二、k8s 实现集成 / 部署 / 交付

 三、创建一个 gitlab 的测试项目（网上找的简单代码测试）

1、测试代码

代码结构

[root@node2 test1]# tree
.
├── pom.xml
└── src
    └── main
        └── java
            └── hello
                ├── Greeter.java
                └── HelloWorld.java

package hello;

public class HelloWorld {
    public static void main(String[] args) {
        Greeter greeter = new Greeter();
        System.out.println(greeter.sayHello());
    }
}

HelloWorld.java

package hello;

public class Greeter {
    public String sayHello() {
        return "Hello world!";
    }
}

Greeter.java

<?xml version="1.0" encoding="UTF-8"?>
<project xmlns="http://maven.apache.org/POM/4.0.0" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance"
    xsi:schemaLocation="http://maven.apache.org/POM/4.0.0 http://maven.apache.org/maven-v4_0_0.xsd">
    <modelVersion>4.0.0</modelVersion>
    <groupId>org.springframework</groupId>
    <artifactId>gs-maven</artifactId>
    <packaging>jar</packaging>
    <version>0.1.0</version>

    <build>
        <plugins>
            <plugin>
                <groupId>org.apache.maven.plugins</groupId>
                <artifactId>maven-shade-plugin</artifactId>
                <version>2.1</version>
                <executions>
                    <execution>
                        <phase>package</phase>
                        <goals>
                            <goal>shade</goal>
                        </goals>
                        <configuration>
                            <transformers>
                                <transformer
                                    implementation="org.apache.maven.plugins.shade.resource.ManifestResourceTransformer">
                                    <mainClass>hello.HelloWorld</mainClass>
                                </transformer>
                            </transformers>
                        </configuration>
                    </execution>
                </executions>
            </plugin>
        </plugins>
    </build>
</project>

pom.xml

2、git 的测试项目

四、jenkins 配置

1、插件安装

安装好 git、GitLab Plugin、Gitlab Hook Plugin、Gitlab API Plugin、Pipeline、Kubernetes plugin 插件。

2、在 jenkins 中配置 kubernetes

 3、简单测试（创建一个 Pipline 项目）

测试的 Pipline 脚本

def label = "mypod-${UUID.randomUUID().toString()}"
podTemplate(label: ''label'', cloud: ''kubernetes'') {
    node(''label'') {
        stage(''Run shell'') {
            sh ''echo hello world''
        }
    }
}

 4、pipline 中配置 gi 凭证

创建凭证，username 是 gitlab 的账号，password 是 gitlab 账号对应的密码。

5、Pipline 中视图 git 凭证

mkdir myjenkins
cd myjenkins/
wget https://mirrors.tuna.tsinghua.edu.cn/apache/maven/maven-3/3.5.4/binaries/apache-maven-3.5.4-bin.tar.gz
tar xf apache-maven-3.5.4-bin.tar.gz

[root@node2 myjenkins]# cat Dockerfile
FROM jenkins/jnlp-slave:3.27-1
LABEL maintainer="maven@qq.com"
ENV MAVEN_HOME /usr/local/maven
ENV PATH=$PATH:$MAVEN_HOME/bin

COPY apache-maven-3.5.4  /usr/local/maven
[root@node2 myjenkins]# docker build  -t myjnlp-slave:1.0 ./

groupmod  -g10000  docker
chown root.docker   /var/run/docker.sock

def label = "mypod-${UUID.randomUUID().toString()}"
def registry = "registry-vpc.cn-hongkong.aliyuncs.com"
def app_name = "javatest"
def namespace = "aliyun-zhang"
def username = "xxxxxxxxxxxxxxxxxx"
def regpass = "xxxxxxxxxxxxxxxxxxx"


podTemplate(label: ''label'', cloud: ''kubernetes'', containers: [
    containerTemplate(
        name: ''jnlp'',
        image: ''myjnlp-slave:1.0''
    ),
],
  volumes: [
    hostPathVolume(mountPath: ''/var/run/docker.sock'', hostPath: ''/var/run/docker.sock''),
    hostPathVolume(mountPath: ''/usr/bin/docker'', hostPath: ''/usr/bin/docker'')
],)
{
    node(''label'') {
        stage(''Task'') {
            stage(''拉取代码'') {
                git credentialsId: ''gitlab-auth'', url: ''http://mygitlab-gitlab-ce.default.svc.cluster.local/root/test1.git''
                def mytag = sh returnStdout: true, script: ''git describe --always --tag''
                sh "git checkout -b $mytag"
                echo "mytag $mytag ${mytag} ----"

            }
            stage(''编译打包'') {
                echo "mvn clean package -Dmaven.test.skip=true"
            }

            stage(''构建上传镜像'') {
                def mytag = sh returnStdout: true, script: ''git describe --always --tag''
                def image_name = "${app_name}:${mytag}".minus("\n")

                echo "image_name $image_name"
                sh label: '''', script: ''''''              echo \''
                    FROM tomcat:latest
                    ADD pom.xml /usr/local/tomcat/webapps/
                    \'' > Dockerfile
                ''''''

                sh """
                    docker build  -t "${registry}/${namespace}/${image_name}" ./
                    docker login -u ${username} -p \"${regpass}\" ${registry}
                    docker push ${registry}/${namespace}/${image_name}

                """

            }
        }
    }
}

[root@k8s-m ~]# cat java-deploy.yaml
apiVersion: apps/v1
kind: Deployment
metadata:
  name: mydeploy
  namespace: default
spec:
  replicas: 2
  selector:
    matchLabels:
      test_node: k8s-node
  template:
    metadata:
      labels:
        test_node: k8s-node
    spec:
      containers:
      - name: myjava-server
        image: tomcat:latest
        ports:
        - name: http
          containerPort: 8080

def label = "mypod-${UUID.randomUUID().toString()}"
def registry = "registry-vpc.cn-hongkong.aliyuncs.com"
def app_name = "javatest"
def namespace = "aliyun-zhang"
def username = "xxxxxxxxxxxx"
def regpass = "xxxxxxxxx"
def k8s_auth = "5ce0993e-e2e9-4126-a910-2acd0a77fefb"


podTemplate(label: ''label'', cloud: ''kubernetes'', containers: [
    containerTemplate(
        name: ''jnlp'',
        image: ''myjnlp-slave:1.0''
    ),
],
  volumes: [
    hostPathVolume(mountPath: ''/var/run/docker.sock'', hostPath: ''/var/run/docker.sock''),
    hostPathVolume(mountPath: ''/usr/bin/docker'', hostPath: ''/usr/bin/docker'')
],)
{
    node(''label'') {
        stage(''Task'') {
            stage(''拉取代码'') {
                git credentialsId: ''gitlab-auth'', url: ''http://mygitlab-gitlab-ce.default.svc.cluster.local/root/test1.git''
                def mytag = sh returnStdout: true, script: ''git describe --always --tag''
                sh "git checkout -b $mytag"
                echo "mytag $mytag ${mytag} ----"
            }
            stage(''编译打包'') {
                sh "mvn clean package -Dmaven.test.skip=true"
            }

            stage(''构建上传镜像'') {
                def mytag = sh returnStdout: true, script: ''git describe --always --tag''
                def image_name = "${app_name}:${mytag}".minus("\n")

                echo "image_name $image_name"
                sh label: '''', script: ''''''              echo \''
                    FROM tomcat:latest
                    ADD target/*.jar /usr/local/tomcat/webapps/
                    \'' > Dockerfile
                ''''''

                sh """
                    docker build  -t "${registry}/${namespace}/${image_name}" ./
                    docker login -u ${username} -p \"${regpass}\" ${registry}
                    docker push ${registry}/${namespace}/${image_name}

                """
            }
             stage(''部署到K8S''){
                def mytag = sh returnStdout: true, script: ''git describe --always --tag''
                def image_name = "${app_name}:${mytag}".minus("\n")
                sh """
                sed -i ''s#tomcat:latest#${registry}/${namespace}/${image_name}#'' java-deploy.yaml
                """
                kubernetesDeploy configs: ''java-deploy.yaml'', kubeconfigId: "${k8s_auth}"
      }
        }
    }
}

[root@node2 test1]# echo 123 >> README.md
[root@node2 test1]# git commit -a -m ''123''
[master bda4c6f] 123
 1 file changed, 1 insertion(+), 1 deletion(-)
[root@node2 test1]# git tag  10.0
[root@node2 test1]# git push origin master 10.0
Username for ''http://10.101.58.237'': root
Password for ''http://root@10.101.58.237'':
Counting objects: 5, done.
Delta compression using up to 2 threads.
Compressing objects: 100% (2/2), done.
Writing objects: 100% (3/3), 347 bytes | 0 bytes/s, done.
Total 3 (delta 0), reused 0 (delta 0)
To http://10.101.58.237/root/test1.git
   da0fbc3..bda4c6f  master -> master
 * [new tag]         10.0 -> 10.0

[root@k8s-m ~]# kubectl get deploy  mydeploy
NAME       READY   UP-TO-DATE   AVAILABLE   AGE
mydeploy   2/2     2            2           64s
[root@k8s-m ~]# kubectl get pod
NAME                                   READY   STATUS    RESTARTS   AGE
mydeploy-746bb8db64-4fpvz              1/1     Running   0          69s
mydeploy-746bb8db64-pp7tw              1/1     Running   0          69s

[root@k8s-m ~]# kubectl get pod mydeploy-746bb8db64-4fpvz  -o yaml|grep image:
  - image: registry-vpc.cn-hongkong.aliyuncs.com/aliyun-zhang/javatest:10.0
    image: registry-vpc.cn-hongkong.aliyuncs.com/aliyun-zhang/javatest:10.0

kubectl rollout undo deployment/deploy-name

#查看 deployment 升级历史
[root@k8s-m ~]# kubectl rollout history deployment/mydeploy
deployment.extensions/mydeploy
REVISION  CHANGE-CAUSE
3         <none>
4         <none>

#看历史版本更加详细的升级信息
[root@k8s-m ~]# kubectl rollout history deployment/mydeploy  --revision=3
deployment.extensions/mydeploy with revision #3
Pod Template:
  Labels:    pod-template-hash=746bb8db64
    test_node=k8s-node
  Containers:
   myjava-server:
    Image:    registry-vpc.cn-hongkong.aliyuncs.com/aliyun-zhang/javatest:10.0
    Port:    8080/TCP
    Host Port:    0/TCP
    Environment:    <none>
    Mounts:    <none>
  Volumes:    <none>

kubectl rollout undo deployment/mydeploy --to-revision=3

[root@k8s-m recreate]# kubectl  explain deploy.spec.strategy.type
KIND:     Deployment
VERSION:  extensions/v1beta1

FIELD:    type <string>

DESCRIPTION:
     Type of deployment. Can be "Recreate" or "RollingUpdate". Default is
     RollingUpdate.

[root@k8s-m ~]# kubectl  get pod -w
NAME                     READY   STATUS    RESTARTS   AGE
my-app-bb9cc7597-dn5bv   1/1     Running   0          3m36s
my-app-bb9cc7597-gqfx4   1/1     Running   0          3m36s
my-app-bb9cc7597-p4dfb   1/1     Running   0          3m36s
my-app-bb9cc7597-p4dfb   1/1     Terminating   0          3m44s
my-app-bb9cc7597-dn5bv   1/1     Terminating   0          3m44s
my-app-bb9cc7597-gqfx4   1/1     Terminating   0          3m44s
my-app-bb9cc7597-p4dfb   0/1     Terminating   0          3m45s
my-app-bb9cc7597-gqfx4   0/1     Terminating   0          3m45s
my-app-bb9cc7597-dn5bv   0/1     Terminating   0          3m45s
my-app-bb9cc7597-p4dfb   0/1     Terminating   0          3m57s
my-app-bb9cc7597-p4dfb   0/1     Terminating   0          3m57s
my-app-db47b56bf-kwd2c   0/1     Pending       0          0s
my-app-db47b56bf-kwd2c   0/1     Pending       0          0s
my-app-db47b56bf-xkqdz   0/1     Pending       0          0s
my-app-db47b56bf-5v4r5   0/1     Pending       0          0s
my-app-db47b56bf-xkqdz   0/1     Pending       0          0s
my-app-db47b56bf-kwd2c   0/1     ContainerCreating   0          0s

[root@k8s-m ~]# kubectl get pod  -w
NAME                     READY   STATUS    RESTARTS   AGE
my-app-db47b56bf-2c2c6   1/1     Running   0          19s
my-app-db47b56bf-k7k5z   1/1     Running   0          19s
my-app-db47b56bf-mclj8   1/1     Running   0          19s
my-app-bb9cc7597-hgz6r   0/1     Pending   0          0s
my-app-bb9cc7597-hgz6r   0/1     Pending   0          0s
my-app-bb9cc7597-hgz6r   0/1     ContainerCreating   0          1s
my-app-bb9cc7597-hgz6r   0/1     ContainerCreating   0          1s
my-app-bb9cc7597-hgz6r   0/1     Running             0          5s
my-app-bb9cc7597-hgz6r   1/1     Running             0          6s
my-app-db47b56bf-mclj8   1/1     Terminating         0          29s
my-app-bb9cc7597-84ngs   0/1     Pending             0          0s
my-app-bb9cc7597-84ngs   0/1     Pending             0          0s
my-app-bb9cc7597-84ngs   0/1     ContainerCreating   0          1s
my-app-bb9cc7597-84ngs   0/1     ContainerCreating   0          2s
my-app-db47b56bf-mclj8   0/1     Terminating         0          31s
my-app-db47b56bf-mclj8   0/1     Terminating         0          34s
my-app-db47b56bf-mclj8   0/1     Terminating         0          34s
my-app-bb9cc7597-84ngs   0/1     Running             0          6s
my-app-bb9cc7597-84ngs   1/1     Running             0          7s

[root@k8s-m recreate]# kubectl  explain deploy.spec.strategy.rollingUpdate
KIND:     Deployment
VERSION:  extensions/v1beta1

RESOURCE: rollingUpdate <Object>

DESCRIPTION:
     Rolling update config params. Present only if DeploymentStrategyType =
     RollingUpdate.

     Spec to control the desired behavior of rolling update.

FIELDS:
   maxSurge    <string>
     The maximum number of pods that can be scheduled above the desired number
     of pods. Value can be an absolute number (ex: 5) or a percentage of desired
     pods (ex: 10%). This can not be 0 if MaxUnavailable is 0. Absolute number
     is calculated from percentage by rounding up. By default, a value of 1 is
     used. Example: when this is set to 30%, the new RC can be scaled up
     immediately when the rolling update starts, such that the total number of
     old and new pods do not exceed 130% of desired pods. Once old pods have
     been killed, new RC can be scaled up further, ensuring that total number of
     pods running at any time during the update is at most 130% of desired pods.

   maxUnavailable    <string>
     The maximum number of pods that can be unavailable during the update. Value
     can be an absolute number (ex: 5) or a percentage of desired pods (ex:
     10%). Absolute number is calculated from percentage by rounding down. This
     can not be 0 if MaxSurge is 0. By default, a fixed value of 1 is used.
     Example: when this is set to 30%, the old RC can be scaled down to 70% of
     desired pods immediately when the rolling update starts. Once new pods are
     ready, old RC can be scaled down further, followed by scaling up the new
     RC, ensuring that the total number of pods available at all times during
     the update is at least 70% of desired pods.

apiVersion: apps/v1
kind: Deployment
metadata:
  name: k8s-demo
  namespace: aspnetcore
  labels:
    name: k8s-demo
spec:
  replicas: 2
  selector:
    matchLabels:
      name: k8s-demo
  template:
    metadata:
      labels:
        name: k8s-demo
    spec:
      containers:
      - name: k8s-demo
        image: edisonsaonian/k8s-demo
        ports:
        - containerPort: 80
        imagePullPolicy: Always

---

kind: Service
apiVersion: v1
metadata:
  name: k8s-demo
  namespace: aspnetcore
spec:
  type: NodePort
  ports:
    - port: 80
      targetPort: 80
  selector:
    name: k8s-demo

kubectl create namespace aspnetcore // 创建一个命名空间“aspnetcore”

mkdir aspnetcore

cd aspnetcore/
vim deploy.yaml  //将上面的配置写入该文件中
kubectl create -f deploy.yaml

[root@m7-a2-15-43 aspnetcore]# kubectl get svc -n aspnetcore
NAME       TYPE       CLUSTER-IP       EXTERNAL-IP   PORT(S)       AGE
k8s-demo   NodePort   10.254.180.117   <none>        80:8671/TCP   4h55m

出处：http://www.cnblogs.com/runningsmallguo/

本文版权归作者和博客园共有，欢迎转载，但未经作者同意必须保留此段声明，且在文章页面明显位置给出原文链接。
