The Smart Field Service Prototype powered by SAP FSM and Wechat

In this blog I will introduce a prototype regarding a Smart Field Service prototype recently developed by our team. The aim of this prototype development is to give our local partners a demonstration about how SAP FSM is flexible enough to integrate with popular mobile application framework to achieve a more modern user experience.

SAP FSM is named as VISIONARIES in Gartner Magic Quadrant for Field Service Management.

See the report in Aprial 2019.

And till 2019 Q1, Wechat has more than 1.1 billions active users per month. The Wechat users finds out that more and more of activities in their daily life could be achieved within Wechat itself by “subscription account” and “mini program”, without installing any additional mobile application. Wechat has almost become a sort of “mobile application platform” in de facto standard.

So it would be very promising if both could be combined to make customer life easier.

We design such a scenario: suppose a customer has bought an equipment from a given company, and need to finish the equipment installation by a technian some days later.

Traditional way for field service reservation

That customer has to call equipment selling company, discuss with the service agent via the phone, schedule a technian and determine the field service date and time. All of such discussion has to be performed online via phone.

And for the service agent who has picked up the call, he/she has to manually create every record in SAP FSM, such as service calls and activities. It’s time consuming with poor productivity.

Innovation way for field service reservation

(1) The customers can directly make reservation themselves via self service provided in Wechat. No additional application required.
(2) The self service in Wechat is developed with a frontend web application and a backend proxy server leveraging SAP FSM nodejs SDK. When customers choose the appropriate date time, specify a technician and confirm the reservation, the request is sent to the backend proxy server, which then calls SAP FSM Restful API via nodejs SDK, to create service calls and activities automatically.

In this way, no human service agent is needed any more.

Below is more detail about this demo scenario.

(1) After the customer has bought the equipment, he/she subscribed the official subscription account of the equipment selling company, in our demo it’s “SAPCX数字创新空间”.

Once done, the menus provided by the subscription account is available. Click “预约(Reserve)” to start book a time via self-service way.

Then the web application developed by our team is displayed in Wechat.

“预约地址”：the address of customer who currently uses Wechat for booking, which is automatically filled by GPS API call. Manual change is still available.

“联系电话”：customer mobile phone number.

“上门时间”: the actual time that customer would like to book the field service.

Once service time is determined, the web application will fire a query request to SAP FSM to fetch technicians list who are available for that very booked time.

The available technicians are rendered in Wechat via list format, with each technician’s name, title, employment length, user ranking etc. Then the customer can choose a technician based on these information.

Once the customer confirms the reservation, our proxy server will call SAP FSM Restful API to create corresponding service calls and activity in the system:

Here below is the created service call in SAP FSM triggered from W echat:

Here below is the created activity in SAP FSM:

In order to let customers can check the appointment anytime after this successful booking, once our web application receives the response from SAP FSM API call, we will push a “reservation confirmation” to Wechat:

Click this notification and customers can review reservation detail in Wechat:

Now a day later, it’s time for the selected technician to travel to the customer site. Once the technician starts, the customer will receive a “real-time position sharing” initiated by the technician in customer’s mobile phone:

With the support of location tracking, the customer can have a rough estimation when the technician arrives.

Now let’s switch to technician perspective for the time being. Once the dispatcher employee presses the “Release Assignments” button on the installation task created by SAP FSM API call in the dispatching dashboard,

The technician will receive a notification message from the SAP FSM application in his phone:

Click the FSM mobile application and the technician can see what exactly should be installed for the current field service:

where do two items (installation service and accessory list) in task view above come from?

Two templates are created in advanced in SAP FSM, tile “Smartforms and Feedback”:

The binding relationship between the activity which the technician see in the mobile and the two work items is achieved by an API call to assign the two templates into the created activity in the runtime.

Once technician has finished installation service, in our prototype, a bill will be pushed to customer’s Wechat application containing detailed price:

The customer can open the bill detail, review it and press the blue button “支付账单(pay the bill)” in the bottom.

Wechat Pay is one of most popular payment method currently used in China. We simply bind a credit card in Wechat and then can perform payment directly using Wechat.

Once the customer pays the bill, a user survey will be sent to the Wechat to collect feedback about this field service experience.

We have developed a web page leveraging Qualtrics survey API. The survey result will be sent back by API to generate corresponding Qualtrics Response for further analysis.

In summary, using our prototype, customers can now perform all necessary steps for a typical field service process purely in Wechat. Neither phone call nor other application is needed. This prototype demonstrates how flexible and powerful SAP FSM Restful API in regard to integration with third party software and how Wechat can be involved to bring an enhanced user experience of SAP FSM.

I have uploaded a video in youtube: https://youtu.be/tscSPtPlPqE

Hope it can inspire you a little bit.

要获取更多Jerry的原创文章，请关注公众号"汪子熙":

本文分享 CSDN - 汪子熙。
如有侵权，请联系 support@oschina.cn 删除。
本文参与“OSC源创计划”，欢迎正在阅读的你也加入，一起分享。

01. walkthrough 1 and 2 - data-sap-ui-libs="sap.ui.commons,sap.ui.table"

Created by Wang, Jerry, last modified on Nov 02, 2015

本文分享 CSDN - 汪子熙。
如有侵权，请联系 support@oschina.cn 删除。
本文参与“OSC源创计划”，欢迎正在阅读的你也加入，一起分享。

Array.prototype.keys()、Array.prototype.values()和Array.prototype.entries()

Array.prototype.keys()

keys() 方法返回一个包含数组中每个索引键的Array Iterator对象。

var arr = ["a", , "c"];
var sparseKeys = Object.keys(arr);
var denseKeys = [...arr.keys()];
console.log(sparseKeys); // [''0'', ''2'']
console.log(denseKeys);  // [0, 1, 2]

let arr = [''w'', ''y'', ''k'', ''o'', ''p''];
let eArr = arr.values();
// 您的浏览器必须支持 for..of 循环
// 以及 let —— 将变量作用域限定在 for 循环中
for (let letter of eArr) {
  console.log(letter);
}

let arr = [''w'', ''y'', ''k'', ''o'', ''p''];
let eArr = arr.values();
console.log(eArr.next().value); // w
console.log(eArr.next().value); // y
console.log(eArr.next().value); // k
console.log(eArr.next().value); // o
console.log(eArr.next().value); // p

var arr = ["a", "b", "c"];
var iterator = arr.entries();
// undefined

for (let e of iterator) {
    console.log(e);
}

// [0, "a"]
// [1, "b"]
// [2, "c"]

Comments on task “Smart Service II: Wrap up and make it ready for Demo“

From: Robin

Sent: Tuesday, November 26, 2019 3:59 PM

To: Innovation Space

Subject: Comments on task “Smart Service II: Wrap up and make it ready for Demo”

Meeting Notes from 2019-11-26

1,服务类型，去掉预约，
2，输入框服务类型样式与上门时间一致
3，所选列表的技工中文名字，正规
4，确定按钮尺寸及字体大小调整，按照设计图
5，技工和客户名字(曾海瑞)，修改，与设计文档保持一致
6，微信预约时间和FSM时间保持一致，算下时间。
7，订单详情改为预约详情，标题改变，
8，标题服务账单改为服务详情
9，推送消息的·头像补全，包括地理，账单等头像
10，地图的标记换成头像
11，取消预约按钮尺寸调整
12，预约内容标题，机械臂
13，打印机替换为机械臂零件
14，清单添加”安装服务”一个新单，还有”可选配件”
15,清单title修改，price该中文？
16，产品信息—》配件信息，费用—》安装费用
17，账单样式调整

本文分享 CSDN - 汪子熙。
如有侵权，请联系 support@oschina.cn 删除。
本文参与“OSC源创计划”，欢迎正在阅读的你也加入，一起分享。

Creating a machine learning-powered REST API with Amazon API Gateway mapping templates and Amazon...

https://amazonaws-china.com/blogs/machine-learning/creating-a-machine-learning-powered-rest-api-with-amazon-api-gateway-mapping-templates-and-amazon-sagemaker/

Amazon SageMaker enables organizations to build, train, and deploy machine learning models. Consumer-facing organizations can use it to enrich their customers’ experiences, for example, by making personalized product recommendations, or by automatically tailoring application behavior based on customers’ observed preferences. When building such applications, one key architectural consideration is how to make the runtime inference endpoint available to client software running on consumer devices. Typically, the endpoint is fronted as part of a broader API, based on a conventional web-friendly approach, such as REST, which offers a complete set of application functions to client software.

Amazon API Gateway is a fully managed service that makes it easy for developers to create, publish, maintain, monitor, and secure APIs at any scale. API Gateway can be used to present an external-facing, single point of entry for Amazon SageMaker endpoints, with the following benefits:

• Insulates clients from the specifics of the underlying implementation by translating between a client-facing REST API and the underlying Amazon SageMaker runtime inference API
• Supports authentication and authorization of client requests
• Manages client requests through the use of throttling, rate-limiting, and quota management
• Uses firewall features as provided by AWS WAF
• Enables cost savings and operational optimization through caching and request validation
• Makes it easier to create canary deployments to introduce model changes safely

In this post, I show how API Gateway can be used to front an Amazon SageMaker inference endpoint as (part of) a REST API, by making use of an API Gateway feature called mapping templates. This feature makes it possible for the REST API to be integrated directly with an Amazon SageMaker runtime endpoint, thereby avoiding the use of any intermediate compute resource (such as AWS Lambda or Amazon ECS containers) to invoke the endpoint. The result is a solution that is simpler, faster, and cheaper to run.

This direct integration approach is especially useful for consumer applications that exhibit high traffic volumes at peak demand times. Amazon SageMaker supports automatic scaling for inference endpoints, and API Gateway automatically scales to match demand, ensuring that there is always sufficient capacity to process incoming requests, and that you only pay for what you use.

Note: This post focuses on direct integration with Amazon SageMaker, but you can also use mapping templates in combination with an intermediate compute layer (based, for example, on AWS Lambda), in which case you can use them to reduce load on the compute layer by reshaping payloads at the gateway itself.

I demonstrate the approach using a console-based walk through, starting with deployment of an Amazon SageMaker model endpoint, and then stepping through the creation of an Amazon API Gateway integration with this endpoint.

Overview of solution

For illustration purposes, this post employs a use case in which a TV app requests ratings predictions for a list of movies. Whenever the app displays a page of movies, it should display them so that movies with a higher ratings prediction are more prominent on the page. In this example, every user and movie can be identified by a numeric ID, and predicted ratings are on a scale of 1 to 5, with a higher rating indicating a stronger likelihood that the user will like a particular movie.

Architecture

The following diagram summarizes the architecture, key components, and interactions in the solution. End-users interact with a client application (using a web browser or mobile device) that sends a REST-style request to an API Gateway endpoint. API Gateway maps this to the request format required by the Amazon SageMaker endpoint, and invokes the endpoint to obtain an inference from the model. API Gateway subsequently receives the response from the Amazon SageMaker endpoint and maps it to a response that is sent back to the client.

Request and response formats

The solution incorporates a REST API that supports a single resource (predicted-ratings) and a GET method. The request takes the form:

GET /<api-path>/predicted-ratings/{user_id}?items=id1,id2,…,idn&

where the path parameter user_id represents the user for which ratings are required, and the query string parameter items contains a comma-separated list of item identifiers.

If the request is processed successfully, the returned HTTP response has response code 200, and the body is a JSON object containing a list of predicted ratings for the specified items as follows:

{
  "ratings": [
    rating_1,
    rating_2,
    …,
    rating_n
  ]
}

For example, you could enter the following request:

% curl "https://<api-path>/predicted-ratings/321?items=101,131,162&"

This would return with a response similar to the below:

{
  "ratings": [
    3.527499437332153,
    3.951640844345093,
    3.658416271209717
  ]
}

Amazon SageMaker model input and output formats

The rating predictor solution is based on a sample model that comes supplied with Amazon SageMaker, specifically: object2vec_movie_recommendation.ipynb. This model inference endpoint supports a POST method, and expects the request body to contain a JSON payload as follows:

{
  "instances": [
    {"in0": [863], "in1": [882]},
    {"in0": [278], "in1": [311]},
    {"in0": [705], "in1": [578]},
    …
  ]
}

where in0 represents a user ID, and in1 represents a movie ID.

The model inference returns the following output:

{
  "predictions": [
    {"scores": [3.047305107116699]},
    {"scores": [3.58427882194519]},
    {"scores": [4.356469631195068]},
    …
  ]
}

You can use mapping templates to map the GET request format received by the REST API to the POST input format expected by the Amazon SageMaker model endpoint, and conversely map the model output format to the response format required by the REST API.

Amazon API Gateway method integration

When you use API Gateway to create a REST API, you need to define the following configuration models for each API method:

• Method request – Defines the data model for the REST request format, and specifies validation and authorization checks to be performed on the received REST request.
• Integration request – Details how the REST request and associated parameters map to the format expected by the backend service endpoint (which in this example is an Amazon SageMaker inference endpoint).
• Integration response – Details how the response received from the backend service (including errors) map to the response format expected by API Gateway.
• Method Response – Defines the data model and response format expected by the REST API.

The following diagram depicts the processing flow, and shows how an example request and response are transformed at each stage.

Mapping Templates

As part of the integration request and response configurations, the solution defines mapping templates using the Apache Velocity Template Language (VTL). VTL is a templating language that was originally designed for web development, but can also be used as a data format transformation tool to convert from one JSON format to another. With mapping templates, you can use VTL templates to convert from the REST request format to the model input format, and to convert the model output to the REST response format.

Walkthrough steps

The walkthrough contains the following key steps:

1. Build and deploy an Amazon SageMaker model
2. Test the Amazon SageMaker model endpoint using the AWS CLI
3. Create an IAM execution role for the REST API
4. Build an API Gateway endpoint for the REST API
5. Create a mapping template for request integration
6. Create a mapping template for response integration
7. Deploy and test the API Gateway endpoint

Prerequisites

To follow this walkthrough, you need to meet the following prerequisites:

• Access to an AWS account – You need sufficient IAM permissions to work with IAM roles, Amazon SageMaker, Amazon S3, and API Gateway.
• AWS CLI – Install the latest version.
• Curl utility – Use version 7.52 onwards.

Step 1: Building and deploying the Amazon SageMaker model

For this step, you need an S3 bucket to store the model data. You can use an existing bucket or create a new one. Record the name of your bucket as you shall need it later.

Create your model using an Amazon SageMaker Notebook instance. Complete the following steps:

1. Log in to your AWS account using the AWS Management Console.
2. On the Amazon SageMaker dashboard, under Notebook Instances, choose Create Notebook Instance.
3. Under Notebook instance settings, specify a name for your notebook.

For this example, you can set the instance type to ml.t2.medium, which is the most cost-effective option. In practice, you would select the instance type based on the size of the dataset and the nature of the data transformation.

1. Under Permissions and Encryption, set the IAM role to Create a new role.
2. Ensure that S3 buckets you specify is selected, specify the bucket name for your bucket, and select Create role.
3. Leave the remaining settings with the default value.
4. Choose Create notebook instance.

It takes a few minutes to create your instance. When the status changes from Pending to InService, your notebook instance is ready to use.

1. Under Actions, choose Open JupyterLab.

A new browser tab opens for your Jupyter notebook.

1. From the left navigation bar, choose the icon for Amazon SageMaker sample notebooks (hover over the icon to see the label).
2. From the list of sample notebooks, select object2vec_movie_recommendation.ipynb. as shown below:



The sample notebook you opened is read-only, so you need to create a writeable copy.

1. Choose Create a Copy at the top right of the pane.
2. When prompted to Select Kernel use conda_python3.

You are now ready to build and train the model in your notebook. This notebook creates two model inference endpoints (one for ratings prediction, and one for recommendations). You only need the first one, so you do not need to execute all the cells in the notebook.

Before executing any cells, complete the following steps:

1. In your notebook, scroll down to the section Model training and inference (just over half-way down the notebook). In the first cell (labeled Define S3 bucket that hosts data and model, and upload data to S3), set the bucket name to your choice of S3 bucket as identified earlier.


2. Starting from the top, use your notebook to execute all cells in order until you get to just before the Recommendation task section (which is about three-quarters of the way down the notebook).

You can either do this by stepping through one cell at a time, or by selecting the first cell in the Recommendation task section and then, under Run, choose Run All Above Selected Cell (see below).

Model training and deployment takes approximately 10 minutes. When it is complete, proceed with the following steps:

1. On the Amazon SageMaker console, under Inference, choose Endpoints.
2. Verify that you can see the runtime endpoint.
3. Record the endpoint name and ARN as you will need these later.

Step 2: Testing the Amazon SageMaker model endpoint using the AWS CLI

You can test the inference endpoint using the AWS CLI as follows:

aws sagemaker-runtime invoke-endpoint \
  --endpoint-name <endpoint-name> \
  --body ''{"instances": [{"in0":[863],"in1":[882]}]}'' \
  --content-type application/json \
  --accept application/json \
  results

Note: the above assumes you are using a bash-compatible shell. If you are using the standard Windows command line, replace the outer single quotes with double quotes for the body parameter, and escape the double quotes characters within the JSON.

If your endpoint is working correctly, you should see a file called results that contains output similar to the following:

{"predictions":[{"scores":[2.433111906051636]}]}

Now that you have a working Amazon SageMaker endpoint, you can build a REST API in front of it.

Step 3: Creating an execution role for the REST API

Before you build the REST API, you need to create an execution role that gives your API the necessary permission to invoke your Amazon SageMaker endpoint. Complete the following steps:

1. On the IAM console, under Roles, choose Create Role.
2. For Select type of trusted entity, select AWS Service.
3. Choose the service API Gateway.
4. Choose Next until you reach the Review.

You can see that a policy has been included which allows API Gateway to push logs to CloudWatch.

1. Give your role a name, for example, APIGatewayAccessToSageMaker.
2. Choose Create Role.

You now need to add permissions so your role can invoke the Amazon SageMaker endpoint.

1. Use the role filter to find the role you just created.
2. Choose the role you created to see the role summary screen.
3. Choose Add Inline Policy.
4. On the Create Policy screen, select the service SageMaker and the action InvokeEndpoint.
5. For Resources, select Specific and enter the ARN for your Amazon SageMaker endpoint.
6. Choose Review Policy.
7. Give your policy a name, for example, SageMakerEndpointInvokeAccess.
8. Choose Create Policy.
9. On the role summary page, record the ARN for the role as you will need this later.

Step 4: Building an API Gateway endpoint

In this section, you build your REST API.

Creating an API

Complete the following steps:

1. On the API Gateway console, choose Create API.
2. Choose REST.
3. Choose New API.
4. Give your API a name, for example, RatingsPredictor.
5. For Endpoint Type, choose Regional.
6. Choose Create API.

Note: In a production system, you should consider whether you would benefit from the Edge Optimized option.

Creating a resource

1. In the Resources editor, from the Actions menu, choose CreateResource.
2. For Resource Name, enter predicted-ratings.
3. Ensure that the Resource Path field also contains predicted-ratings.
4. Choose Create Resource.

You should see the predicted-ratings resource appear in the navigation tree.

1. Choose the predicted-ratings resource you created.
2. From the Actions menu, choose Create Resource.
3. For Resource Path, enter {user_id}.
4. For Resource Name, enter user_id.
5. Choose Create Resource.

The resource navigation tree should now be similar to the following screenshot, and show /predicted-ratings/{user_id}.

Creating a GET method

The next step is to create a GET method on the resource path /predicted-ratings/{user_id} and integrate it with your Amazon SageMaker endpoint. Complete the following steps:

1. From the Actions menu, choose {user_id}.
2. Choose Create Method.
3. From the drop-down that appears under the {user_id} resource, select GET and confirm by clicking the tick mark.

The right-hand pane now displays a Setup screen. See the following screenshot.

1. For Request Integration type, choose AWS Service.
2. For AWS Region, enter your Region.
3. For AWS Service, choose SageMaker Runtime.
4. Leave AWS Subdomain blank.


5. For HTTP method, choose POST.
6. For Action Type, choose Use Path override.
7. For Path override, enter the Amazon SageMaker endpoint path using the format endpoints/<sagemaker-endpoint-name>/invocations.
8. For Execution role, enter the ARN of the role you created earlier.
9. For Content Handling, choose Passthrough.
10. Select Use Default Timeout.
11. Choose Save.

You have created a GET endpoint in the REST API, and mapped it to a POST endpoint. In the next step, you use mapping templates to map parameters passed in the GET request (from the path and query-string) into the right places in the POST request expected by the Amazon SageMaker endpoint.

Step 5: Create a mapping template for request integration

You should now see a Method Execution screen in the right-hand pane. See the following screenshot.

This contains a diagram showing how requests flow from your REST API to the Amazon SageMaker runtime and how responses flow back.

Creating a VTL mapping template

In this next step, create a VTL mapping template to convert GET requests received on the REST API to POST requests expected by the Amazon SageMaker runtime. Complete the following steps:

1. Choose Integration Request.
2. Expand the Mapping Templates.
3. Select Request Body Passthrough: Never.

You can safely ignore the warning because it disappears after you specify a mapping template.

1. Choose Add mapping template.
2. For Content-Type, specify application/json and click the tick box to confirm.

If you scroll down, you see a multi-line text entry field. This is where you add your VTL template.

1. Enter the following template:

   {
     "instances": [
   #set( $user_id = $input.params("user_id") )
   #set( $items = $input.params("items") )
   #foreach( $item in $items.split(",") )
       {"in0": [$user_id], "in1": [$item]}#if( $foreach.hasNext ),#end
       $esc.newline
   #end
     ]
   }

2. Choose Save.

The template defines what goes into the body of the POST request. The first two lines are copied into the request body exactly as specified. The third line uses a #set directive to extract and store the user_id path parameter in the variable $user_id. The fourth line extracts the query string parameter items and places it in the variable $items. This is stored as a single string containing a comma-separated list of items.

Lines 5-8 loop through all the items and generate the required JSON for each one. The template converts the string held in $items to an array using the string split() method, and iterates through this using a #foreach directive. A comma separator is inserted between JSON objects, with no comma after the last entry.

Testing the mapping

You can now test this mapping using the API Gateway built-in test harness. Complete the following steps:

1. Choose Method Execution.
2. Choose Test.
3. For Path parameter {user_id}, enter 321.
4. For Query Strings parameter, enter items=101,131,162&.
5. Choose Test.

If everything is working correctly, you should see response code 200, with a response body that contains a JSON object similar to the below:

{
  "predictions": [
    {"scores": [3.527499437332153]},
    {"scores": [3.951640844345093]},
    {"scores": [3.658416271209717]}
  ]
}

You can also scroll through the logs to verify the sequence of events. You should see something similar to the following:

<timestamp>: Endpoint request body after transformations: {
  "instances": [
    {"in0": [321], "in1": [101]},
    {"in0": [321], "in1": [131]},
    {"in0": [321], "in1": [162]}
  ]
}
<timestamp> : Sending request to https://runtime.sagemaker.eu-west-1.amazonaws.com/endpoints/recs/invocations
<timestamp> : Received response. Status: 200, Integration latency: 232 ms

This proves that the REST request converted successfully to the input format required by the model, and that the model runtime executed successfully. However, the returned response body is still not in the format stipulated for the REST API. By default, API Gateway sets up the response integration to pass the response through unaltered. In the next step, you add a second mapping template to convert the model response to the required REST API format.

Step 6: Creating a mapping template for response integration

To add a mapping template for the response, complete the following steps:

1. On the Method Execution screen, choose Integration Response.

You should see a single entry with HTTP status regex set to the single character, with method response 200. This is the default response rule, which returns a 200 response code and passes the response through unaltered.

1. Expand this rule.
2. Under Mapping Templates, choose application/json.
3. Enter the following mapping template:

   {
     "ratings": [
   #set( $predictions = $input.path("$.predictions") )
   #foreach( $item in $predictions )
       $item.scores[0]#if( $foreach.hasNext ),#end
       $esc.newline
   #end
     ]
   }

This template iterates through the list of predictions returned by the model, and produces output that is compliant with the format required by the REST API.

1. Choose Save.

You can test this again by following the same procedure you used earlier, and this time you should see the output in the required response format.

Step 7: Deploying and testing the API

You are now ready to deploy your REST API. Complete the following steps:

1. On the Method Execution screen, under Actions, choose Deploy API.
2. For Deployment stage, choose [New Stage].
3. Give your stage a name, such as test.
4. Enter the required descriptions for this stage and deployment.
5. Choose Deploy.

You should now see a Stage Editor in the right-hand pane, with an Invoke URL endpoint for your deployed API. You can use curl to test your deployed endpoint.

1. At the command line, enter the following:

   curl "<invoke-url>/predicted-ratings/321?items=101,131,162&"

   Replace <invoke-url> with the URL for your endpoint.

You should see output similar to the below:

{
  "ratings": [
    3.527499437332153,
    3.951640844345093,
    3.658416271209717
  ]
}

You now have a deployed, working REST API that is integrated with your Amazon SageMaker runtime.

Additional considerations

This post focused on how to use API Gateway mapping templates to transform requests and responses between formats required by the REST API and model runtime. API Gateway provides numerous additional features that you can use to implement authorization, request validation, caching, response error code mapping, and throttling. When you are designing your overall architecture, consider how best to use these features.

This post used an example in which you could map requests and responses directly without the need for any intermediate compute resource. This may not be possible in all situations, such as when you need to enrich the request body with additional data from another source. In such cases, you can still use VTL-based mapping templates to pre-process requests and post-process responses, which reduces the load on any intermediate compute layer.

Cleaning up

When you are finished experimenting with your setup, clean up the various resources that you used on API Gateway, S3, and Amazon SageMaker. Make sure that you delete the Amazon SageMaker endpoint so you don’t continue to accrue charges.

If you wish to retain the model and API Gateway setup for further experimentation at a later time, you can re-create the endpoint when required. Remember to update the API Gateway request integration if you use a different endpoint name.

Conclusion

This post demonstrated how to use API Gateway to create a public RESTful endpoint for an Amazon SageMaker inference. Specifically, it showed how to use mapping templates and VTL to transform requests and responses to match the formats expected by the public-facing REST endpoint and the internal inference endpoint.

Mapping templates can help you avoid using intermediate compute resources between API Gateway and Amazon SageMaker. As a result, you reduce the latency and operational complexity of your application. API Gateway Mapping templates are also useful in situations in which you cannot avoid intermediate compute; you can still use them to perform pre- and post-processing to reduce load on the compute layer.

This approach is especially useful for use cases characterized by high-volume peak demand with low-latency inference, as typically seen in consumer applications.

About the Author

Mike Rizzo is a Senior Solutions Architect in the AWS EMEA Commercial team based in the UK. He has a Ph.D. in Computer Science from the University of Kent and an MBA from London Business School.

关于The Smart Field Service Prototype powered by SAP FSM and Wechat的介绍已经告一段落，感谢您的耐心阅读，如果想了解更多关于01. walkthrough 1 and 2 - data-sap-ui-libs="sap.ui.commons,sap.ui.table"、Array.prototype.keys()、Array.prototype.values()和Array.prototype.entries()、Comments on task “Smart Service II: Wrap up and make it ready for Demo“、Creating a machine learning-powered REST API with Amazon API Gateway mapping templates and Amazon...的相关信息，请在本站寻找。
