For more information and graphics showing the math
* behind this approach see the Vision Processing section of the
* ScreenStepsLive documentation.
*
* @param image The image to use for measuring the particle estimated
* rectangle
* @param report The Particle Analysis Report for the particle
* @param outer True if the particle should be treated as an outer target,* false to treat it as a center target
* @return The estimated distance to the target in Inches.
*/
public static double computedistance(BinaryImage image,boolean outer) throws NIVisionException {
double rectShort,height;
int targetHeight;
rectShort = NIVision.MeasureParticle(image.image,NIVision.MeasurementType.IMAQ_MT_EQUIVALENT_RECT_SHORT_SIDE);
//using the smaller of the estimated rectangle short side and the bounding rectangle height results in better performance
//on skewed rectangles
height = Math.min(report.boundingRectHeight,rectShort);
targetHeight = outer ? 29 : 21;
return X_IMAGE_RES * targetHeight / (height * 12 * 2 * Math.tan(VIEW_ANGLE * Math.PI / (180 * 2)));
}
项目：649code2014
文件：HottargetVision.java
/**
* Computes the estimated distance to a target using the height of the
* particle in the image. For more information and graphics showing the math
* behind this approach see the Vision Processing section of the
* ScreenStepsLive documentation.
*
* @param image The image to use for measuring the particle estimated
* rectangle
* @param report The Particle Analysis Report for the particle
* @param outer True if the particle should be treated as an outer target,* false to treat it as a center target
* @return The estimated distance to the target in Inches.
*/
private static double computedistance(BinaryImage image,NIVision.MeasurementType.IMAQ_MT_EQUIVALENT_RECT_LONG_SIDE);
//using the smaller of the estimated rectangle long side and the bounding rectangle height results in better performance
//on skewed rectangles
height = Math.min(report.boundingRectHeight,rectLong);
targetHeight = 32;
return Y_IMAGE_RES * targetHeight / (height * 12 * 2 * Math.tan(VIEW_ANGLE * Math.PI / (180 * 2)));
}
项目：FRCTesting
文件：ImageUtils.java
/**
* Computes the estimated distance to a target using the height of the
* particle in the image. For more information and graphics showing the math
* behind this approach see the Vision Processing section of the
* ScreenStepsLive documentation.
*
* @param image The image to use for measuring the particle estimated
* rectangle
* @param report The Particle Analysis Report for the particle
* @param outer True if the particle should be treated as an outer target,rectShort);
targetHeight = outer ? 29 : 21;
return X_IMAGE_RES * targetHeight / (height * 12 * 2 * Math.tan(VIEW_ANGLE * Math.PI / (180 * 2)));
}
项目：FRC623Robot2014
文件：VisionController.java
/**
* Computes the estimated distance to a target using the height of the
* particle in the image. For more information and graphics showing the math
* behind this approach see the Vision Processing section of the
* ScreenStepsLive documentation.
*
* @param image The image to use for measuring the particle estimated
* rectangle
* @param report The Particle Analysis Report for the particle
* @param outer True if the particle should be treated as an outer target,* false to treat it as a center target
* @return The estimated distance to the target in Inches.
*/
double computedistance(BinaryImage image,rectLong);
targetHeight = 32;
return Y_IMAGE_RES * targetHeight / (height * 12 * 2 * Math.tan(VIEW_ANGLE * Math.PI / (180 * 2)));
}
我们今天的关于binary,varbinary,image的区别和binary和varbinary的分享已经告一段落，感谢您的关注，如果您想了解更多关于.net – SQL Server Varbinary(max)：从varbinary字段中选择一个字节子集、c# – 如何将图像存储到varbinary(max)列？、C#二进制读写BinaryReader、BinaryWriter、BinaryFormatter、edu.wpi.first.wpilibj.image.BinaryImage的实例源码的相关信息，请在本站查询。
本文标签：
