Python-Tkinter滚动条框架（python tkinter frame滚动条）

我的目标是向具有多个标签的框架添加垂直滚动条。一旦框架内的标签超过框架的高度，滚动条应自动启用。搜索之后，我发现了这个有用的帖子。根据该帖子，我了解到要实现我想要的功能（如果我错了，请纠正我，我是一个初学者），我必须先创建一个Frame，然后Canvas在该框架内创建一个并将滚动条粘贴到该框架上好。之后，创建另一个框架并将其作为窗口对象放在画布内。所以，我终于想出了这个：

from Tkinter import *def data():    for i in range(50):       Label(frame,text=i).grid(row=i,column=0)       Label(frame,text="my text"+str(i)).grid(row=i,column=1)       Label(frame,text="..........").grid(row=i,column=2)def myfunction(event):    canvas.configure(scrollregion=canvas.bbox("all"),width=200,height=200)root=Tk()sizex = 800sizey = 600posx  = 100posy  = 100root.wm_geometry("%dx%d+%d+%d" % (sizex, sizey, posx, posy))myframe=Frame(root,relief=GROOVE,width=50,height=100,bd=1)myframe.place(x=10,y=10)canvas=Canvas(myframe)frame=Frame(canvas)myscrollbar=Scrollbar(myframe,orient="vertical",command=canvas.yview)canvas.configure(yscrollcommand=myscrollbar.set)myscrollbar.pack(side="right",fill="y")canvas.pack(side="left")canvas.create_window((0,0),window=frame,anchor=''nw'')frame.bind("<Configure>",myfunction)data()root.mainloop()

1. 我做对了吗？有没有更好/更聪明的方法来实现此代码给我的输出？
2. 为什么必须使用网格方法？（我尝试了放置方法，但是所有标签都没有出现在画布上。）
3. anchor=’nw’在画布上创建窗口时使用的特别之处是什么？
   我是初学者，请保持简单的答案。

答案1

请注意，建议的代码仅适用于Python 2

这是一个例子：

from Tkinter import *   # from x import * is bad practicefrom ttk import *# http://tkinter.unpythonic.net/wiki/VerticalScrolledFrameclass VerticalScrolledFrame(Frame):    """A pure Tkinter scrollable frame that actually works!    * Use the ''interior'' attribute to place widgets inside the scrollable frame    * Construct and pack/place/grid normally    * This frame only allows vertical scrolling    """    def __init__(self, parent, *args, **kw):        Frame.__init__(self, parent, *args, **kw)                    # create a canvas object and a vertical scrollbar for scrolling it        vscrollbar = Scrollbar(self, orient=VERTICAL)        vscrollbar.pack(fill=Y, side=RIGHT, expand=FALSE)        canvas = Canvas(self, bd=0, highlightthickness=0,                        yscrollcommand=vscrollbar.set)        canvas.pack(side=LEFT, fill=BOTH, expand=TRUE)        vscrollbar.config(command=canvas.yview)        # reset the view        canvas.xview_moveto(0)        canvas.yview_moveto(0)        # create a frame inside the canvas which will be scrolled with it        self.interior = interior = Frame(canvas)        interior_id = canvas.create_window(0, 0, window=interior,                                           anchor=NW)        # track changes to the canvas and frame width and sync them,        # also updating the scrollbar        def _configure_interior(event):            # update the scrollbars to match the size of the inner frame            size = (interior.winfo_reqwidth(), interior.winfo_reqheight())            canvas.config(scrollregion="0 0 %s %s" % size)            if interior.winfo_reqwidth() != canvas.winfo_width():                # update the canvas''s width to fit the inner frame                canvas.config(width=interior.winfo_reqwidth())        interior.bind(''<Configure>'', _configure_interior)        def _configure_canvas(event):            if interior.winfo_reqwidth() != canvas.winfo_width():                # update the inner frame''s width to fill the canvas                canvas.itemconfigure(interior_id, width=canvas.winfo_width())        canvas.bind(''<Configure>'', _configure_canvas)if __name__ == "__main__":    class SampleApp(Tk):        def __init__(self, *args, **kwargs):            root = Tk.__init__(self, *args, **kwargs)            self.frame = VerticalScrolledFrame(root)            self.frame.pack()            self.label = Label(text="Shrink the window to activate the scrollbar.")            self.label.pack()            buttons = []            for i in range(10):                buttons.append(Button(self.frame.interior, text="Button " + str(i)))                buttons[-1].pack()    app = SampleApp()    app.mainloop()

它尚未将鼠标滚轮绑定到滚动条，但是可以的。但是，使用滚轮滚动可能会有些颠簸。

编辑：

到1）
恕我直言，滚动帧在Tkinter中有些棘手，而且似乎做得并不多。似乎没有优雅的方法可以做到这一点。
代码的一个问题是你必须手动设置画布大小-这就是我发布的示例代码所解决的问题。

至2）
你在谈论数据功能？Place也对我有用。（总的来说，我更喜欢网格）。

到3）
好吧，它将窗口放置在画布上。

我注意到的一件事是，你的示例默认情况下会处理鼠标滚轮滚动，而我发布的示例则不会。一定要看一下。

python gui tkinter快速入门教程 | python tkinter tutorial

本文首发于个人博客https://kezunlin.me/post/d5c57f56/，欢迎阅读最新内容！

python tkinter tutorial
<!--more-->

Guide

main ui

messagebox
- showinfo()
- showwarning()
- showerror()
- askquestion()
- askokcancel()
- askyesno()
- askretrycancel()
- askyesnocancel()


filedialog
- asksaveasfilename()
- asksaveasfile()
- askopenfilename()
- askopenfile()
- askdirectory()
- askopenfilenames()
- askopenfiles()

demo

from numpy.random import seed, uniform
from numpy import uint8, uint16, load, save

from cv2 import imread, imwrite
from os import listdir, makedirs
from os.path import exists, basename

# for python 3
from tkinter import Tk, Frame, messagebox, filedialog, Button, Label, StringVar

class MyGUI():
    def __init__(self):

        self.root = Tk()

        sw = self.root.winfo_screenwidth()
        sh = self.root.winfo_screenheight()

        ww = 700
        wh = 200
        x = (sw-ww) / 2
        y = (sh-wh) / 2
        self.root.title(''Image Compress Tool'')
        # center
        self.root.geometry("%dx%d+%d+%d" % (ww, wh, x, y))

        # frame1
        frame1 = Frame(self.root)
        frame1.grid(row=0, column=0, sticky=''w'')

        self.input_btn = Button(frame1, text="Input Folder", width=10, height=3, command=self.set_input_folder)
        self.input_btn.pack(side=''left'')

        self.input_label_text = StringVar()
        self.input_label_text.set("Input Folder")

        self.input_label = Label(frame1, textvariable=self.input_label_text, width=70, height=3)
        self.input_label.pack(side=''left'')

        # frame2
        frame2 = Frame(self.root)
        frame2.grid(row=1, column=0, sticky=''w'')

        self.output_btn = Button(frame2, text="Output Folder", width=10, height=3, command=self.set_output_folder)
        self.output_btn.pack(side=''left'')

        self.output_label_text = StringVar()
        self.output_label_text.set("Output Folder")

        self.output_label = Label(frame2, textvariable = self.output_label_text, width=70, height=3)
        self.output_label.pack(side=''left'')

        # frame3
        frame3 = Frame(self.root)
        frame3.grid(row=2, column=0, sticky=''nw'')

        self.run_btn = Button(frame3, text="执行加密", width=10, height=3, command=self.run_task)
        self.run_btn.pack(side=''left'')

        self.run_label_text = StringVar()
        self.run_label_text.set("Ready")

        self.run_label = Label(frame3, textvariable = self.run_label_text, width=70, height=3)
        self.run_label.pack(side=''left'')

    def mainloop(self):
        self.root.mainloop()

    def set_input_folder(self):
        result = filedialog.askdirectory()
        self.input_label_text.set(result)

    def set_output_folder(self):
        result = filedialog.askdirectory()
        self.output_label_text.set(result)

    def run_task(self):
        input_folder = self.input_label_text.get()
        output_folder = self.output_label_text.get()
        #print("input_folder: "+input_folder)
        #print("output_folder: "+output_folder)
        if exists(input_folder):
            #batch_compress(input_folder, output_folder)
            self.run_label_text.set("Compress OK.")
            messagebox.showinfo("Info", "Compress OK.")
        else:
            messagebox.showwarning("Warn", "Please input folder")

def gui():
    app = MyGUI()
    app.mainloop()

def main():
    gui()

if __name__ =="__main__":
    main()

snapshots

Reference

• tkinter demo
• tkinter docs

History

• 20190411: created.

Copyright

• Post author: kezunlin
• Post link: https://kezunlin.me/post/d5c57f56/
• Copyright Notice: All articles in this blog are licensed under CC BY-NC-SA 3.0 unless stating additionally.

Python GUI 编程 (Tkinter) 带滚动条的 Text

import tkinter

#创建主窗口
win = tkinter.Tk()
#设置标题
win.title("sunck")
#设置大小和位置
#win.geometry("400x400+200+20")

''''''
文本控件，用于显示多行文本
''''''
#创建滚动条
scroll = tkinter.Scrollbar()
text = tkinter.Text(win, width=50, height=8)
#side放到窗体的那一侧   fill填充
scroll.pack(side=tkinter.RIGHT, fill=tkinter.Y)
text.pack(side=tkinter.LEFT, fill=tkinter.Y)
#关联
scroll.config(command=text.yview)
text.config(yscrollcommand=scroll.set)

str = ''''''If there is anyone out there who still doubts that America is a place where all things are possible, who still wonders if the dream of our founders is alive in our time, who still questions the power of our democracy, tonight is your answerIt’s the answer told by lines that stretched around schools and churches in numbers this nation has never seen, by people who waited three hours and four hours, many for the first time in their lives, because they believed that this time must be different, that their voices could be that difference.''''''
text.insert(tkinter.INSERT, str)

win.mainloop()

python gui编程（tkinter）是什么？实例展示Python tkinter教程

之前的文章我们学习了python cgi编程，这篇文章我们就来介绍python gui编程（tkinter）并附上python tkinter教程。
python 提供了多个图形开发界面的库，几个常用 python gui 库如下：

Tkinter： Tkinter 模块(Tk 接口)是 Python 的标准 Tk GUI 工具包的接口 .Tk 和 Tkinter 可以在大多数的 Unix 平台下使用,同样可以应用在 Windows 和 Macintosh 系统里。Tk8.0 的后续版本可以实现本地窗口风格,并良好地运行在绝大多数平台中。

wxPython：wxPython 是一款开源软件，是 Python 语言的一套优秀的 GUI 图形库，允许 Python 程序员很方便的创建完整的、功能健全的 GUI 用户界面。

Jython：Jython 程序可以和 Java 无缝集成。除了一些标准模块，Jython 使用 Java 的模块。Jython 几乎拥有标准的Python 中不依赖于 C 语言的全部模块。比如，Jython 的用户界面将使用 Swing，AWT或者 SWT。Jython 可以被动态或静态地编译成 Java 字节码。

import tkinter

#!/usr/bin/python
# -*- coding: UTF-8 -*-
import Tkinter
top = Tkinter.Tk()
# 进入消息循环
top.mainloop()

def runclock(self):
        """
        Method that runs and change the clock info
        """
        #t0 = time.time()

        if self.playing:
            #Time remaining in milliseconds
            clock = self.clock


            minutes = clock//60000
            clock %= 60000

            sec = clock//1000
            clock %= 1000

            mil = clock//10

            #If the turn is of player 1
            if self.turn == 1:
                self.WriteClock(self.canvas1,self.play1,"%.2i:%.2i:%.2i"%(minutes,sec,mil))
            else:
                self.WriteClock(self.canvas2,self.play2,mil))

            #tf = time.time()

            #deltat = (tf - t0)

            #s = 1 - deltat

            self.rel -= 1

            #if s > 0:
            #    time.sleep(s/1000)
            #else:
            #    self.rel += s*1000

            self.root.after(1,self.runclock)
