本文目录一览：- Oracle EBS OM 取消订单行（oracle 如何取消event）
- EBS oracle 批量导入更新 MOQ（最小拆分量、采购提前期、最小订购量、最小包装量）
- Excel oracle add in 无法上传journal to oracle ebs: members not found error0cle
- How to find Oracle EBS Weblogic Server Admin Port and URL
- Improving Oracle backup and recovery performance with Amazon EBS multi-volume crash-consistent sn...
Oracle EBS OM 取消订单行（oracle 如何取消event）
DECLARE
l_header_rec OE_ORDER_PUB.Header_Rec_Type;
l_line_tbl OE_ORDER_PUB.Line_Tbl_Type;
l_action_request_tbl OE_ORDER_PUB.Request_Tbl_Type;
l_header_adj_tbl OE_ORDER_PUB.Header_Adj_Tbl_Type;
l_line_adj_tbl OE_ORDER_PUB.line_adj_tbl_Type;
l_header_scr_tbl OE_ORDER_PUB.Header_Scredit_Tbl_Type;
l_line_scredit_tbl OE_ORDER_PUB.Line_Scredit_Tbl_Type;
l_request_rec OE_ORDER_PUB.Request_Rec_Type ;
l_return_status VARCHAR2(1000);
l_msg_count NUMBER;
l_msg_data VARCHAR2(1000);
p_api_version_number NUMBER :=1.0;
p_init_msg_list VARCHAR2(10) := FND_API.G_FALSE;
p_return_values VARCHAR2(10) := FND_API.G_FALSE;
p_action_commit VARCHAR2(10) := FND_API.G_FALSE;
x_return_status VARCHAR2(1);
x_msg_count NUMBER;
x_msg_data VARCHAR2(100);
p_header_rec OE_ORDER_PUB.Header_Rec_Type := OE_ORDER_PUB.G_MISS_HEADER_REC;
p_old_header_rec OE_ORDER_PUB.Header_Rec_Type := OE_ORDER_PUB.G_MISS_HEADER_REC;
p_header_val_rec OE_ORDER_PUB.Header_Val_Rec_Type := OE_ORDER_PUB.G_MISS_HEADER_VAL_REC;
p_old_header_val_rec OE_ORDER_PUB.Header_Val_Rec_Type := OE_ORDER_PUB.G_MISS_HEADER_VAL_REC;
p_Header_Adj_tbl OE_ORDER_PUB.Header_Adj_Tbl_Type := OE_ORDER_PUB.G_MISS_HEADER_ADJ_TBL;
p_old_Header_Adj_tbl OE_ORDER_PUB.Header_Adj_Tbl_Type := OE_ORDER_PUB.G_MISS_HEADER_ADJ_TBL;
p_Header_Adj_val_tbl OE_ORDER_PUB.Header_Adj_Val_Tbl_Type := OE_ORDER_PUB.G_MISS_HEADER_ADJ_VAL_TBL;
p_old_Header_Adj_val_tbl OE_ORDER_PUB.Header_Adj_Val_Tbl_Type := OE_ORDER_PUB.G_MISS_HEADER_ADJ_VAL_TBL;
p_Header_price_Att_tbl OE_ORDER_PUB.Header_Price_Att_Tbl_Type := OE_ORDER_PUB.G_MISS_HEADER_PRICE_ATT_TBL;
p_old_Header_Price_Att_tbl OE_ORDER_PUB.Header_Price_Att_Tbl_Type := OE_ORDER_PUB.G_MISS_HEADER_PRICE_ATT_TBL;
p_Header_Adj_Att_tbl OE_ORDER_PUB.Header_Adj_Att_Tbl_Type := OE_ORDER_PUB.G_MISS_HEADER_ADJ_ATT_TBL;
p_old_Header_Adj_Att_tbl OE_ORDER_PUB.Header_Adj_Att_Tbl_Type := OE_ORDER_PUB.G_MISS_HEADER_ADJ_ATT_TBL;
p_Header_Adj_Assoc_tbl OE_ORDER_PUB.Header_Adj_Assoc_Tbl_Type := OE_ORDER_PUB.G_MISS_HEADER_ADJ_ASSOC_TBL;
p_old_Header_Adj_Assoc_tbl OE_ORDER_PUB.Header_Adj_Assoc_Tbl_Type := OE_ORDER_PUB.G_MISS_HEADER_ADJ_ASSOC_TBL;
p_Header_Scredit_tbl OE_ORDER_PUB.Header_Scredit_Tbl_Type := OE_ORDER_PUB.G_MISS_HEADER_SCREDIT_TBL;
p_old_Header_Scredit_tbl OE_ORDER_PUB.Header_Scredit_Tbl_Type := OE_ORDER_PUB.G_MISS_HEADER_SCREDIT_TBL;
p_Header_Scredit_val_tbl OE_ORDER_PUB.Header_Scredit_Val_Tbl_Type := OE_ORDER_PUB.G_MISS_HEADER_SCREDIT_VAL_TBL;
p_old_Header_Scredit_val_tbl OE_ORDER_PUB.Header_Scredit_Val_Tbl_Type := OE_ORDER_PUB.G_MISS_HEADER_SCREDIT_VAL_TBL;
p_line_tbl OE_ORDER_PUB.Line_Tbl_Type := OE_ORDER_PUB.G_MISS_LINE_TBL;
p_old_line_tbl OE_ORDER_PUB.Line_Tbl_Type := OE_ORDER_PUB.G_MISS_LINE_TBL;
p_line_val_tbl OE_ORDER_PUB.Line_Val_Tbl_Type := OE_ORDER_PUB.G_MISS_LINE_VAL_TBL;
p_old_line_val_tbl OE_ORDER_PUB.Line_Val_Tbl_Type := OE_ORDER_PUB.G_MISS_LINE_VAL_TBL;
p_Line_Adj_tbl OE_ORDER_PUB.Line_Adj_Tbl_Type := OE_ORDER_PUB.G_MISS_LINE_ADJ_TBL;
p_old_Line_Adj_tbl OE_ORDER_PUB.Line_Adj_Tbl_Type := OE_ORDER_PUB.G_MISS_LINE_ADJ_TBL;
p_Line_Adj_val_tbl OE_ORDER_PUB.Line_Adj_Val_Tbl_Type := OE_ORDER_PUB.G_MISS_LINE_ADJ_VAL_TBL;
p_old_Line_Adj_val_tbl OE_ORDER_PUB.Line_Adj_Val_Tbl_Type := OE_ORDER_PUB.G_MISS_LINE_ADJ_VAL_TBL;
p_Line_price_Att_tbl OE_ORDER_PUB.Line_Price_Att_Tbl_Type := OE_ORDER_PUB.G_MISS_LINE_PRICE_ATT_TBL;
p_old_Line_Price_Att_tbl OE_ORDER_PUB.Line_Price_Att_Tbl_Type := OE_ORDER_PUB.G_MISS_LINE_PRICE_ATT_TBL;
p_Line_Adj_Att_tbl OE_ORDER_PUB.Line_Adj_Att_Tbl_Type := OE_ORDER_PUB.G_MISS_LINE_ADJ_ATT_TBL;
p_old_Line_Adj_Att_tbl OE_ORDER_PUB.Line_Adj_Att_Tbl_Type := OE_ORDER_PUB.G_MISS_LINE_ADJ_ATT_TBL;
p_Line_Adj_Assoc_tbl OE_ORDER_PUB.Line_Adj_Assoc_Tbl_Type := OE_ORDER_PUB.G_MISS_LINE_ADJ_ASSOC_TBL;
p_old_Line_Adj_Assoc_tbl OE_ORDER_PUB.Line_Adj_Assoc_Tbl_Type := OE_ORDER_PUB.G_MISS_LINE_ADJ_ASSOC_TBL;
p_Line_Scredit_tbl OE_ORDER_PUB.Line_Scredit_Tbl_Type := OE_ORDER_PUB.G_MISS_LINE_SCREDIT_TBL;
p_old_Line_Scredit_tbl OE_ORDER_PUB.Line_Scredit_Tbl_Type := OE_ORDER_PUB.G_MISS_LINE_SCREDIT_TBL;
p_Line_Scredit_val_tbl OE_ORDER_PUB.Line_Scredit_Val_Tbl_Type := OE_ORDER_PUB.G_MISS_LINE_SCREDIT_VAL_TBL;
p_old_Line_Scredit_val_tbl OE_ORDER_PUB.Line_Scredit_Val_Tbl_Type := OE_ORDER_PUB.G_MISS_LINE_SCREDIT_VAL_TBL;
p_Lot_Serial_tbl OE_ORDER_PUB.Lot_Serial_Tbl_Type := OE_ORDER_PUB.G_MISS_LOT_SERIAL_TBL;
p_old_Lot_Serial_tbl OE_ORDER_PUB.Lot_Serial_Tbl_Type := OE_ORDER_PUB.G_MISS_LOT_SERIAL_TBL;
p_Lot_Serial_val_tbl OE_ORDER_PUB.Lot_Serial_Val_Tbl_Type := OE_ORDER_PUB.G_MISS_LOT_SERIAL_VAL_TBL;
p_old_Lot_Serial_val_tbl OE_ORDER_PUB.Lot_Serial_Val_Tbl_Type := OE_ORDER_PUB.G_MISS_LOT_SERIAL_VAL_TBL;
p_action_request_tbl OE_ORDER_PUB.Request_Tbl_Type := OE_ORDER_PUB.G_MISS_REQUEST_TBL;
x_header_val_rec OE_ORDER_PUB.Header_Val_Rec_Type;
x_Header_Adj_tbl OE_ORDER_PUB.Header_Adj_Tbl_Type;
x_Header_Adj_val_tbl OE_ORDER_PUB.Header_Adj_Val_Tbl_Type;
x_Header_price_Att_tbl OE_ORDER_PUB.Header_Price_Att_Tbl_Type;
x_Header_Adj_Att_tbl OE_ORDER_PUB.Header_Adj_Att_Tbl_Type;
x_Header_Adj_Assoc_tbl OE_ORDER_PUB.Header_Adj_Assoc_Tbl_Type;
x_Header_Scredit_tbl OE_ORDER_PUB.Header_Scredit_Tbl_Type;
x_Header_Scredit_val_tbl OE_ORDER_PUB.Header_Scredit_Val_Tbl_Type;
x_line_val_tbl OE_ORDER_PUB.Line_Val_Tbl_Type;
x_Line_Adj_tbl OE_ORDER_PUB.Line_Adj_Tbl_Type;
x_Line_Adj_val_tbl OE_ORDER_PUB.Line_Adj_Val_Tbl_Type;
x_Line_price_Att_tbl OE_ORDER_PUB.Line_Price_Att_Tbl_Type;
x_Line_Adj_Att_tbl OE_ORDER_PUB.Line_Adj_Att_Tbl_Type;
x_Line_Adj_Assoc_tbl OE_ORDER_PUB.Line_Adj_Assoc_Tbl_Type;
x_Line_Scredit_tbl OE_ORDER_PUB.Line_Scredit_Tbl_Type;
x_Line_Scredit_val_tbl OE_ORDER_PUB.Line_Scredit_Val_Tbl_Type;
x_Lot_Serial_tbl OE_ORDER_PUB.Lot_Serial_Tbl_Type;
x_Lot_Serial_val_tbl OE_ORDER_PUB.Lot_Serial_Val_Tbl_Type;
x_action_request_tbl OE_ORDER_PUB.Request_Tbl_Type;
X_DEBUG_FILE VARCHAR2(100);
l_line_tbl_index NUMBER;
l_msg_index_out NUMBER(10);
BEGIN
dbms_output.enable(1000000);
fnd_global.apps_initialize(1318,21623,660); -- pass in user_id, responsibility_id, and application_id
oe_msg_pub.initialize;
oe_debug_pub.initialize;
X_DEBUG_FILE := OE_DEBUG_PUB.Set_Debug_Mode(''FILE'');
oe_debug_pub.SetDebugLevel(5); -- Use 5 for the most debuging output, I warn you its a lot of data
dbms_output.put_line(''START OF NEW DEBUG'');
--This is to CANCEL an existing order line
l_line_tbl_index :=1;
-- Initialize record to missing
l_line_tbl(l_line_tbl_index) := OE_ORDER_PUB.G_MISS_LINE_REC;
l_line_tbl(l_line_tbl_index).header_id := 98252; --Optional Parameter
l_line_tbl(l_line_tbl_index).line_id := 200869; --Mandatory parameter
l_line_tbl(l_line_tbl_index).ordered_quantity := 0;
l_line_tbl(l_line_tbl_index).cancelled_flag := ''Y'';
l_line_tbl(l_line_tbl_index).change_reason := ''Not provided'';
l_line_tbl(l_line_tbl_index).operation := OE_GLOBALS.G_OPR_Update;
-- CALL TO PROCESS orDER
OE_ORDER_PUB.process_order (
p_api_version_number => 1.0
, p_init_msg_list => fnd_api.g_false
, p_return_values => fnd_api.g_false
, p_action_commit => fnd_api.g_false
, x_return_status => l_return_status
, x_msg_count => l_msg_count
, x_msg_data => l_msg_data
, p_header_rec => l_header_rec
, p_line_tbl => l_line_tbl
, p_action_request_tbl => l_action_request_tbl
-- OUT PARAMETERS
, x_header_rec => l_header_rec
, x_header_val_rec => x_header_val_rec
, x_Header_Adj_tbl => x_Header_Adj_tbl
, x_Header_Adj_val_tbl => x_Header_Adj_val_tbl
, x_Header_price_Att_tbl => x_Header_price_Att_tbl
, x_Header_Adj_Att_tbl => x_Header_Adj_Att_tbl
, x_Header_Adj_Assoc_tbl => x_Header_Adj_Assoc_tbl
, x_Header_Scredit_tbl => x_Header_Scredit_tbl
, x_Header_Scredit_val_tbl => x_Header_Scredit_val_tbl
, x_line_tbl => l_line_tbl
, x_line_val_tbl => x_line_val_tbl
, x_Line_Adj_tbl => x_Line_Adj_tbl
, x_Line_Adj_val_tbl => x_Line_Adj_val_tbl
, x_Line_price_Att_tbl => x_Line_price_Att_tbl
, x_Line_Adj_Att_tbl => x_Line_Adj_Att_tbl
, x_Line_Adj_Assoc_tbl => x_Line_Adj_Assoc_tbl
, x_Line_Scredit_tbl => x_Line_Scredit_tbl
, x_Line_Scredit_val_tbl => x_Line_Scredit_val_tbl
, x_Lot_Serial_tbl => x_Lot_Serial_tbl
, x_Lot_Serial_val_tbl => x_Lot_Serial_val_tbl
, x_action_request_tbl => l_action_request_tbl
);
dbms_output.put_line(''OM Debug file: '' ||oe_debug_pub.G_DIR||''/''||oe_debug_pub.G_FILE);
-- Retrieve messages
FOR i IN 1 .. l_msg_count
LOOP
Oe_Msg_Pub.get( p_msg_index => i
, p_encoded => Fnd_Api.G_FALSE
, p_data => l_msg_data
, p_msg_index_out => l_msg_index_out);
DBMS_OUTPUT.PUT_LINE(''message is: '' || l_msg_data);
DBMS_OUTPUT.PUT_LINE(''message index is: '' || l_msg_index_out);
dbms_output.put_line('' www.dezai.cn'');
END LOOP;
-- Check the return status
IF l_return_status = FND_API.G_RET_STS_SUCCESS
THEN
dbms_output.put_line(''Process order Success'');
ELSE
dbms_output.put_line(''Failed'');
END IF;
END;
/
Commit;
EBS oracle 批量导入更新 MOQ（最小拆分量、采购提前期、最小订购量、最小包装量）
EXCEL 的列：组织 id, 供应商编号，供应商地点，料号，最小拆分量、采购提前期、最小订购量、最小包装量
-- 采购导入更新 MOQ 四个值，若有为空的那列，会保留原来的值，不会去更新那列的值
PROCEDURE UPDATE_PO_MOQ AS
CURSOR PO_MOQ_CUR IS
SELECT ID,
TRIM(ORG_ID) ORG_ID,
trim(vendor_no) vendor_no,
trim(vendor_site) vendor_site,
trim(segment1) segment1,
TRIM(min_split_qty) min_split_qty,
TRIM(processing_lead_time) processing_lead_time,
TRIM(min_order_qty) min_order_qty,
TRIM(fixed_order_quantity) fixed_order_quantity
FROM CUX.UPDATE_PO_MOQ_TEMP1; --CUX.EXCEL_BOM_LMH;
E_CHECK EXCEPTION;
V_ERR_MESSAGE VARCHAR2(2000);
L_VENDOR_ID NUMBER :=0;
L_VENDOR_SITE NUMBER :=0;
l_INVENTORY_ITEM_ID number := 0;
-- l_ORGANIZATION_ID number := 0;
L_COUNT NUMBER := 0;
begin
BEGIN
-- 清空导入错误表
DELETE FROM CUX_IMPORT_DATA_ERROR;
FOR PO_MOQ_REC IN PO_MOQ_CUR LOOP
BEGIN
SELECT count(*) into L_COUNT
FROM MEG_CUX_ORG_V
WHERE OPERATING_UNIT = PO_MOQ_REC.ORG_ID;
EXCEPTION
WHEN NO_DATA_FOUND THEN
V_ERR_MESSAGE := '' 业务实体【'' || PO_MOQ_REC.ORG_ID || ''】不存在 -'';
RAISE E_CHECK;
END;
BEGIN
SELECT P.VENDOR_ID into L_VENDOR_ID
FROM PO_VENDORS P
WHERE SEGMENT1 = PO_MOQ_REC.VENDOR_NO;
EXCEPTION
WHEN NO_DATA_FOUND THEN
V_ERR_MESSAGE := '' 供应商编号【'' || PO_MOQ_REC.VENDOR_NO || ''】不存在 -'';
RAISE E_CHECK;
END;
BEGIN
SELECT T.VENDOR_SITE_ID INTO L_VENDOR_SITE
FROM AP_SUPPLIER_SITES_ALL T
WHERE vendor_site_code = PO_MOQ_REC.VENDOR_SITE
and T.VENDOR_ID=L_VENDOR_ID
AND org_id =PO_MOQ_REC.ORG_ID;
EXCEPTION
WHEN NO_DATA_FOUND THEN
V_ERR_MESSAGE := '' 供应商简称 / 地点【'' || PO_MOQ_REC.VENDOR_SITE || ''】不存在 -'';
RAISE E_CHECK;
END ;
BEGIN
select msi.inventory_item_id
into l_INVENTORY_ITEM_ID
from mtl_system_items_b msi
where msi.segment1 = PO_MOQ_REC.SEGMENT1
and msi.organization_id = 140;
EXCEPTION
WHEN NO_DATA_FOUND THEN
V_ERR_MESSAGE := '' 料号【'' || PO_MOQ_REC.SEGMENT1 || ''】不存在 -'';
RAISE E_CHECK;
END;
BEGIN
-- 为空的列，不更新，保留原来的值
UPDATE PO_ASL_ATTRIBUTES PAA
SET PAA.ATTRIBUTE1=nvl(PO_MOQ_REC.MIN_SPLIT_QTY,PAA.ATTRIBUTE1),
PAA.PROCESSING_LEAD_TIME=nvl(PO_MOQ_REC.PROCESSING_LEAD_TIME,PAA.PROCESSING_LEAD_TIME),
PAA.MIN_ORDER_QTY=nvl(PO_MOQ_REC.MIN_ORDER_QTY,PAA.MIN_ORDER_QTY),
PAA.FIXED_LOT_MULTIPLE=nvl(PO_MOQ_REC.FIXED_ORDER_QUANTITY,PAA.FIXED_LOT_MULTIPLE)
WHERE vendor_id= L_VENDOR_ID
AND vendor_site_id =L_VENDOR_SITE
AND item_id =l_INVENTORY_ITEM_ID;
EXCEPTION
WHEN E_CHECK THEN
INSERT INTO CUX_IMPORT_DATA_ERROR
(ID, COLUMN_VALUES, ERR_MESSAGE)
VALUES
(PO_MOQ_REC.ID,
''【'' || PO_MOQ_REC.VENDOR_NO || ''】-【'' ||
PO_MOQ_REC.SEGMENT1 || ''】'',
V_ERR_MESSAGE);
END;
END LOOP;
END;
COMMIT;
end UPDATE_PO_MOQ;
Excel oracle add in 无法上传journal to oracle ebs: members not found error0cle
如何解决Excel oracle add in 无法上传journal to oracle ebs: members not found error0cle
想要用于 oracle ADI 的 Excel O365 加载项，专门用于总帐日志上传，生成为 .xlsm 来自 一直显示未找到成员。
已经尝试降级和停止自动更新excel版本，但还是不行。
How to find Oracle EBS Weblogic Server Admin Port and URL
How to find Oracle EBS Weblogic Server Admin Port and URL
Method 1
Open the Application tier context file
vi $CONTEXTFILE
Check the value of ''WLS Admin Server Port'' from "s_wls_adminport" parameter
Method 2
Open the EBS domain config file
vi $EBS_DOMAIN_HOME/config/config.xml
Check the ''listen-port'' value of the ''AdminServer''
Weblogic console URL
http://<server name>. <domain name> : <weblogic Admin Port>/console
Ex: http://oracle.test.com:7002/console
Password: As per environment
Improving Oracle backup and recovery performance with Amazon EBS multi-volume crash-consistent sn...
https://amazonaws-china.com/blogs/database/improving-oracle-backup-and-recovery-performance-with-amazon-ebs-multi-volume-crash-consistent-snapshots/
Amazon Elastic Block Store (EBS) snapshots offer the ability to back up the data on your EBS volumes to Amazon S3 by taking point-in-time snapshots. If you run your Oracle Databases on Amazon EC2 and use EBS volumes, you may be using EBS snapshots to meet your backup requirements. Prior to May 2019, you had to put the database in backup mode and individually snapshot each EBS volume that contained database files. This approach had three main disadvantages:
- You had to interact with the database
- You had to take individual snapshots of the volumes by calling multiple APIs
- In backup mode, a database block is completely copied to the log buffer the first time it is modified, which likely generates more redo and impacts database performance for certain workloads
AWS released a new feature in May 2019 that allows you to create crash-consistent snapshots across all the EBS volumes attached to an EC2 instance with a single API call and minimal I/O pause. For more information, see Taking crash-consistent snapshots across multiple Amazon EBS volumes on an Amazon EC2 instance.
You can eliminate the need to put the database in backup mode by combining this feature and the Storage Snapshot Optimization feature introduced in Oracle Database 12c. This post describes and walks you through this process, discusses the benefits of this new feature (from a performance point of view), and also describes some use cases.
The database has to be 12c or greater to benefit from the Oracle Database 12c Storage Snapshot Optimization feature, which allows you to use third-party technologies to take a storage snapshot of your database without having to put the database in backup mode. You can use that snapshot to recover all or part of your database. For more information, see Storage Snapshot Optimization on the Oracle website.
Oracle customers with enterprise-grade, on-premises storage arrays and Oracle Database 12c with Storage Snapshot Optimization have enjoyed vastly improved backup and restore operations, such as point-in-time recovery and cloning. With the new EBS multi-volume crash-consistent snapshot capability, you can use similar skills you had used on-premises for years to improve your overall experience in AWS.
The main advantage of not putting the database (or tablespaces) in backup mode is that it generates less redo. Generating less redo reduces checkpoint frequency and redo size, which reduces both log write and database writer I/O during the backup and also reduces database recovery time if you need to apply the logs during a recovery.
Test environment
The test environment contained the following elements:
- An Oracle Database version 19c instance created in an EC2 instance (root volume is 50 GB)
- An ASM instance with two disk groups (
DATAandRECO)- The disk group
DATAconsists of nine EBS volumes presented as ASM disks (5 GB each) and contains the datafiles - The disk group
RECOconsists of four EBS volumes presented as ASM disks (30 GB each) and contains the redo log files, archive log files, and control files
- The disk group
- A 19-GB table, in which each block contains only two rows. Create and populate the table with the following code:
$ cat create_table.sql create table BDT ( id number(15) ,c1 varchar2(10) )tablespace BDT; insert /*+ APPEND */ into BDT select rownum ,''xxxxxxxxxx'' from dual connect by level <= 1; alter table BDT minimize records_per_block; truncate table BDT; alter session set WORKAREA_SIZE_POLICY=MANUAL; alter session set SORT_AREA_SIZE=1073741824; insert /*+ APPEND */ into BDT select rownum ,''xxxxxxxxxx'' from dual connect by level <= 5000000; - An initial crash-consistent multi-volume snapshot, which you can create with the following code:
$ cat ./cli_create_multivol_table_created.sh aws ec2 create-snapshots \ --instance-specification InstanceId=<your_instance_id>,ExcludeBootVolume=true \ --description "table created" \ --tag-specifications ''ResourceType=snapshot,Tags=[{Key="Name",Value="table created"}]''
During the tests in this post, you generate update activity on the table and simulate a need to recover the database after the update activity.
Using a crash-consistent snapshot and Oracle Storage Snapshot Optimization
The first test uses the crash-consistent snapshot feature and Oracle Storage Snapshot Optimization. Complete the following steps:
- Update a column on the 19-GB table with the following code:
$ cat update_table.sh sqlplus / as sysdba << EOF execute dbms_workload_repository.create_snapshot; update bdt.bdt set c1 = ''BDT''; commit; execute dbms_workload_repository.create_snapshot; EOFThe amount of redo generated is approximately 42 GB. See the following code:
Statistic Total per Second per Trans -------------------------------- ------------------ -------------- ------------- redo size 2,629,050,100 7,429,507.5 1.8778929E+08 - Take another crash-consistent multi-volume snapshot with the following code:
$ cat ./cli_create_multivol_table_updated.sh aws ec2 create-snapshots \ --instance-specification InstanceId=<your_instance_id>,ExcludeBootVolume=true \ --description "table updated" \ --tag-specifications ''ResourceType=snapshot,Tags=[{Key="Name",Value="table updated"}]
Simulating a use case
To simulate a need to recover the database, complete the following steps:
- Stop the EC2 instance and detach all the EBS volumes (except the root volume) with the following code:
$ cat ./cli_detach_non_root.sh # detach volumes from DATA for datavol in `aws ec2 describe-volumes --query ''Volumes[*].[VolumeId]'' --output text --filters Name=attachment.instance-id,Values=<your_instance_id> Name=size,Values=5` do aws ec2 detach-volume --instance-id <your_instance_id> --volume-id $datavol done # detach volumes from RECO for datavol in `aws ec2 describe-volumes --query ''Volumes[*].[VolumeId]'' --output text --filters Name=attachment.instance-id,Values=<your_instance_id> Name=size,Values=30` do aws ec2 detach-volume --instance-id <your_instance_id> --volume-id $datavol done - Create volumes from the initial crash-consistent multi-volume snapshot (for the DATA disk group only) and attach them to the EC2 instance with the following code:
$ cat ./cli_create_data_volumes_test1.sh # create DATA Volumes for datasnaps in `aws ec2 describe-snapshots --query ''Snapshots[*].[SnapshotId]'' --output text --filters Name=tag:Name,Values="table created" Name=volume-size,Values=5` do aws ec2 create-volume --availability-zone eu-west-3a --snapshot-id $datasnaps --tag-specifications ''ResourceType=volume,Tags=[{Key="Name",Value="Volume from table created snapshot"}]'' done $ cat ./cli_attach_data_volumes_test1.sh # Attach volumes for DATA for voldev in 1:/dev/sdf 2:/dev/sdg 3:/dev/sdh 4:/dev/sdi 5:/dev/sdj 6:/dev/sdk 7:/dev/sdl 8:/dev/sdm 9:/dev/sdn do themax=`echo $voldev | cut -f1 -d:` thedev=`echo $voldev | cut -f2 -d:` volid=`aws ec2 describe-volumes --query ''Volumes[*].[VolumeId]'' --output text --filters Name=tag:Name,Values="Volume from table created snapshot" --max-items $themax | grep -v None | tail -1` aws ec2 attach-volume --device $thedev --instance-id <your_instance_id> --volume-id $volid done - Create volumes from the crash-consistent multi-volume snapshot taken after the update (for the
RECOdisk group only) and attach them to the EC2 instance with the following code:$ cat ./cli_create_reco_volumes_test1.sh # create RECO Volumes for recosnaps in `aws ec2 describe-snapshots --query ''Snapshots[*].[SnapshotId]'' --output text --filters Name=tag:Name,Values="table updated" Name=volume-size,Values=30` do aws ec2 create-volume --availability-zone eu-west-3a --snapshot-id $recosnaps --tag-specifications ''ResourceType=volume,Tags=[{Key="Name",Value="Volume from table updated snapshot"}]'' done $ cat ./cli_attach_reco_volumes_test1.sh # Attach volumes for RECO for voldev in 1:/dev/sdo 2:/dev/sdp 3:/dev/sdq 4:/dev/sdr do themax=`echo $voldev | cut -f1 -d:` thedev=`echo $voldev | cut -f2 -d:` volid=`aws ec2 describe-volumes --query ''Volumes[*].[VolumeId]'' --output text --filters Name=tag:Name,Values="Volume from table updated snapshot" --max-items $themax | grep -v None | tail -1` aws ec2 attach-volume --device $thedev --instance-id <your_instance_id> --volume-id $volid doneThe
RECOdisk group contains redo log files, control files, and archived redo log files. It has all the needed information to recover the database.
Recovering the database
To recover the database, complete the following steps:
- Start the EC2 instance.
- Start the database. See the following code:
SQL> startup ORACLE instance started. Total System Global Area 4999608360 bytes Fixed Size 8906792 bytes Variable Size 822083584 bytes Database Buffers 4110417920 bytes Redo Buffers 58200064 bytes Database mounted. ORA-01113: file 1 needs media recovery ORA-01110: data file 1: ''+DATA/BDT19/DATAFILE/system.257.1010589259'' - Get the time of the initial snapshots (you can see it is unique across the snapshots). See the following code:
$ cat ./cli_describe_snapshots.sh aws ec2 describe-snapshots --query ''Snapshots[*].[StartTime]'' --output text --filters Name=tag:Name,Values="table created" Name=volume-size,Values=5 | uniq $ sh ./cli_describe_snapshots.sh 2019-11-23T10:43:10.964Z - Recover the database using the Storage Snapshot Optimization (update the snapshot time accordingly based on the previous output and add a few seconds). See the following code:
$ cat ./recover_opti.sh sqlplus / as sysdba << EOF alter session set nls_date_format=''YYYY/MM/DD HH24:MI:SS''; RECOVER database SNAPSHOT TIME ''2019/11/23 10:43:50''; alter database open; EOF $ time sh ./recover_opti.sh SQL*Plus: Release 19.0.0.0.0 - Production on Sat Nov 23 11:37:12 2019 Version 19.3.0.0.0 Copyright (c) 1982, 2019, Oracle. All rights reserved. Connected to: Oracle Database 19c Enterprise Edition Release 19.0.0.0.0 - Production Version 19.3.0.0.0 SQL> Session altered. SQL> Media recovery complete. SQL> Database altered. SQL> Disconnected from Oracle Database 19c Enterprise Edition Release 19.0.0.0.0 - Production Version 19.3.0.0.0 real 6m31.077s user 0m0.007s sys 0m0.021sThe time to recover is approximately 6 minutes.
Restoring the database
To restore the database as it was before the test, complete the following steps:
- Stop the EC2 instance and detach all the EBS volumes except the root one. You can use the same script that you used previously.
- Create volumes from the initial crash-consistent multi-volume snapshot (for the
DATAandRECOdisk groups) and attach them to the EC2 instance. See the following code:$ cat ./cli_create_reset_volumes.sh # create DATA Volumes for datasnaps in `aws ec2 describe-snapshots --query ''Snapshots[*].[SnapshotId]'' --output text --filters Name=tag:Name,Values="table created" Name=volume-size,Values=5` do aws ec2 create-volume --availability-zone eu-west-3a --snapshot-id $datasnaps --tag-specifications ''ResourceType=volume,Tags=[{Key="Name",Value="Volume to reset from table created snapshot"}]'' done # create RECO Volumes for recosnaps in `aws ec2 describe-snapshots --query ''Snapshots[*].[SnapshotId]'' --output text --filters Name=tag:Name,Values="table created" Name=volume-size,Values=30` do aws ec2 create-volume --availability-zone eu-west-3a --snapshot-id $recosnaps --tag-specifications ''ResourceType=volume,Tags=[{Key="Name",Value="Volume to reset from table created snapshot"}]'' done $ cat ./cli_attach_reset_volumes.sh for voldev in 1:/dev/sdf 2:/dev/sdg 3:/dev/sdh 4:/dev/sdi 5:/dev/sdj 6:/dev/sdk 7:/dev/sdl 8:/dev/sdm 9:/dev/sdn 10:/dev/sdo 11:/dev/sdp 12:/dev/sdq 13:/dev/sdr do themax=`echo $voldev | cut -f1 -d:` thedev=`echo $voldev | cut -f2 -d:` volid=`aws ec2 describe-volumes --query ''Volumes[*].[VolumeId]'' --output text --filters Name=tag:Name,Values="Volume to reset from table created snapshot" --max-items $themax | grep -v None | tail -1` aws ec2 attach-volume --device $thedev --instance-id <your_instance_id> --volume-id $volid done - Start the EC2 instance.
- Start the database.
The database instance starts and performs only instance recovery, as if the host had simply crashed. This is an excellent example of crash-consistent snapshot usage: simply restore and recover all the volumes as it was during the time of the snapshot.
Using the begin/end backup procedure
The second test uses the begin/end backup procedure. Complete the following steps:
- Put the database in backup mode. See the following code:
SQL> alter database begin backup; Database altered. - Take a snapshot looping on all the EBS volumes that belong to the
DATAdisk group with the following code:$ cat ./cli_create_data_snapshots_test2.sh # Snap DATA volumes for datavol in `aws ec2 describe-volumes --query ''Volumes[*].[VolumeId]'' --output text --filters Name=attachment.instance-id,Values=<your_instance_id> Name=size,Values=5` do aws ec2 create-snapshot --description "DATA snap begin backup" --tag-specifications ''ResourceType=snapshot,Tags=[{Key="Name",Value="DATA snap begin backup"}]'' --volume-id $datavol done - Update a column on the 19-GB table (with the same script as in the first test) with the following code:
$ cat ./update_table.sh sqlplus / as sysdba << EOF execute dbms_workload_repository.create_snapshot; update bdt.bdt set c1 = ''BDT''; commit; execute dbms_workload_repository.create_snapshot; EOFThe amount of redo generated is approximately 42 GB. See the following code:
Statistic Total per Second per Trans -------------------------------- ------------------ -------------- ------------- redo size 42,000,569,896 40,984,442.6 3.0000407E+09 - Put the database out of the backup mode. See the following code:
SQL> alter database end backup; Database altered. - Take a snapshot looping on all the EBS volumes that belong to the
RECOdisk group with the following code:$ cat ./cli_create_reco_snapshots_test2.sh # Snap RECO volumes for datavol in `aws ec2 describe-volumes --query ''Volumes[*].[VolumeId]'' --output text --filters Name=attachment.instance-id,Values=<your_instance_id> Name=size,Values=30` do aws ec2 create-snapshot --description "RECO snap end backup" --tag-specifications ''ResourceType=snapshot,Tags=[{Key="Name",Value="RECO snap end backup"}]'' --volume-id $datavol done
Simulating a use case
To simulate a need to recover the database, complete the following steps:
- Stop the EC2 instance and detach all the EBS volumes except the root one. Use the same code that you used previously.
- Create volumes from the snapshots of the EBS volumes that belong to the
DATAdisk group (while the database was in backup mode) and attach them to the EC2 instance. See the following code:$ cat ./cli_create_data_volumes_test2.sh # create DATA Volumes for datasnaps in `aws ec2 describe-snapshots --query ''Snapshots[*].[SnapshotId]'' --output text --filters Name=tag:Name,Values="DATA snap begin backup" Name=volume-size,Values=5` do aws ec2 create-volume --availability-zone eu-west-3a --snapshot-id $datasnaps --tag-specifications ''ResourceType=volume,Tags=[{Key="Name",Value="Volume from DATA snap begin backup"}]'' done $ cat ./cli_attach_data_volumes_test2.sh # Attach volumes for DATA for voldev in 1:/dev/sdf 2:/dev/sdg 3:/dev/sdh 4:/dev/sdi 5:/dev/sdj 6:/dev/sdk 7:/dev/sdl 8:/dev/sdm 9:/dev/sdn do themax=`echo $voldev | cut -f1 -d:` thedev=`echo $voldev | cut -f2 -d:` volid=`aws ec2 describe-volumes --query ''Volumes[*].[VolumeId]'' --output text --filters Name=tag:Name,Values="Volume from DATA snap begin backup" --max-items $themax | grep -v None | tail -1` aws ec2 attach-volume --device $thedev --instance-id <your_instance_id> --volume-id $volid done - Create volumes from the snapshots of the EBS volumes that belong to the
RECOdisk group (while the database was out of backup mode) and attach them to the EC2 instance. See the following code:$ cat ./cli_create_reco_volumes_test2.sh # create RECO Volumes for recosnaps in `aws ec2 describe-snapshots --query ''Snapshots[*].[SnapshotId]'' --output text --filters Name=tag:Name,Values="RECO snap end backup" Name=volume-size,Values=30` do aws ec2 create-volume --availability-zone eu-west-3a --snapshot-id $recosnaps --tag-specifications ''ResourceType=volume,Tags=[{Key="Name",Value="Volume from RECO snap end backup"}]'' done $ cat ./cli_attach_reco_volumes_test2.sh # Attach volumes for RECO for voldev in 1:/dev/sdo 2:/dev/sdp 3:/dev/sdq 4:/dev/sdr do themax=`echo $voldev | cut -f1 -d:` thedev=`echo $voldev | cut -f2 -d:` volid=`aws ec2 describe-volumes --query ''Volumes[*].[VolumeId]'' --output text --filters Name=tag:Name,Values="Volume from RECO snap end backup" --max-items $themax | grep -v None | tail -1` aws ec2 attach-volume --device $thedev --instance-id <your_instance_id> --volume-id $volid done
Recovering the database
To recover the database, complete the following steps:
- Start the EC2 instance.
- Start the database. See the following code:
SQL> startup ORACLE instance started. Total System Global Area 4999608360 bytes Fixed Size 8906792 bytes Variable Size 822083584 bytes Database Buffers 4110417920 bytes Redo Buffers 58200064 bytes Database mounted. ORA-01113: file 1 needs media recovery ORA-01110: data file 1: ''+DATA/BDT19/DATAFILE/system.257.1010589259'' - Recover the database. See the following code:
$ cat recover_non_opti.sh sqlplus / as sysdba << EOF RECOVER database; AUTO alter database open; EOF $ $ time sh ./recover_non_opti.sh SQL*Plus: Release 19.0.0.0.0 - Production on Sat Nov 23 13:06:46 2019 Version 19.3.0.0.0 Copyright (c) 1982, 2019, Oracle. All rights reserved. Connected to: Oracle Database 19c Enterprise Edition Release 19.0.0.0.0 - Production Version 19.3.0.0.0 SQL> ORA-00279: change 14646020 generated at 11/23/2019 12:15:13 needed for thread 1 ORA-00289: suggestion : +RECO/BDT19/ARCHIVELOG/2019_11_23/thread_1_seq_507.323.1025094369 ORA-00280: change 14646020 for thread 1 is in sequence #507 Specify log: {<RET>=suggested | filename | AUTO | CANCEL}. . (truncating output for visibility) . Log applied. Media recovery complete. SQL> Database altered. SQL> Disconnected from Oracle Database 19c Enterprise Edition Release 19.0.0.0.0 - Production Version 19.3.0.0.0 real 15m8.149s user 0m0.025s sys 0m0.025sThe time to recover is approximately 15 minutes.
Additional use cases
You could use crash-consistent snapshots in the following use cases:
- Point-in-time recovery
- Automation of test environments refresh and creation (without interacting at all with the source database)
- Add an additional layer of security (if you use another backup strategy, such as using rman and backing up to S3)
Conclusion
This post demonstrated that a database can generate far more redo logs while in backup mode (for the same update). The time to recover from the crash-consistent snapshots was far less than the time needed to recover from a standard begin backup/end backup strategy. Furthermore, you can easily use the crash-consistent snapshots to reconstruct the database (between the two tests) as it was before the first test (performing instance recovery only).
That said, if you run your Oracle Database instances on Amazon EC2 and use Amazon EBS volumes you might want to consider using the crash-consistent snapshots feature for the advantages mentioned above.
About the Author
Bertrand Drouvot is a Sr. Database Engineer with Amazon Web Services.
关于Oracle EBS OM 取消订单行和oracle 如何取消event的问题我们已经讲解完毕，感谢您的阅读，如果还想了解更多关于EBS oracle 批量导入更新 MOQ（最小拆分量、采购提前期、最小订购量、最小包装量）、Excel oracle add in 无法上传journal to oracle ebs: members not found error0cle、How to find Oracle EBS Weblogic Server Admin Port and URL、Improving Oracle backup and recovery performance with Amazon EBS multi-volume crash-consistent sn...等相关内容，可以在本站寻找。
本文标签：
