To display a notification,you must
have an icon in the notification
area. In certain cases,such as
Microsoft Communicator or battery
level,that icon will already be
present. In many other cases,however,
you will add an icon to the
notification area only as long as is
needed to show the notification.

由于我不想在通知区域添加任何图标,我想到的可能是“重用”现有的一个最常见的桌面上的图标.一个好的候选者可能是系统时钟.

我的问题是：

>我如何查找/枚举
NOTIFYICONDATA结构
系统时钟(AKA“日期和时间
属性“恢复时”？
>有没有更好的方法
完成这个(没有添加
一个图标)？

它是自我意识的,这意味着发送给它的通知将排队(您可以控制它).为此,我提供了一个IQueryContinue实现.该项目是C语言,是开源的,帮助自己.

以下是它的内容：

HRESULT NotifyUser(const NOTIFU_ParaM& params,IQueryContinue *querycontinue,IUserNotificationCallback *notifcallback)
 {
    HRESULT result = E_FAIL;

    IUserNotification *un = 0;
    IUserNotification2 *deux = 0; //french pun : "un" above stands for UserNotification but it also means 1 in french. deux means 2.

    //First try with the Vista/Windows 7 interface
    //(unless /xp flag is specified
    if (!params.mForceXP)
       result = CoCreateInstance(CLSID_UserNotification,CLSCTX_ALL,IID_IUserNotification2,(void**)&deux);

    //Fall back to Windows XP
    if (!SUCCEEDED(result))
    {
       TRACE(eWARN,L"Using Windows XP interface IUserNotification\n");
       result = CoCreateInstance(CLSID_UserNotification,IID_IUserNotification,(void**)&un);
    }
    else
    {
       TRACE(eINFO,L"Using Vista interface IUserNotification2\n");
       un = (IUserNotification*)deux; //Rather ugly cast saves some code...
    }

    if (SUCCEEDED(result))
    {
       const std::basic_string<TCHAR> crlf_text(L"\\n");
       const std::basic_string<TCHAR> crlf(L"\n");
       std::basic_string<TCHAR> text(params.mText);
       size_t look = 0;
       size_t found;

       //Replace \n with actual CRLF pair
       while ((found = text.find(crlf_text,look)) != std::string::npos)
       {
          text.replace(found,crlf_text.size(),crlf);
          look = found+1;
       }

       result = un->SetIconInfo(params.mIcon,params.mTitle.c_str());
       result = un->SetBalloonInfo(params.mTitle.c_str(),text.c_str(),params.mType);

       //Looks like it controls what happends when the X button is
       //clicked on
       result = un->SetBalloonRetry(0,250,0);

       if (deux)
          result = deux->Show(querycontinue,notifcallback);
       else
          result = un->Show(querycontinue,250);

       un->Release();
    }

    return result;
 }

#include "stdafx.h"
    #include "shellapi.h"

    LRESULT CALLBACK WndProc(HWND hWnd,UINT message,WParaM wParam,LParaM lParam);

    int APIENTRY _tWinMain(HINSTANCE hInstance,HINSTANCE hPrevInstance,LPTSTR lpCmdLine,int nCmdshow)
    {
        MSG msg;

        WNDCLASS wc;
        memset(&wc,sizeof(wc));
        wc.lpfnWndProc = WndProc;
        wc.hInstance = hInstance;
        wc.hCursor = LoadCursor(NULL,IDC_ARROW);
        wc.hbrBackground = (HBrush)(COLOR_WINDOW+1);
        wc.lpszClassName = "sysTrayTest";
        RegisterClass(&wc);

        HWND hWnd = CreateWindow("sysTrayTest","",WS_OVERLAPPEDWINDOW,CW_USEDEFAULT,500,NULL,hInstance,NULL);
        if (hWnd)
        {
            ShowWindow(hWnd,nCmdshow);
            while (GetMessage(&msg,0))
            {
                TranslateMessage(&msg);
                dispatchMessage(&msg);
            }
        }

        return 0;
    }

    LRESULT CALLBACK WndProc(HWND hWnd,LParaM lParam)
    {
        switch (message)
        {
            case WM_DESTROY:
            {
                NOTIFYICONDATA nid;
                memset(&nid,sizeof(NOTIFYICONDATA));
                nid.cbSize = sizeof(NOTIFYICONDATA);
                nid.hWnd = hWnd;
                nid.uID = 1;
                Shell_NotifyIcon(NIM_DELETE,&nid);

                PostQuitMessage(0);
            }
            break;

            case WM_CREATE:
            {
                NOTIFYICONDATA nid;
                memset(&nid,sizeof(NOTIFYICONDATA));
                nid.cbSize = sizeof(NOTIFYICONDATA);
                nid.hWnd = hWnd;
                nid.uID = 1;
                nid.uFlags = NIF_ICON | NIF_MESSAGE | NIF_TIP;
                nid.uCallbackMessage = WM_USER + 200;
                nid.hIcon = LoadIcon(NULL,IDI_informatION);
                lstrcpy (nid.szTip,"Test Tip");
                Shell_NotifyIcon(NIM_ADD,&nid);
            }
            break;

            case WM_LBUTTONDOWN:
            {
                NOTIFYICONDATA nid;
                memset(&nid,sizeof(NOTIFYICONDATA));
                nid.cbSize = sizeof(NOTIFYICONDATA);
                nid.hWnd = hWnd;
                nid.uID = 1;
                nid.uFlags = NIF_INFO;
                lstrcpy(nid.szInfo,"Test balloon tip");
                lstrcpy(nid.szInfoTitle,"Test Title");
                nid.dwInfoFlags = NIIF_INFO;
                nid.uTimeout = 15000;
                Shell_NotifyIcon(NIM_MODIFY,&nid);
            }
            break;

            default:
                return DefWindowProc(hWnd,message,wParam,lParam);
        }
        return 0;
    }

解决方法

1 private void notifyIcon1_MouseDoubleClick(object sender, MouseEventArgs e)
2 {
3     this.Show();//显示界面
4     this.WindowState = FormWindowState.Normal;
5     this.ShowInTaskbar = true;//显示在任务栏
6 }

1 private void FormMain_Resize(object sender, EventArgs e)
2 {
3     if (this.WindowState == FormWindowState.Minimized)
4     {
5         this.Hide();
6         this.ShowInTaskbar = false;
7     }
8 }

public class InnerClass: Form
 {
  private Shell_NotifyIconEx servicesClass = null; // 接受主CLASS 的实例句柄
  internal InnerClass(Shell_NotifyIconEx _servicesClass)
  {
   servicesClass = _servicesClass;
  }

  private const int WM_LBUTTONDOWN = 0x0201; // 左键
  private const int WM_RBUTTONDOWN = 0x204; // 右键
  private const int WM_MBUTTONDOWN = 0x207; // 中键

  [DllImport("user32.dll", EntryPoint = "TrackPopupMenu")]
  private static extern int TrackPopupMenu( // c# 和vb.net 好象没有了随地popup 了，只要请它老人家出马了
   IntPtr hMenu,
   int wFlags,
   int x,
   int y,
   int nReserved,
   IntPtr hwnd,
   ref RECT lprc
   );

  [StructLayout(LayoutKind.Sequential)]
  private struct RECT
  { // 上面那位用的结构，表示前弹出菜单可用的一个范围大小（一般是全屏幕都让它用，留着搞游戏或视频对话之类的朋友指定菜单可用的范围）
   internal int Left;
   internal int Top;
   internal int Right;
   internal int Bottom;
  }

  protected override void WndProc(ref Message msg)
  {
   if (msg.Msg == servicesClass.WM_NOTIFY_TRAY)
   { // 如果消息相符
    if ((int)msg.WParam == servicesClass.uID)
    { // 并且消息的WParam 相符
     MouseButtons mb =MouseButtons.None;
     if ((int)msg.LParam == WM_LBUTTONDOWN)
     { //如果点击的是左键
      mb =MouseButtons.Left;
     }
     else if ((int)msg.LParam == WM_MBUTTONDOWN)
     { //中键
      mb =MouseButtons.Middle;
     }
     else if ((int)msg.LParam == WM_RBUTTONDOWN)
     { //右键
      if (servicesClass.contextMenuHwnd != IntPtr.Zero)
      { //如果有定义过菜单关联
       RECT r = new RECT();
       r.Left = Screen.PrimaryScreen.WorkingArea.Left;
       r.Right =Screen.PrimaryScreen.WorkingArea.Right;
       r.Top =Screen.PrimaryScreen.WorkingArea.Top;
       r.Bottom =Screen.PrimaryScreen.WorkingArea.Right;

       TrackPopupMenu(
        servicesClass.contextMenuHwnd,
        2,
       Cursor.Position.X,
       Cursor.Position.Y,
        0,
        servicesClass.formHwnd,
        ref r
        );
      }
      else
      { //如果没有定义过菜单关联
       mb =MouseButtons.Right;
      }
     }

     if (mb !=MouseButtons.None && servicesClass._delegateOfCallBack != null)
     {
      servicesClass._delegateOfCallBack(mb); // 执行回调
      return;
     }
    }
   }

   base.WndProc(ref msg);
  }
 }

public class Shell_NotifyIconEx
 {
  /// <summary>
  /// ArLi, last fix: 2003.9.12, reference: ArLi.CommonPrj Lib @ http://zpcity.com/arli/
  /// </summary>
  public static readonly System.Version myVersion = new System.Version(1, 2); //版本声明

  private readonly InnerClass formTmp = null; // 这个很重要，不能放在构造里，因为它必须和此实例同等生存期才不会被中止消息循环
  private readonly IntPtr formTmpHwnd = IntPtr.Zero; // 这是上一行的句柄
  private readonly bool VersionOk = false; // 这是一个由VersionPass 返回的属性，它允许开发者检测当前机子的Shell32.dll(可能在win95 或未知平台上版本) 合适此组，不符则用.net 自己的notifyicon
  private bool forgetDelNotifyBox = false; // 这是一个私有标志，它允许开发者在程序退出时忘记调用DelNotifyBox 来清除图标时会自动在析构里清掉它。

  internal IntPtr formHwnd = IntPtr.Zero; // 这是调用此组件的主窗口句柄（当前实例有效，可多个icon 不冲突）
  internal IntPtr contextMenuHwnd = IntPtr.Zero; // 这是菜单的句柄（当前实例有效，可多个icon 不冲突）

  internal delegate void delegateOfCallBack(System.Windows.Forms.MouseButtons mb);
  internal delegateOfCallBack _delegateOfCallBack = null;

  public Shell_NotifyIconEx() // 构造
  {
   WM_NOTIFY_TRAY += 1; // 消息ID +1，避免多个ICON 消息处理冲突
   uID += 1; // 同上
   formTmp = new InnerClass(this); // 新实例一个消息循环
   formTmpHwnd = formTmp.Handle; // 新实例句柄
   VersionOk = this.GetShell32VersionInfo() >= 5; // 版本是否合适，此组件由于重点在气泡提示，它要求Shell32.dll 5.0(ie 5.0) 以上
  }

  ~Shell_NotifyIconEx()
  { // 析构
   if (forgetDelNotifyBox) this.DelNotifyBox(); //如果开发者忘记则清理icon
  }

  #region API_Consts
  internal readonly int WM_NOTIFY_TRAY = 0x0400 + 2001; //readonly 表示只在构造可付值
  internal readonly int uID = 5000;

  // 常数定义，有VC 的可以参见 shellapi.h
  private const int NIIF_NONE = 0x00;
  private const int NIIF_INFO = 0x01;
  private const int NIIF_WARNING = 0x02;
  private const int NIIF_ERROR = 0x03;

  private const int NIF_MESSAGE = 0x01;
  private const int NIF_ICON = 0x02;
  private const int NIF_TIP = 0x04;
  private const int NIF_STATE = 0x08;
  private const int NIF_INFO = 0x10;

  private const int NIM_ADD = 0x00;
  private const int NIM_MODIFY = 0x01;
  private const int NIM_DELETE = 0x02;
  private const int NIM_SETFOCUS = 0x03;
  private const int NIM_SETVERSION = 0x04;

  private const int NIS_HIDDEN = 0x01;
  private const int NIS_SHAREDICON = 0x02;

  private const int NOTIFYICON_OLDVERSION = 0x00;
  private const int NOTIFYICON_VERSION = 0x03;

  [DllImport("shell32.dll", EntryPoint = "Shell_NotifyIcon")]
  private static extern bool Shell_NotifyIcon( // 这位是主角
   int dwMessage,
   ref NOTIFYICONDATA lpData
  );

  /// <summary>
  /// 此API 的作用是当 this.focus() 无效时可以考虑使用，效果很好
  /// </summary>
  /// <param name="hwnd">this.Handle, 当前窗体句柄</param>
  [DllImport("user32.dll", EntryPoint = "SetForegroundWindow")]
  public static extern int SetForegroundWindow(
   IntPtr hwnd
  );

  [StructLayout(LayoutKind.Sequential)]
  private struct NOTIFYICONDATA
  { // 主角用的结构
   internal int cbSize;
   internal IntPtr hwnd;
   internal int uID;
   internal int uFlags;
   internal int uCallbackMessage;
   internal IntPtr hIcon;
   [MarshalAs(UnmanagedType.ByValTStr, SizeConst = 0x80)]
   internal string szTip;
   internal int dwState; // 这里往下几个是 5.0 的精华
   internal int dwStateMask;
   [MarshalAs(UnmanagedType.ByValTStr, SizeConst = 0xFF)]
   internal string szInfo;
   internal int uTimeoutAndVersion;
   [MarshalAs(UnmanagedType.ByValTStr, SizeConst = 0x40)]
   internal string szInfoTitle;
   internal int dwInfoFlags;
  }
  #endregion

  /// <summary>
  /// 建一个结构
  /// </summary>
  private NOTIFYICONDATA GetNOTIFYICONDATA(IntPtr iconHwnd, string sTip, string boxTitle, string boxText)
  {
   NOTIFYICONDATA nData = new NOTIFYICONDATA();

   nData.cbSize = System.Runtime.InteropServices.Marshal.SizeOf(nData); // 结构的大小
   nData.hwnd = formTmpHwnd; // 处理消息循环的窗体句柄，可以移成主窗体
   nData.uID = uID; // 消息的 WParam，回调时用
   nData.uFlags = NIF_MESSAGE | NIF_ICON | NIF_TIP | NIF_INFO; // 标志，表示由消息、图标、提示、信息组成
   nData.uCallbackMessage = WM_NOTIFY_TRAY; // 消息ID，回调用
   nData.hIcon = iconHwnd; // 图标的句柄，有兴趣的话可以定时改变它变成动画ICON
   nData.uTimeoutAndVersion = 10 * 1000 | NOTIFYICON_VERSION; // 提示的超时值（几秒后自动消失）和版本
   nData.dwInfoFlags = NIIF_INFO; // 类型标志，有INFO、WARNING、ERROR，更改此值将影响气泡提示框的图标类型

   nData.szTip = sTip; // 图标的提示信息
   nData.szInfoTitle = boxTitle; // 气泡提示框的标题
   nData.szInfo = boxText; // 气泡提示框的提示内容

   return nData; // 这个嘛。。。
  }

  private int GetShell32VersionInfo()
  { // 返回shell32 的版本
   FileInfo fi = new FileInfo(Path.Combine(System.Environment.SystemDirectory, "shell32.dll")); //将来的平台shell32 放哪目前不得而知，碰到再改
   if (fi.Exists)
   {
    FileVersionInfo theVersion = FileVersionInfo.GetVersionInfo(fi.FullName);
    int i = theVersion.FileVersion.IndexOf(''.'');
    if (i > 0)
    {
     try
     {
      return int.Parse(theVersion.FileVersion.Substring(0, i));
     }
     catch { }
    }
   }
   return 0;
  }

  /// <summary>
  /// 加一个新图标
  /// </summary>
  /// <param name="iconHwnd">图标句柄</param>
  /// <param name="sTip">提示, 5.0 最大: 128 char</param>
  /// <param name="boxTitle">气泡标题, 最大: 64 char</param>
  /// <param name="boxText">气泡内容, 最大: 256 char</param>
  /// <returns>成功、失败或错误(-1)</returns>
  public int AddNotifyBox(IntPtr iconHwnd, string sTip, string boxTitle, string boxText)
  {
   if (!this.VersionOk) return -1;

   NOTIFYICONDATA nData = GetNOTIFYICONDATA(iconHwnd, sTip, boxTitle, boxText);
   if (Shell_NotifyIcon(NIM_ADD, ref nData))
   {
    this.forgetDelNotifyBox = true;
    return 1;
   }
   else
   {
    return 0;
   }
  }

  /// <summary>
  /// 和add 差不多，不重复了
  /// </summary>
  public int DelNotifyBox()
  {
   if (!this.VersionOk) return -1;

   NOTIFYICONDATA nData = GetNOTIFYICONDATA(IntPtr.Zero, null, null, null);
   if (Shell_NotifyIcon(NIM_DELETE, ref nData))
   {
    this.forgetDelNotifyBox = false;
    return 1;
   }
   else
   {
    return 0;
   }
  }

  public int ModiNotifyBox(IntPtr iconHwnd, string sTip, string boxTitle, string boxText)
  {
   if (!this.VersionOk) return -1;

   NOTIFYICONDATA nData = GetNOTIFYICONDATA(iconHwnd, sTip, boxTitle, boxText);
   return Shell_NotifyIcon(NIM_MODIFY, ref nData) ? 1 : 0;
  }

  #region Optional Module //这里是可选方法
  /// <summary>
  /// 连接一个已存在的 contextMenu
  /// </summary>
  /// <param name="_formHwnd">窗体句柄，用来处理菜单的消息</param>
  /// <param name="_contextMenuHwnd">菜单的句柄</param>
  public void ConnectMyMenu(IntPtr _formHwnd, IntPtr _contextMenuHwnd)
  {
   formHwnd = _formHwnd;
   contextMenuHwnd = _contextMenuHwnd;
  }

  /// <summary>
  /// 立即清理掉图标、委托和formtmp 资源（好象没什么资源，考虑到可能二次开发挂接就开了这个东东）
  /// </summary>
  public void Dispose()
  {
   _delegateOfCallBack = null;
   this.formTmp.Dispose();
  }

  /// <summary>
  /// 版本适合
  /// </summary>
  public bool VersionPass
  {
   get
   {
    return this.VersionOk;
   }
  }
  #endregion
 }

 private void button2_Click (object sender, System.EventArgs e) {
  Shell_NotifyIconEx ().AddNotifyBox (this.Icon.Handle, this.Text, "这是标题", "单击这里开始，我将带你畅游API 世界");
 }

private void GetPoc1 (MouseButtons mb) { // 回调处理
 if (mb == MouseButtons.Left) {
  MessageBox.Show ("来自菜单1");
 }
}
privateShell_NotifyIconEx o1 = newShell_NotifyIconEx (); //这个放外面是用在 o.DelNotifyBox
private void button1_Click (object sender, System.EventArgs e) {
 o1.AddNotifyBox (this.Icon.Handle, this.Text, "菜单1", "单击这里开始，我将带你畅游API 世界");
 o1.ConnectMyMenu (this.Handle, this.contextMenu1.Handle); // 挂上菜单，可选
 o1._delegateOfCallBack = newShell_NotifyIconEx.delegateOfCallBack (GetPoc1); //定义回调
}

private void GetPoc1(MouseButtons mb) { // 回调处理
 if (mb == MouseButtons.Left) {
 MessageBox.Show("来自菜单1");
 }
 }
 private Shell_NotifyIconEx o1 = new Shell_NotifyIconEx(); //这个放外面是用在 o.DelNotifyBox
 private void button1_Click(object sender, System.EventArgs e) {
 o1.AddNotifyBox(this.Icon.Handle,this.Text,"菜单1","单击这里开始，我将带你畅游API 世界");
 o1.ConnectMyMenu(this.Handle,this.contextMenu1.Handle); // 挂上菜单，可选
 o1._delegateOfCallBack = new Shell_NotifyIconEx.delegateOfCallBack(GetPoc1); //定义回调
 }
 private void GetPoc2(MouseButtons mb) {
 if (mb == MouseButtons.Left) {
 MessageBox.Show("来自菜单2");
 }
 }
 private Shell_NotifyIconEx o2 = new Shell_NotifyIconEx(); //第二个nofityicon 和上面一样
 private void button2_Click(object sender, System.EventArgs e) {
 o2.AddNotifyBox(this.Icon.Handle,this.Text,"菜单2","单击这里开始，我将带你畅游API 世界");
 o2.ConnectMyMenu(this.Handle,this.contextMenu2.Handle);
 o2._delegateOfCallBack = new Shell_NotifyIconEx.delegateOfCallBack(GetPoc2);
 }

• C# winform打印excel的方法
• C# winform中窗口关闭按钮的隐藏与禁用详解
• C# WinForm-Timer控件的使用
• C# Winform实现波浪滚动效果
• C# Winform按钮中图片实现左图右字的效果实例
• C# Winform中如何绘制动画示例详解
• C# Winform调用百度接口实现人脸识别教程(附源码)
• C# Winform程序实现防止多开的方法总结【亲测】
• c# winform异步不卡界面的实现方法
• c# winform 解决PictureBox 无法打印全部图片的问题
