windows 10上源码编译libjpeg-turbo和使用教程(源码编译软件)
本文首发于个人博客https://kezunlin.me/post/83828674/,欢迎阅读!
compile and use libjpeg-turbo on windows 10
Series
- compile and use libjpeg-turbo on windows 10
- compile and use libjpeg-turbo on ubuntu 16.04
Guide
build requirements
Build Requirements
- cmake 2.8
- NASM 2.13
- Visual Studio 2015
- libjpeg-turbo 1.5.4
(1) If usingNASM
, 2.05 or later is required for an x86-64 build.(2)
nasm.exe/yasm.exe
should be in your PATH.
download
git clone https://github.com/libjpeg-turbo/libjpeg-turbo.git
# or
wget https://codeload.github.com/libjpeg-turbo/libjpeg-turbo/zip/master
install nasm
wget http://www.nasm.us/pub/nasm/releasebuilds/2.13.03rc1/win64/nasm-2.13.03rc1-installer-x64.exe
add C:\Program Files\NASM
to env path.
## compile libjpeg
cmake-gui
CMAKE_BUILD_TYPE = Release
ENABLE_SHARED = ON
CMAKE_INSTALL_PREFIX = d:/libjpeg-turbo64
NASM = C:/Program Files/NASM/nasm.exe
configure and generate sln
, compile with visual studio 2015
and install.
## usage with cmake
### libjpegturbo-config.cmake
set(LIBJPEGTURBO_FOUND TRUE) # auto
set(LIBJPEGTURBO_ROOT_DIR "d:/libjpeg-turbo64")
find_path(LIBJPEGTURBO_INCLUDE_DIR NAMES jpeglib.h turbojpeg.h PATHS "${LIBJPEGTURBO_ROOT_DIR}/include")
mark_as_advanced(LIBJPEGTURBO_INCLUDE_DIR) # show entry in cmake-gui
find_library(LIBJPEGTURBO_JPEG_LIBRARY NAMES jpeg.lib PATHS "${LIBJPEGTURBO_ROOT_DIR}/lib")
mark_as_advanced(LIBJPEGTURBO_JPEG_LIBRARY) # show entry in cmake-gui
find_library(LIBJPEGTURBO_TURBOJPEG_LIBRARY NAMES turbojpeg.lib PATHS "${LIBJPEGTURBO_ROOT_DIR}/lib")
mark_as_advanced(LIBJPEGTURBO_TURBOJPEG_LIBRARY) # show entry in cmake-gui
# use xxx_INCLUDE_DIRS and xxx_LIBRARIES in CMakeLists.txt
set(LIBJPEGTURBO_INCLUDE_DIRS ${LIBJPEGTURBO_INCLUDE_DIR} )
set(LIBJPEGTURBO_LIBRARIES ${LIBJPEGTURBO_JPEG_LIBRARY} ${LIBJPEGTURBO_TURBOJPEG_LIBRARY} )
message( "libjpegturbo-config.cmake " ${LIBJPEGTURBO_ROOT_DIR})
### CMakeLists.txt
find_package(LIBJPEGTURBO REQUIRED)
include_directories(${LIBJPEGTURBO_INCLUDE_DIRS})
add_executable (example_jpeg
${CMAKE_CURRENT_SOURCE_DIR}/src/example/example_jpeg.cpp
)
target_link_libraries (example_jpeg
${LIBJPEGTURBO_LIBRARIES}
)
add_executable (example_turbojpeg
${CMAKE_CURRENT_SOURCE_DIR}/src/example/example_turbojpeg.cpp
)
target_link_libraries (example_turbojpeg
${LIBJPEGTURBO_LIBRARIES}
)
Example Code
jpeglib vs turbojpeg
jpeglib
- include:
#include "jpeglib.h"
- lib:
jpeg.lib
- dll:
jpeg62.dll
turbojpeg
- include:
#include "turbojpeg.h"
- lib:
turbojpeg.lib
- dll:
turbojpeg.dll
turbojpeg is (3-5x) faster than jpeglib.
jpeglib
#include <iostream>
#include <fstream>
#include <ctime>
#include "jpeglib.h"
typedef unsigned char BYTE;
bool CompressJPEG(
/*IN*/BYTE *src, int width, int height, int depth,
/*OUT*/BYTE **dst, unsigned long *dstLen
)
{
// NOTICE: dst space must be created outside before passing in.
struct jpeg_compress_struct jcs;
struct jpeg_error_mgr jem;
jcs.err = jpeg_std_error(&jem);
jpeg_create_compress(&jcs);
jpeg_mem_dest(&jcs, dst, dstLen);
jcs.image_width = width;
jcs.image_height = height;
jcs.input_components = depth;
jcs.in_color_space = JCS_RGB;
jpeg_set_defaults(&jcs);
jpeg_set_quality(&jcs, 80, true);
jcs.jpeg_color_space = JCS_YCbCr;
jcs.comp_info[0].h_samp_factor = 2;
jcs.comp_info[0].v_samp_factor = 2;
jpeg_start_compress(&jcs, TRUE);
JSAMPROW row_pointer[1];
int row_stride = jcs.image_width*jcs.num_components;
while (jcs.next_scanline<jcs.image_height)
{
row_pointer[0] = &src[jcs.next_scanline*row_stride];
jpeg_write_scanlines(&jcs, row_pointer, 1);
}
jpeg_finish_compress(&jcs);
jpeg_destroy_compress(&jcs);
return true;
}
bool DeompressJPEG(
/*IN*/BYTE *src, unsigned long srcLen,
/*OUT*/BYTE **dst, unsigned long *dstLen, int *width, int *height, int *depth
)
{
// NOTICE: dst space will be created inside.
struct jpeg_decompress_struct cinfo;
struct jpeg_error_mgr jerr;
cinfo.err=jpeg_std_error(&jerr);
jpeg_create_decompress(&cinfo);
jpeg_mem_src(&cinfo,src,srcLen);
jpeg_read_header(&cinfo,TRUE);
jpeg_start_decompress(&cinfo);
(*width) = cinfo.output_width;
(*height) = cinfo.output_height;
(*depth) = cinfo.num_components;
(*dstLen) = (*width)*(*height)*(*depth);
BYTE *tmp_dst = new BYTE[*dstLen];
JSAMPROW row_pointer[1];
int row_stride = cinfo.image_width*cinfo.num_components;
while (cinfo.output_scanline<cinfo.output_height)
{
row_pointer[0] = &tmp_dst[cinfo.output_scanline*row_stride];
jpeg_read_scanlines(&cinfo,row_pointer,1);
}
jpeg_finish_decompress(&cinfo);
jpeg_destroy_decompress(&cinfo);
*dst = tmp_dst;
return true;
}
void compress_jpeg_to_file(
/*IN*/BYTE *src,int width, int height, int components, int color_space,int quality,
/*OUT*/char *dst_filename
)
{
/* This struct contains the JPEG compression parameters and pointers to
* working space (which is allocated as needed by the JPEG library).
* It is possible to have several such structures, representing multiple
* compression/decompression processes, in existence at once. We refer
* to any one struct (and its associated working data) as a "JPEG object".
*/
struct jpeg_compress_struct cinfo;
/* This struct represents a JPEG error handler. It is declared separately
* because applications often want to supply a specialized error handler
* (see the second half of this file for an example). But here we just
* take the easy way out and use the standard error handler, which will
* print a message on stderr and call exit() if compression fails.
* Note that this struct must live as long as the main JPEG parameter
* struct, to avoid dangling-pointer problems.
*/
struct jpeg_error_mgr jerr;
/* More stuff */
FILE *outfile; /* target file */
JSAMPROW row_pointer[1]; /* pointer to JSAMPLE row[s] */
int row_stride; /* physical row width in image buffer */
/* Step 1: allocate and initialize JPEG compression object */
/* We have to set up the error handler first, in case the initialization
* step fails. (Unlikely, but it could happen if you are out of memory.)
* This routine fills in the contents of struct jerr, and returns jerr''s
* address which we place into the link field in cinfo.
*/
cinfo.err = jpeg_std_error(&jerr);
/* Now we can initialize the JPEG compression object. */
jpeg_create_compress(&cinfo);
/* Step 2: specify data destination (eg, a file) */
/* Note: steps 2 and 3 can be done in either order. */
/* Here we use the library-supplied code to send compressed data to a
* stdio stream. You can also write your own code to do something else.
* VERY IMPORTANT: use "b" option to fopen() if you are on a machine that
* requires it in order to write binary files.
*/
if ((outfile = fopen(dst_filename, "wb")) == NULL) {
fprintf(stderr, "can''t open %s\n", dst_filename);
exit(1);
}
jpeg_stdio_dest(&cinfo, outfile);
/* Step 3: set parameters for compression */
/* First we supply a description of the input image.
* Four fields of the cinfo struct must be filled in:
*/
cinfo.image_width = width; /* image width and height, in pixels */
cinfo.image_height = height;
cinfo.input_components = components; /* # of color components per pixel */
cinfo.in_color_space = (J_COLOR_SPACE)color_space; /* colorspace of input image */
/* Now use the library''s routine to set default compression parameters.
* (You must set at least cinfo.in_color_space before calling this,
* since the defaults depend on the source color space.)
*/
jpeg_set_defaults(&cinfo);
/* Now you can set any non-default parameters you wish to.
* Here we just illustrate the use of quality (quantization table) scaling:
*/
jpeg_set_quality(&cinfo, quality, TRUE /* limit to baseline-JPEG values */);
/* Step 4: Start compressor */
/* TRUE ensures that we will write a complete interchange-JPEG file.
* Pass TRUE unless you are very sure of what you''re doing.
*/
jpeg_start_compress(&cinfo, TRUE);
/* Step 5: while (scan lines remain to be written) */
/* jpeg_write_scanlines(...); */
/* Here we use the library''s state variable cinfo.next_scanline as the
* loop counter, so that we don''t have to keep track ourselves.
* To keep things simple, we pass one scanline per call; you can pass
* more if you wish, though.
*/
row_stride = cinfo.image_width * cinfo.input_components; /* JSAMPLEs per row in image_buffer */
while (cinfo.next_scanline < cinfo.image_height) {
/* jpeg_write_scanlines expects an array of pointers to scanlines.
* Here the array is only one element long, but you could pass
* more than one scanline at a time if that''s more convenient.
*/
row_pointer[0] = &src[cinfo.next_scanline * row_stride];
(void)jpeg_write_scanlines(&cinfo, row_pointer, 1);
}
/* Step 6: Finish compression */
jpeg_finish_compress(&cinfo);
/* After finish_compress, we can close the output file. */
fclose(outfile);
/* Step 7: release JPEG compression object */
/* This is an important step since it will release a good deal of memory. */
jpeg_destroy_compress(&cinfo);
/* And we''re done! */
}
void compress_jpeg_to_mem(
/*IN*/BYTE *src,int width, int height, int components, int color_space,int quality,
/*OUT*/BYTE **dst, unsigned long *dstLen
)
{
/* This struct contains the JPEG compression parameters and pointers to
* working space (which is allocated as needed by the JPEG library).
* It is possible to have several such structures, representing multiple
* compression/decompression processes, in existence at once. We refer
* to any one struct (and its associated working data) as a "JPEG object".
*/
struct jpeg_compress_struct cinfo;
/* This struct represents a JPEG error handler. It is declared separately
* because applications often want to supply a specialized error handler
* (see the second half of this file for an example). But here we just
* take the easy way out and use the standard error handler, which will
* print a message on stderr and call exit() if compression fails.
* Note that this struct must live as long as the main JPEG parameter
* struct, to avoid dangling-pointer problems.
*/
struct jpeg_error_mgr jerr;
/* More stuff */
//FILE *outfile; /* target file */
JSAMPROW row_pointer[1]; /* pointer to JSAMPLE row[s] */
int row_stride; /* physical row width in image buffer */
/* Step 1: allocate and initialize JPEG compression object */
/* We have to set up the error handler first, in case the initialization
* step fails. (Unlikely, but it could happen if you are out of memory.)
* This routine fills in the contents of struct jerr, and returns jerr''s
* address which we place into the link field in cinfo.
*/
cinfo.err = jpeg_std_error(&jerr);
/* Now we can initialize the JPEG compression object. */
jpeg_create_compress(&cinfo);
/* Step 2: specify data destination (eg, a file) */
/* Note: steps 2 and 3 can be done in either order. */
//jpeg_stdio_dest(&cinfo, outfile);
jpeg_mem_dest(&cinfo, dst, dstLen);
/* Step 3: set parameters for compression */
/* First we supply a description of the input image.
* Four fields of the cinfo struct must be filled in:
*/
cinfo.image_width = width; /* image width and height, in pixels */
cinfo.image_height = height;
cinfo.input_components = components; /* # of color components per pixel */
cinfo.in_color_space = (J_COLOR_SPACE)color_space; /* colorspace of input image */
/* Now use the library''s routine to set default compression parameters.
* (You must set at least cinfo.in_color_space before calling this,
* since the defaults depend on the source color space.)
*/
jpeg_set_defaults(&cinfo);
/* Now you can set any non-default parameters you wish to.
* Here we just illustrate the use of quality (quantization table) scaling:
*/
jpeg_set_quality(&cinfo, quality, TRUE /* limit to baseline-JPEG values */);
/* Step 4: Start compressor */
/* TRUE ensures that we will write a complete interchange-JPEG file.
* Pass TRUE unless you are very sure of what you''re doing.
*/
jpeg_start_compress(&cinfo, TRUE);
/* Step 5: while (scan lines remain to be written) */
/* jpeg_write_scanlines(...); */
/* Here we use the library''s state variable cinfo.next_scanline as the
* loop counter, so that we don''t have to keep track ourselves.
* To keep things simple, we pass one scanline per call; you can pass
* more if you wish, though.
*/
row_stride = cinfo.image_width * cinfo.input_components; /* JSAMPLEs per row in image_buffer */
while (cinfo.next_scanline < cinfo.image_height) {
/* jpeg_write_scanlines expects an array of pointers to scanlines.
* Here the array is only one element long, but you could pass
* more than one scanline at a time if that''s more convenient.
*/
row_pointer[0] = &src[cinfo.next_scanline * row_stride];
(void)jpeg_write_scanlines(&cinfo, row_pointer, 1);
}
/* Step 6: Finish compression */
jpeg_finish_compress(&cinfo);
/* After finish_compress, we can close the output file. */
//fclose(outfile);
/* Step 7: release JPEG compression object */
/* This is an important step since it will release a good deal of memory. */
jpeg_destroy_compress(&cinfo);
/* And we''re done! */
}
int decompress_jpeg_from_file(
/*IN*/char *src_filename,
/*OUT*/BYTE **dst, unsigned long *dstLen, int *width, int *height, int *components,int *color_space)
{
/* This struct contains the JPEG decompression parameters and pointers to
* working space (which is allocated as needed by the JPEG library).
*/
struct jpeg_decompress_struct cinfo;
/* We use our private extension JPEG error handler.
* Note that this struct must live as long as the main JPEG parameter
* struct, to avoid dangling-pointer problems.
*/
struct jpeg_error_mgr jerr;
/* More stuff */
FILE *infile; /* source file */
int row_stride; /* physical row width in output buffer */
/* In this example we want to open the input file before doing anything else,
* so that the setjmp() error recovery below can assume the file is open.
* VERY IMPORTANT: use "b" option to fopen() if you are on a machine that
* requires it in order to read binary files.
*/
if ((infile = fopen(src_filename, "rb")) == NULL) {
fprintf(stderr, "can''t open %s\n", src_filename);
return 0;
}
/* Step 1: allocate and initialize JPEG decompression object */
/* We set up the normal JPEG error routines, then override error_exit. */
cinfo.err = jpeg_std_error(&jerr);
/* Now we can initialize the JPEG decompression object. */
jpeg_create_decompress(&cinfo);
/* Step 2: specify data source (eg, a file) */
jpeg_stdio_src(&cinfo, infile);
/* Step 3: read file parameters with jpeg_read_header() */
(void)jpeg_read_header(&cinfo, TRUE);
/* We can ignore the return value from jpeg_read_header since
* (a) suspension is not possible with the stdio data source, and
* (b) we passed TRUE to reject a tables-only JPEG file as an error.
* See libjpeg.txt for more info.
*/
/* Step 4: set parameters for decompression */
/* In this example, we don''t need to change any of the defaults set by
* jpeg_read_header(), so we do nothing here.
*/
/* Step 5: Start decompressor */
(void)jpeg_start_decompress(&cinfo);
/* We can ignore the return value since suspension is not possible
* with the stdio data source.
*/
/* We may need to do some setup of our own at this point before reading
* the data. After jpeg_start_decompress() we have the correct scaled
* output image dimensions available, as well as the output colormap
* if we asked for color quantization.
* In this example, we need to make an output work buffer of the right size.
*/
/* JSAMPLEs per row in output buffer */
row_stride = cinfo.output_width * cinfo.output_components;
/* Make a one-row-high sample array that will go away when done with image */
/* Set output fields */
(*width) = cinfo.output_width;
(*height) = cinfo.output_height;
(*components) = cinfo.num_components;
(*color_space) = cinfo.jpeg_color_space;
(*dstLen) = (*width)*(*height)*(*components);
BYTE *tmp_dst = new BYTE[*dstLen]; /* Allocate out buffer */
JSAMPROW row_pointer[1];
row_stride = cinfo.output_width*cinfo.num_components;
/* Step 6: while (scan lines remain to be read) */
/* jpeg_read_scanlines(...); */
/* Here we use the library''s state variable cinfo.output_scanline as the
* loop counter, so that we don''t have to keep track ourselves.
*/
while (cinfo.output_scanline < cinfo.output_height) {
/* jpeg_read_scanlines expects an array of pointers to scanlines.
* Here the array is only one element long, but you could ask for
* more than one scanline at a time if that''s more convenient.
*/
row_pointer[0] = &tmp_dst[cinfo.output_scanline*row_stride];
(void)jpeg_read_scanlines(&cinfo, row_pointer, 1);
}
(*dst) = tmp_dst; // assign to outside dst
/* Step 7: Finish decompression */
(void)jpeg_finish_decompress(&cinfo);
/* We can ignore the return value since suspension is not possible
* with the stdio data source.
*/
/* Step 8: Release JPEG decompression object */
/* This is an important step since it will release a good deal of memory. */
jpeg_destroy_decompress(&cinfo);
/* After finish_decompress, we can close the input file.
* Here we postpone it until after no more JPEG errors are possible,
* so as to simplify the setjmp error logic above. (Actually, I don''t
* think that jpeg_destroy can do an error exit, but why assume anything...)
*/
fclose(infile);
/* At this point you may want to check to see whether any corrupt-data
* warnings occurred (test whether jerr.pub.num_warnings is nonzero).
*/
/* And we''re done! */
return 1;
}
int decompress_jpeg_from_mem(
/*IN*/BYTE *src, unsigned long srcLen,
/*OUT*/BYTE **dst, unsigned long *dstLen, int *width, int *height, int *components, int *color_space)
{
/* This struct contains the JPEG decompression parameters and pointers to
* working space (which is allocated as needed by the JPEG library).
*/
struct jpeg_decompress_struct cinfo;
/* We use our private extension JPEG error handler.
* Note that this struct must live as long as the main JPEG parameter
* struct, to avoid dangling-pointer problems.
*/
struct jpeg_error_mgr jerr;
/* More stuff */
//FILE *infile; /* source file */
int row_stride; /* physical row width in output buffer */
/* In this example we want to open the input file before doing anything else,
* so that the setjmp() error recovery below can assume the file is open.
* VERY IMPORTANT: use "b" option to fopen() if you are on a machine that
* requires it in order to read binary files.
*/
/*
if ((infile = fopen(src_filename, "rb")) == NULL) {
fprintf(stderr, "can''t open %s\n", src_filename);
return 0;
}
*/
/* Step 1: allocate and initialize JPEG decompression object */
/* We set up the normal JPEG error routines, then override error_exit. */
cinfo.err = jpeg_std_error(&jerr);
/* Now we can initialize the JPEG decompression object. */
jpeg_create_decompress(&cinfo);
/* Step 2: specify data source (eg, a file) */
//jpeg_stdio_src(&cinfo, infile);
jpeg_mem_src(&cinfo, src, srcLen);
/* Step 3: read file parameters with jpeg_read_header() */
(void)jpeg_read_header(&cinfo, TRUE);
/* We can ignore the return value from jpeg_read_header since
* (a) suspension is not possible with the stdio data source, and
* (b) we passed TRUE to reject a tables-only JPEG file as an error.
* See libjpeg.txt for more info.
*/
/* Step 4: set parameters for decompression */
/* In this example, we don''t need to change any of the defaults set by
* jpeg_read_header(), so we do nothing here.
*/
/* Step 5: Start decompressor */
(void)jpeg_start_decompress(&cinfo);
/* We can ignore the return value since suspension is not possible
* with the stdio data source.
*/
/* We may need to do some setup of our own at this point before reading
* the data. After jpeg_start_decompress() we have the correct scaled
* output image dimensions available, as well as the output colormap
* if we asked for color quantization.
* In this example, we need to make an output work buffer of the right size.
*/
/* JSAMPLEs per row in output buffer */
row_stride = cinfo.output_width * cinfo.output_components;
/* Make a one-row-high sample array that will go away when done with image */
/* Set output fields */
(*width) = cinfo.output_width;
(*height) = cinfo.output_height;
(*components) = cinfo.num_components;
(*color_space) = cinfo.jpeg_color_space;
(*dstLen) = (*width)*(*height)*(*components);
BYTE *tmp_dst = new BYTE[*dstLen]; /* Allocate out buffer */
JSAMPROW row_pointer[1];
row_stride = cinfo.output_width*cinfo.num_components;
/* Step 6: while (scan lines remain to be read) */
/* jpeg_read_scanlines(...); */
/* Here we use the library''s state variable cinfo.output_scanline as the
* loop counter, so that we don''t have to keep track ourselves.
*/
while (cinfo.output_scanline < cinfo.output_height) {
/* jpeg_read_scanlines expects an array of pointers to scanlines.
* Here the array is only one element long, but you could ask for
* more than one scanline at a time if that''s more convenient.
*/
row_pointer[0] = &tmp_dst[cinfo.output_scanline*row_stride];
(void)jpeg_read_scanlines(&cinfo, row_pointer, 1);
}
(*dst) = tmp_dst; // assign to outside dst
/* Step 7: Finish decompression */
(void)jpeg_finish_decompress(&cinfo);
/* We can ignore the return value since suspension is not possible
* with the stdio data source.
*/
/* Step 8: Release JPEG decompression object */
/* This is an important step since it will release a good deal of memory. */
jpeg_destroy_decompress(&cinfo);
/* After finish_decompress, we can close the input file.
* Here we postpone it until after no more JPEG errors are possible,
* so as to simplify the setjmp error logic above. (Actually, I don''t
* think that jpeg_destroy can do an error exit, but why assume anything...)
*/
//fclose(infile);
/* At this point you may want to check to see whether any corrupt-data
* warnings occurred (test whether jerr.pub.num_warnings is nonzero).
*/
/* And we''re done! */
return 1;
}
void test_compress_to_file()
{
int width = 2000;
int height = 1000;
int channel = 1;
int nImgSize = width * height * channel;
unsigned char * pRawImage = new unsigned char[nImgSize]; // new buffer
memset(pRawImage, 0, nImgSize);
for (int i = 100; i < 300; i++) // row [height]
{
for (int j = 0; j < width; j++) // column [width]
{
*(pRawImage + width * i + j) = (char)255;
}
}
// do work.
compress_jpeg_to_file(
pRawImage,width,height,channel,J_COLOR_SPACE::JCS_GRAYSCALE,90,
"../image/compress/to_file.jpg"
);
delete[] pRawImage;
}
void test_compress_to_mem()
{
int width = 2000;
int height = 1000;
int channel = 1;
int nImgSize = width * height * channel;
unsigned char * pRawImage = new unsigned char[nImgSize]; // new buffer
memset(pRawImage, 0, nImgSize);
for (int i = 100; i < 300; i++) // row [height]
{
for (int j = 0; j < width; j++) // column [width]
{
*(pRawImage + width * i + j) = (char)255;
}
}
// (1) new dst space outside **compress** function
// pOutBuffer''s nImgSize must > lOutSize to contain valid dst buffer.
unsigned char *pOutBuffer = new unsigned char[nImgSize]; // new dst buffer
unsigned long lOutSize = 0;
// (2) compress to mem
compress_jpeg_to_mem(
pRawImage, width, height, channel, J_COLOR_SPACE::JCS_GRAYSCALE, 90,
&pOutBuffer, &lOutSize
);
std::cout << "orginal size = " << nImgSize << std::endl;
std::cout << "compress size = "<<lOutSize << std::endl; // 30403
// (3) write mem buffer to file
const char* dst_filename = "../image/compress/mem_to_file.jpg";
FILE *outfile;
if ((outfile = fopen(dst_filename, "wb")) == NULL) {
fprintf(stderr, "can''t open %s\n", dst_filename);
exit(1);
}
fwrite(pOutBuffer,lOutSize,1,outfile);
fclose(outfile);
delete[] pOutBuffer;
delete[] pRawImage;
}
void test_decompress_from_file()
{
char* src_filename = "../image/compress/to_file.jpg";
BYTE *dst = NULL; // raw image buffer allocated inside **decompress** function
unsigned long dstLen;
int width, height, channel,color_space;
// allocate dst inside function
decompress_jpeg_from_file(
src_filename,
&dst,&dstLen,&width,&height,&channel,&color_space
);
std::cout << dstLen << std::endl;
std::cout << width << std::endl;
std::cout << height << std::endl;
std::cout << channel << std::endl;
std::cout << color_space << std::endl;
// use raw image buffer
// do work.
compress_jpeg_to_file(
dst, width, height, channel, J_COLOR_SPACE::JCS_GRAYSCALE, 90,
"../image/compress/decompress_from_file_and_then_to_file.jpg"
);
// free allocated memory
if (dst != NULL)
{
delete[] dst;
}
}
void test_decompress_from_mem()
{
// (0) create memory src buffer
char* src_filename = "../image/compress/to_file.jpg";
std::ifstream ifs(src_filename, std::ios_base::binary | std::ios_base::in);
ifs.seekg(0, std::ios::end);
uint64_t size = ifs.tellg();
ifs.seekg(0, std::ios::beg);
//std::vector<char> buffer(size);
//ifs.read(&buffer.front(), size);
BYTE *src = new BYTE[size];
ifs.read((char*)src, size);
// (1) decompress from mem
BYTE *dst = NULL; // raw image buffer allocated inside **decompress** function
unsigned long dstLen;
int width, height, channel, color_space;
// allocate dst inside function
decompress_jpeg_from_mem(
src,size,
&dst, &dstLen, &width, &height, &channel, &color_space
);
std::cout << dstLen << std::endl;
std::cout << width << std::endl;
std::cout << height << std::endl;
std::cout << channel << std::endl;
std::cout << color_space << std::endl;
// (2) use raw image buffer
// do work.
compress_jpeg_to_file(
dst, width, height, channel, J_COLOR_SPACE::JCS_GRAYSCALE, 90,
"../image/compress/decompress_from_mem_and_then_to_file.jpg"
);
// free dst allocated memory
if (dst != NULL)
{
delete[] dst;
}
// free src memory buffer
delete[] src;
}
int IMAGE_COUNT = 10000;
void test_compress_time()
{
int width = 2000;
int height = 1000;
int channel = 1;
unsigned long srcLen = width * height * channel;
unsigned char * src = new unsigned char[srcLen]; // new buffer
memset(src, 0, srcLen);
for (int i = 100; i < 300; i++) // row [height]
{
for (int j = 0; j < width; j++) // column [width]
{
*(src + width * i + j) = (char)255;
}
}
int quality = 90;
time_t start = time(NULL);
for (int i = 0; i < IMAGE_COUNT; i++)
{
// (1) new dst space outside **compress** function
// pOutBuffer''s nImgSize must > lOutSize to contain valid dst buffer.
unsigned char *pOutBuffer = new unsigned char[srcLen]; // new dst buffer
unsigned long lOutSize = 0;
// (2) compress to mem
compress_jpeg_to_mem(
src, width, height, channel, J_COLOR_SPACE::JCS_GRAYSCALE, 90,
&pOutBuffer, &lOutSize
);
// (3) free memory
delete[] pOutBuffer;
}
time_t end = time(NULL);
std::cout << "======================================" << std::endl;
double ms = (double)(end - start) * 1000;
std::cout << " use times = " << ms << "ms; avg = " << ms / IMAGE_COUNT << " ms; " << " #" << IMAGE_COUNT << std::endl;
// avg = 4.9 ms #10000 for jpeg
// avg = 4.5 ms #10000 for turbojpeg
std::cout << "======================================" << std::endl;
delete[] src;
}
void test_decompress_time()
{
}
int main(int argc, char* argv[])
{
// 30403, 30153
//test_compress_to_file();
//test_compress_to_mem();
//test_decompress_from_file();
//test_decompress_from_mem();
test_compress_time();
return 0;
}
turbojpeg
#include <iostream>
#include <fstream>
#include <vector>
#include <ctime>
#include "turbojpeg.h"
typedef unsigned char BYTE;
void save_buffer_to_file(const char *filename,BYTE* buffer,unsigned long size)
{
FILE *outfile;
if ((outfile = fopen(filename, "wb")) != NULL) {
fwrite(buffer, size, 1, outfile);
fclose(outfile);
}
else
{
fprintf(stderr, "can''t open %s\n", filename);
exit(1);
}
}
/*
* Compress image buffer to a JPEG image in memory.
*
* @@input
*
* @param : [src] pointer to an image buffer that will be compressed.
* @param :
*
* @@output
* @param : [dst] pointer to an image buffer that will receive the compressed image.
This variable should be passed in with NULL, and will be allocated by
TurboJPEG(either by tjAlloc(),or by the Compress/Decompress) method
So we need to use tjFree() to free memory allocated after we are done
working on dst.
* @param : [dstLen] size of dst image buffer in bytes. This should be passed in with
value 0.
*
* @@return
* @param void
*
* @@demo
*
BYTE *dst = NULL;
unsigned long dstLen = 0;
tj_compress_jpeg_to_mem(
....,
&dst,&dstLen
)
*/
void tj_compress_jpeg_to_mem(
/*IN*/BYTE *src, int width, int height, int pixelFormat, int subsamp, int quality, int flags,
/*OUT*/BYTE **dst, unsigned long *dstLen
)
{
// NOTICE : we must use tjAlloc() and tjFree() to allocate dst buffer.
// for compress, we let **tjCompress2** allocate dst buffer.
// for decompress, we allocate dst buffer by ourself.
tjhandle handle = tjInitCompress();
//tjCompress2(handle, src, width, 0/*pitch*/, height, TJPF::TJPF_GRAY,
// &pOutBuffer, &lOutSize, TJSAMP::TJSAMP_GRAY, quality,
// TJFLAG_FASTDCT); //TJFLAG_FASTDCT
tjCompress2(
handle, src, width, 0/*pitch*/, height, pixelFormat,
dst, dstLen, subsamp, quality, flags
);
tjDestroy(handle);
}
void tj_compress_gray_jpeg_to_mem(
/*IN*/BYTE *src, int width, int height, int quality,
/*OUT*/BYTE **dst, unsigned long *dstLen
)
{
int pixelFormat = TJPF::TJPF_GRAY;
int subsamp = TJSAMP::TJSAMP_GRAY;
int flags = TJFLAG_FASTDCT;
tj_compress_jpeg_to_mem(
src, width, height, pixelFormat, subsamp, quality, flags,
dst, dstLen
);
}
void tj_compress_gray_jpeg_to_file(
/*IN*/BYTE *src, int width, int height, int quality,
/*OUT*/const char* dst_filename
)
{
int pixelFormat = TJPF::TJPF_GRAY;
int subsamp = TJSAMP::TJSAMP_GRAY;
int flags = TJFLAG_FASTDCT;
// (1) init dst memory buffer
BYTE *dst = NULL; // memory allocated by TurboJPEG tjAlloc()
unsigned long dstLen = 0;
// (2) compress
tj_compress_jpeg_to_mem(
src, width, height, pixelFormat, subsamp, quality, flags,
&dst, &dstLen
);
// (3) write buffer to file
save_buffer_to_file(dst_filename, dst, dstLen);
// (4) free memory allocated by TurboJPEG
tjFree(dst);
}
/*
* Compress image buffer to a JPEG image in memory.
*
* @@input
*
* @param : [src] pointer to an image buffer that will be compressed.
* @param :
*
* @@output
* @param : [dst] pointer to an image buffer that will receive the decompressed image.
This variable should be passed in with NULL, and will be allocated in
method by new[]. So we need to use delete[] to free memory allocated
after we are done working on dst.
* @param : [dstLen] size of dst image buffer in bytes. This should be passed in with
value 0.
*
* @@return
* @param void
*
* @@demo
*
BYTE *dst = NULL;
unsigned long dstLen = 0;
tj_decompress_jpeg_from_mem(
....,
&dst,&dstLen
)
*/
void tj_decompress_jpeg_from_mem(
/*IN*/BYTE *src, unsigned long srcLen,int tjPixelFormat,int flags,
/*OUT*/BYTE **dst, unsigned long *dstLen, int *width, int *height, int *components, int *jpegSubsamp, int *jpegColorspace)
{
tjhandle handle = tjInitDecompress();
tjDecompressHeader3(handle, src, srcLen, width, height, jpegSubsamp, jpegColorspace);
(*components) = tjPixelSize[(TJPF)tjPixelFormat]; // 1 for GRAY,3 for RGB
(*dstLen) = (*width) * (*height) * (*components);
BYTE *tmp_dst = new BYTE[*dstLen]; /* Allocate out buffer */
tjDecompress2(
handle, src, srcLen,
tmp_dst, *width, 0/*pitch*/, *height, tjPixelFormat, flags
);
tjDestroy(handle);
(*dst) = tmp_dst; // pass dst out
}
void tj_decompress_gray_jpeg_from_mem(
/*IN*/BYTE *src, unsigned long srcLen,
/*OUT*/BYTE **dst, unsigned long *dstLen, int *width, int *height, int *components
)
{
int pixelFormat = TJPF::TJPF_GRAY;
int flags = TJFLAG_ACCURATEDCT;
int subsamp,colorspace; // no use for now (3 TJSAMP::TJSAMP_GRAY, 2 TJCS::TJCS_GRAY)
tj_decompress_jpeg_from_mem(
src, srcLen, pixelFormat, flags,
dst, dstLen, width, height, components, &subsamp, &colorspace
);
}
void tj_decompress_gray_jpeg_from_file(
/*IN*/const char* src_filename,
/*OUT*/BYTE **dst, unsigned long *dstLen, int *width, int *height, int *components
)
{
// (0) read src memory buffer from file
std::ifstream ifs(src_filename, std::ios_base::binary | std::ios_base::in);
ifs.seekg(0, std::ios::end);
uint64_t srcLen = ifs.tellg();
ifs.seekg(0, std::ios::beg);
BYTE *src = new BYTE[srcLen];
ifs.read((char*)src, srcLen);
// (2) decompress
int pixelFormat = TJPF::TJPF_GRAY;
int flags = TJFLAG_ACCURATEDCT;
int subsamp, colorspace; // no use for now (3 TJSAMP::TJSAMP_GRAY, 2 TJCS::TJCS_GRAY)
tj_decompress_jpeg_from_mem(
src, srcLen, pixelFormat, flags,
dst, dstLen, width, height, components, &subsamp, &colorspace
);
// (3) free src memory buffer
delete[] src;
// (4) pass out dst buffer
}
void test_compress()
{
int width = 2000;
int height = 1000;
int channel = 1;
unsigned long srcLen = width * height * channel;
unsigned char * src = new unsigned char[srcLen]; // new buffer
memset(src, 0, srcLen);
for (int i = 100; i < 300; i++) // row [height]
{
for (int j = 0; j < width; j++) // column [width]
{
*(src + width * i + j) = (char)255;
}
}
//========================================================================
// compress to file
int quality = 90;
const char* filename = "../image/compress/tj_mem_to_file.jpg";
tj_compress_gray_jpeg_to_file(src, width, height, quality, filename);
//========================================================================
delete[] src;
}
void test_decompress()
{
// (0) create memory src buffer
char* src_filename = "../image/compress/to_file.jpg";
// (2) decompress
BYTE *dst = NULL; // allocated inside **decompress** function by new[].
unsigned long dstLen = 0;
int width, height, components;
tj_decompress_gray_jpeg_from_file(
src_filename,
&dst, &dstLen, &width, &height, &components
);
std::cout << dstLen << std::endl;
std::cout << width << std::endl;
std::cout << height << std::endl;
std::cout << components << std::endl;
// (3) use dst buffer
//========================================================================
// compress to file
int quality = 90;
const char* dst_filename = "../image/compress/tj_decompress_to_mem_to_file.jpg";
tj_compress_gray_jpeg_to_file(dst, width, height, quality, dst_filename);
//========================================================================
// (4) free dst buffer
delete[] dst;
}
int IMAGE_COUNT = 10000;
void test_compress_time()
{
int width = 2000;
int height = 1000;
int channel = 1;
unsigned long srcLen = width * height * channel;
unsigned char * src = new unsigned char[srcLen]; // new buffer
memset(src, 0, srcLen);
for (int i = 100; i < 300; i++) // row [height]
{
for (int j = 0; j < width; j++) // column [width]
{
*(src + width * i + j) = (char)255;
}
}
int quality = 90;
time_t start = time(NULL);
for (int i = 0; i < IMAGE_COUNT; i++)
{
//========================================================================
// (1) init dst memory buffer
BYTE *dst = NULL; // memory allocated by TurboJPEG tjAlloc()
unsigned long dstLen = 0;
// (2) compress
tj_compress_gray_jpeg_to_mem(
src, width, height, quality,
&dst, &dstLen
);
// (3) free memory allocated by TurboJPEG
tjFree(dst);
//========================================================================
}
time_t end = time(NULL);
std::cout << "======================================" << std::endl;
double ms = (double)(end - start) * 1000;
std::cout << " use times = " << ms << "ms; avg = " << ms / IMAGE_COUNT << " ms; " << " #" << IMAGE_COUNT << std::endl;
// avg = 4.9 ms #10000 for jpeg
// avg = 4.5 ms #10000 for turbojpeg
std::cout << "======================================" << std::endl;
delete[] src;
}
void test_decompress_time()
{
}
int main(int argc, char* argv[])
{
//test_compress();
//test_decompress();
test_compress_time();
return 0;
}
Reference
- example.c
- building
- turbo offical doc
- compress and decompress jpeg
- opencv imdecode to libjpeg-turbo (good)
- tjcompress and tjdecompress
History
- 20180201: created.
- 20180202: add example code.
Copyright
- Post author: kezunlin
- Post link: https://kezunlin.me/post/83828674/
- Copyright Notice: All articles in this blog are licensed under CC BY-NC-SA 3.0 unless stating additionally.
AdDuplex:Windows 10 21H1 和 Windows 11 首次进入快速增
AdDuplex 关于 Windows 10 统计数据的最后一份报告是几个月前的。从那以后发生了很多事情。因为Windows 10 2004的比例明显缩水,Windows 10 21H1的比例有所增加。
事实上,现在有 26.6% 的用户在使用 Windows 10 21H1。Windows 10 20H2 的份额从 40.1% 下降到 36.3%,而 2004 年的份额从 40.6% 下降到“仅”24.6%。
有趣的是内部版本用户数量的增加。这里的比例通常最多在 0.4% 和 0.7% 之间波动。但现在仅 Windows 11 就已经拥有 0.9% 的份额,Windows 10 Insider 已经拥有 0.2% 的份额。现在已经总结了旧版本的比例。与 1903 年和 1909 年一起是 11.5%。
Linux/Wine:windows 应用程序启动 windows 控制台命令并在 windows 上等待时在 linux 上不等待:如何修复?
如何解决Linux/Wine:windows 应用程序启动 windows 控制台命令并在 windows 上等待时在 linux 上不等待:如何修复??
除了一项功能外,我还使用 Wine 成功运行了 Windows 程序。该程序可以设置为在 texlive 发行版中启动 pdflatex,当它启动时,它等待查看结果是否成功,然后复制/移动文件。但是在 Linux 上,我无法安排它像在 Windows 上那样等待 pdflatex 完成,因此过早地复制/移动文件并且 pdflatex 无法找到它们。
有一个对话框可以用来保存任意命令,当我按下应用程序中的 pdflatex 按钮时,该命令将被执行。我将此对话框指向 Windows 上的 C:\texlive\2020\bin\win32\pdflatex.exe 并且它可以工作。除了不等待的问题外,我成功地放置了这个命令,以便在Linux上使用wine运行pdflatex。
Z:/usr/bin/gnome-terminal --wait -- /home/nonnull/bin/runlatex/runlatex.sh "%f"
通过将 runlatex.sh 中的最后一个命令设为 exec /bin/bash
,终端保持打开状态,因此我可以看到 pdflatex 的所有输出,并知道它正在使用 runlatex.sh 必须找出的正确文件运行通过将传递给它的 Windows 路径转换为其实际路径。 pdflatex 以各种方式抱怨它在那里创建的文件,然后在运行期间不存在。即使终端是打开的,所以没有完成执行,应用程序抱怨 pdflatex 没有正确完成,甚至在 pdflatex 的输出文本完成向下滚动终端之前。当我省略 exec 时,应用程序的行为不会改变终端立即关闭时的命令 pdflatex 完成。
Wine 是怎么回事,命令在完成运行之前不会保持附加状态?我该怎么办?对可以绕过这个困难的命令或机制有什么建议吗?如果需要的话,我准备编写一个 win32 程序来进行调解。
解决方法
暂无找到可以解决该程序问题的有效方法,小编努力寻找整理中!
如果你已经找到好的解决方法,欢迎将解决方案带上本链接一起发送给小编。
小编邮箱:dio#foxmail.com (将#修改为@)
Microsoft Edge 93 在 Windows 11 和 Windows 10 上获得设计
WIN11地平线上出现,它的设置为开始滚动10月5日提前计划的推出,微软边缘93已经发布了两个实验功能的支持:菜单和一个全新设计的现代滚动条相匹配的良好作风的视窗 11。
Microsoft Edge 93 具有多项改进和一些新功能。例如,微软已经启用了对类似 Chrome 的标签组的支持,旨在帮助用户有效地查找标签,以便他们可以轻松切换和管理标签。
Edge 93 还支持 PDF 文档的“从上次中断的地方继续”。同样,您可以使用将鼠标悬停在支持的视频上时出现的新工具栏,轻松地以画中画模式观看视频。工具栏只是让您在画中画窗口中查看该视频。
垂直选项卡设计已更新为 edge://settings/appearance 中的一个新选项,以隐藏浏览器的标题栏。除了这些改进之外,微软还引入了对新实验性功能的支持:Windows 11 Visual Updates 和 Overlay 滚动条
第一个标志将打开云母效果,这是一种新的 Windows 11 独有的设计材料,可自动将桌面背景的颜色应用于活动窗口。云母效果仅适用于浏览器的标题栏,如下面的屏幕截图所示。
它还为 Edge 菜单和上下文菜单启用 Fluent Design 的亚克力效果(部分透明)。如果您在 Windows 11 上启用该标志,它将调整菜单字体的大小,使其看起来更大一些。除了字体变化,它还使一些按钮居中,包括最小化、最大化和关闭。
另一方面,Windows 11 和 Windows 10 都完全支持叠加滚动条。叠加滚动条标志为浏览器的默认滚动条提供了精简设计,并且还支持暗模式。
更重要的是,“覆盖滚动条”功能旨在与 Windows 11 应用程序(如设置和资源管理器)的外观和感觉相匹配。
为了尝试这些功能,您需要 Edge 93(稳定版)或更新版本。更新到最新版本后,打开 Edge 标志菜单并启用 Windows 11 视觉更新标志。
要尝试 Edge 93 中的新滚动条,请打开 Edge 的属性选项卡并将以下代码添加到目标字段:
--enable-features=OverlayScrollbar,OverlayScrollbarWinStyle,OverlayScrollbarWinStyleAnimation
微软可能会在未来几个月为 Windows 11 用户引入更多的 Edge 视觉更新。
MSMG ToolKit 11.7 支持 Windows 11 22000 和 Windows 10 21H2
我们已经多次报告了 MSMG ToolKit 。一个小工具,除其他外,用于删除 Windows 下的功能。集成更新或驱动程序等等。
使用 MSMG ToolKit 11.7,现在还支持 Windows 11(系统)和 Windows 10 21H2(系统和移除组件)。更改列表很长。这是一个概述:
• 使用 Tweak 更新了“Apply Tweaks”功能,以禁用Windows 11 源操作系统的 Windows 11 安装程序的硬件检查。
• bin 文件夹的更新:Windows 11 WADK (v10.0.22000.1)、7-zip v21.03 命令行二进制文件
• 适用于 Windows 11、Windows Server LTSC 2022 的“集成 Microsoft .NET Framework 3.5”功能
• Microsoft .NET Framework 3.5 Pack for MSMG Toolkit for Windows 11, Windows Server LTSC 2022
• Microsoft .NET Framework 4.8 Pack for Windows 7 / Server 2008 R2 和该包也已更新
• 更新了适用于 Windows 11 和 Windows Server LTSC 2022 的“Microsoft Windows Accessible Braille”功能
• 更新“集成多媒体受限编解码器”功能以集成适用于 Windows 10 LTSC 和服务器源操作系统的 Windows 10 杜比编解码器并更新编解码器包。
• 更新开放安全外壳 (SSH) 功能以支持 Windows 11
• 更新了“集成 Microsoft DaRT 工具”功能以支持 Windows 11、Windows Server LTSC 2022 + DebugTools
• 更新删除 Windows 组件功能以支持 Windows 10 1809、1903、1909、2004、20H1、20H2
• 由于错误而禁用 Windows 防火墙 Windows 组件的删除。
• 添加了适用于 Windows 10 的“包含 Windows 图标皮肤”功能。
• 更正了“WIM 管理器- 导出”功能中的错误,如果选择了所有 WIM 索引,则导出失败。
• 已修复函数“WIM Manger- Convert”中的错误,如果选择了所有 WIM 索引,则转换失败。
• 工具包代码优化
我们今天的关于windows 10上源码编译libjpeg-turbo和使用教程和源码编译软件的分享就到这里,谢谢您的阅读,如果想了解更多关于AdDuplex:Windows 10 21H1 和 Windows 11 首次进入快速增、Linux/Wine:windows 应用程序启动 windows 控制台命令并在 windows 上等待时在 linux 上不等待:如何修复?、Microsoft Edge 93 在 Windows 11 和 Windows 10 上获得设计、MSMG ToolKit 11.7 支持 Windows 11 22000 和 Windows 10 21H2的相关信息,可以在本站进行搜索。
本文标签:
