react 16 渲染整理（react的渲染）
背景
老的react架构在渲染时会有一些性能问题，从setstate到render，程序一直在跑，一直到render完成。才能继续下一步操作。如果组件比较多，或者有复杂的计算逻辑，这之间的消耗的时间是比较多的。 假设更新一个组件需要1ms，如果有200个组件要更新，那就需要200ms，这200ms之间是不能响应的。如果这时候用户在input框输入什么东西，表现出来的就是明显的卡顿。 React这样的调度策略对动画的支持也不好。如果React更新一次状态，占用浏览器主线程的时间超过16.6ms，就会被人眼发觉前后两帧不连续，呈现出动画卡顿。
Fiber
react团队经过两年的工作，重写了react中核心算法reconciliation。并在v16版本中发布了这个新的特性。为了区别之前和之后的reconciler，通常将之前的reconciler称为stack reconciler，重写后的称为fiber reconciler，简称为Fiber。
区别
最大的变化就是支持了任务帧，把各个任务都增加了优先级，同步和异步。比如用户输入input是优先级比较高的，它可以打断低优先级的任务。 比如再处理dom diff的时候耗时严重，fiber任务处理大概会有50ms的帧时长，超过这个时间就会先去看看有没高优任务去做。然后回来做低优先级任务。
- 优先级高的任务可以中断低优先级的任务。
- 还增加了异步任务，调用requestIdleCallback api，浏览器空闲的时候执行。（不过用户操作默认是同步的，暂时还没开放这个特性）
- dom diff树变成了链表，一个dom对应两个fiber（一个链表），对应两个队列，这都是为找到被中断的任务，重新执行而设计的。
渲染流程
scheduleWork - requestWork - 同步/异步 - performSyncWork- performWork - performWorkOnRoot - renderRoot/completeRoot - workLoop-performUnitOfWork-beginWork/completeUnitOfWork -updateClassComponent-reconcileChildrenAtExpirationTime- reconcileChildFibers-reconcileChildrenArray 源码基于react v16.3.0 （8e3d94ff）
setstate
Component.prototype.setState = function(partialState, callback) {
this.updater.enqueueSetState(this, partialState, callback, ''setState'');
};
enqueueSetState
主要是把任务插入fiber的update queue，然后调度任务
enqueueSetState(instance, partialState, callback) {
const fiber = ReactInstanceMap.get(instance);
callback = callback === undefined ? null : callback;
const expirationTime = computeExpirationForFiber(fiber);
const update = {
expirationTime,
partialState,
callback,
isReplace: false,
isForced: false,
capturedValue: null,
next: null,
};
insertUpdateIntoFiber(fiber, update);
scheduleWork(fiber, expirationTime);
},
insertUpdateIntoFiber
插入fiber两棵树的update queue
每个react 结点都有2个fiber链表，一个叫current fiber，一个叫alternate fiber，而每个链表又对应两个updateQueue。 而currentFiber.alternate = alternateFiber; alternateFiber.alternate = currentFiber。通过alternate属性连接起来。初始化的时候，alternate fiber是current fiber 的clone。 处理diff的时候，操作的是alternateFiber，处理完diff，让currentFiber = alternateFiber；这样一个处理就完成了。
scheduleWork
scheduleWork会更新每个节点的优先级，然后循环到root，以后的操作都从root开始遍历。
- expirationTime 优先级 expirationTime 不为 1 的时候，则其值越低，优先级越高。
{
NoWork: 0, // No work is pending.
SynchronousPriority: 1, // For controlled text inputs. Synchronous side-effects.
AnimationPriority: 2, // Needs to complete before the next frame.
HighPriority: 3, // Interaction that needs to complete pretty soon to feel responsive.
LowPriority: 4, // Data fetching, or result from updating stores.
OffscreenPriority: 5, // Won''t be visible but do the work in case it becomes visible.
};
function scheduleWork(fiber: Fiber, expirationTime: ExpirationTime) {
return scheduleWorkImpl(fiber, expirationTime, false);
}
function scheduleWorkImpl(
fiber: Fiber,
expirationTime: ExpirationTime,
isErrorRecovery: boolean,
) {
recordScheduleUpdate(); // 记录更新，实际啥也没干
let node = fiber;
while (node !== null) {
// Walk the parent path to the root and update each node''s
// expiration time.
// 更新每个node的优先级
if (
node.expirationTime === NoWork ||
node.expirationTime > expirationTime
) {
node.expirationTime = expirationTime;
}
if (node.alternate !== null) {
if (
node.alternate.expirationTime === NoWork ||
node.alternate.expirationTime > expirationTime
) {
node.alternate.expirationTime = expirationTime;
}
}
if (node.return === null) {
if (node.tag === HostRoot) {
const root: FiberRoot = (node.stateNode: any);
if (
!isWorking &&
nextRenderExpirationTime !== NoWork &&
expirationTime < nextRenderExpirationTime
) {
// This is an interruption. (Used for performance tracking.)
interruptedBy = fiber;
resetStack();
}
if (
// If we''re in the render phase, we don''t need to schedule this root
// for an update, because we''ll do it before we exit...
!isWorking ||
isCommitting ||
// ...unless this is a different root than the one we''re rendering.
nextRoot !== root
) {
// Add this root to the root schedule.
requestWork(root, expirationTime);
}
} else {
}
return;
}
}
node = node.return;
}
}
requestWork
同步执行performSyncWork，异步执行scheduleCallbackWithExpiration， scheduleCallbackWithExpiration会调浏览器的requestidlecallback，在浏览器空闲的时候进行处理。 react还对这个api做了polyfill
function requestWork(root: FiberRoot, expirationTime: ExpirationTime) {
if (isRendering) {
return;
}
if (isBatchingUpdates) { // 这里是BatchingUpdates的处理。
// Flush work at the end of the batch.
if (isUnbatchingUpdates) {
// ...unless we''re inside unbatchedUpdates, in which case we should
// flush it now.
nextFlushedRoot = root;
nextFlushedExpirationTime = Sync;
performWorkOnRoot(root, Sync, false);
}
return;
}
if (expirationTime === Sync) {
performSyncWork();
} else {
scheduleCallbackWithExpiration(expirationTime);
}
}
performSyncWork 主要的任务调度
这里会找到高优任务先执行。 同步任务会直接调用performWorkOnRoot进行下一步， 异步任务也会调performWorkOnRoot，但处理不太一样 如果有上次遗留的任务，留到空闲时运行
function performSyncWork() {
performWork(Sync, false, null);
}
function performWork(
minExpirationTime: ExpirationTime,
isAsync: boolean,
dl: Deadline | null,
) {
deadline = dl;
findHighestPriorityRoot();
if (isAsync) {
while (
nextFlushedRoot !== null &&
nextFlushedExpirationTime !== NoWork &&
(minExpirationTime === NoWork ||
minExpirationTime >= nextFlushedExpirationTime) &&
(!deadlineDidExpire ||
recalculateCurrentTime() >= nextFlushedExpirationTime)
) {
performWorkOnRoot(
nextFlushedRoot,
nextFlushedExpirationTime,
!deadlineDidExpire,
);
findHighestPriorityRoot();
}
} else {
while (
nextFlushedRoot !== null &&
nextFlushedExpirationTime !== NoWork &&
(minExpirationTime === NoWork ||
minExpirationTime >= nextFlushedExpirationTime)
) {
performWorkOnRoot(nextFlushedRoot, nextFlushedExpirationTime, false);
findHighestPriorityRoot();
}
}
if (deadline !== null) {
callbackExpirationTime = NoWork;
callbackID = -1;
}
// If there''s work left over, schedule a new callback.
if (nextFlushedExpirationTime !== NoWork) {
scheduleCallbackWithExpiration(nextFlushedExpirationTime);
}
// Clean-up.
deadline = null;
deadlineDidExpire = false;
finishRendering();
}
performWorkOnRoot (异步任务和同步任务的异同)
如果有上次遗留，直接调用completeRoot进到渲染阶段。如果没有就调renderRoot开始reconcilation阶段。 异步任务主要是渲染的时候判断一下时间，如果没时间了，先把finishedWork赋给全局，下次循环处理。
function performWorkOnRoot(
root: FiberRoot,
expirationTime: ExpirationTime,
isAsync: boolean,
) {
isRendering = true;
// Check if this is async work or sync/expired work.
if (!isAsync) {
// Flush sync work.
let finishedWork = root.finishedWork;
if (finishedWork !== null) {
// This root is already complete. We can commit it.
completeRoot(root, finishedWork, expirationTime);
} else {
root.finishedWork = null;
finishedWork = renderRoot(root, expirationTime, false);
if (finishedWork !== null) {
// We''ve completed the root. Commit it.
completeRoot(root, finishedWork, expirationTime);
}
}
} else {
// Flush async work.
let finishedWork = root.finishedWork;
if (finishedWork !== null) {
// This root is already complete. We can commit it.
completeRoot(root, finishedWork, expirationTime);
} else {
root.finishedWork = null;
finishedWork = renderRoot(root, expirationTime, true);
if (finishedWork !== null) {
// We''ve completed the root. Check the deadline one more time
// before committing.
if (!shouldYield()) {
// Still time left. Commit the root.
completeRoot(root, finishedWork, expirationTime);
} else {
// There''s no time left. Mark this root as complete. We''ll come
// back and commit it later.
root.finishedWork = finishedWork;
}
}
}
}
isRendering = false;
}
renderRoot
如果是第一次进入，会创建一个nextUnitOfWork。 nextUnitOfWork是每个工作的粒度。 然后调用workLoop
function renderRoot(
root: FiberRoot,
expirationTime: ExpirationTime,
isAsync: boolean,
): Fiber | null {
isWorking = true;
// Check if we''re starting from a fresh stack, or if we''re resuming from
// previously yielded work.
if (
expirationTime !== nextRenderExpirationTime ||
root !== nextRoot ||
nextUnitOfWork === null
) {
// Reset the stack and start working from the root.
resetStack();
nextRoot = root;
nextRenderExpirationTime = expirationTime;
nextUnitOfWork = createWorkInProgress(
nextRoot.current,
null,
nextRenderExpirationTime,
);
root.pendingCommitExpirationTime = NoWork;
}
let didFatal = false;
startWorkLoopTimer(nextUnitOfWork);
do {
try {
workLoop(isAsync);
} catch (thrownValue) {
// ...
}
break;
} while (true);
// We''re done performing work. Time to clean up.
// ...
}
workLoop
异步任务在处理的时候会调用shouldYield，shouldYield会判断是不是已经超时了，超时暂时先不做。
function workLoop(isAsync) {
if (!isAsync) {
// Flush all expired work.
while (nextUnitOfWork !== null) {
nextUnitOfWork = performUnitOfWork(nextUnitOfWork);
}
} else {
// Flush asynchronous work until the deadline runs out of time.
while (nextUnitOfWork !== null && !shouldYield()) {
nextUnitOfWork = performUnitOfWork(nextUnitOfWork);
}
}
}
function shouldYield() {
if (deadline === null) {
return false;
}
if (deadline.timeRemaining() > timeHeuristicForUnitOfWork) {
// Disregard deadline.didTimeout. Only expired work should be flushed
// during a timeout. This path is only hit for non-expired work.
return false;
}
deadlineDidExpire = true;
return true;
}
performUnitOfWork （reconcilation阶段）
reconcilation又分两步 1是beginWork，beginWork会开始处理组件，针对不同组件不同处理。包括dom diff 2 是completeUnitOfWork，completeUnitOfWork会对begin work产生的effect list进行一些处理。
function performUnitOfWork(workInProgress: Fiber): Fiber | null {
const current = workInProgress.alternate;
startWorkTimer(workInProgress);
let next = beginWork(current, workInProgress, nextRenderExpirationTime);
if (next === null) {
next = completeUnitOfWork(workInProgress);
}
ReactCurrentOwner.current = null;
return next;
}
beginWork
主要是对react 组件进行一些操作。和调用一些生命周期， 我们主要关注classComponent，就是react的组件 HostConponent在浏览器下就是dom
function beginWork(
current: Fiber | null,
workInProgress: Fiber,
renderExpirationTime: ExpirationTime,
): Fiber | null {
if (
workInProgress.expirationTime === NoWork ||
workInProgress.expirationTime > renderExpirationTime
) {
return bailoutOnLowPriority(current, workInProgress);
}
switch (workInProgress.tag) {
case FunctionalComponent:
return updateFunctionalComponent(current, workInProgress);
case ClassComponent:
return updateClassComponent(
current,
workInProgress,
renderExpirationTime,
);
case HostRoot:
return updateHostRoot(current, workInProgress, renderExpirationTime);
case HostComponent:
return updateHostComponent(
current,
workInProgress,
renderExpirationTime,
);
case HostText:
return updateHostText(current, workInProgress);
case ForwardRef:
return updateForwardRef(current, workInProgress);
case Fragment:
return updateFragment(current, workInProgress);
case Mode:
return updateMode(current, workInProgress);
case ContextProvider:
return updateContextProvider(
current,
workInProgress,
renderExpirationTime,
);
case ContextConsumer:
return updateContextConsumer(
current,
workInProgress,
renderExpirationTime,
);
default:
invariant(
false,
''Unknown unit of work tag. This error is likely caused by a bug in '' +
''React. Please file an issue.'',
);
}
}
updateClassComponent
mount组件，构建组件实例，调用生命周期比如willMount，初始化组件的的updateQueue。
- updateClassInstance中，如果props不一致,会调willReceiveProps方法，然后checkShouldCompoentUpdate，也就是 shouldCompoentUpdate。
- finishClassComponent中，会判断之前的shouldUpdate，如果是true就要调用组件的render，产出children，然后对children进行dom diff。
function updateClassComponent(
current: Fiber | null,
workInProgress: Fiber,
renderExpirationTime: ExpirationTime,
) {
// Push context providers early to prevent context stack mismatches.
// During mounting we don''t know the child context yet as the instance doesn''t exist.
// We will invalidate the child context in finishClassComponent() right after rendering.
const hasContext = pushLegacyContextProvider(workInProgress);
let shouldUpdate;
if (current === null) {
if (workInProgress.stateNode === null) {
// In the initial pass we might need to construct the instance.
constructClassInstance(workInProgress, workInProgress.pendingProps);
mountClassInstance(workInProgress, renderExpirationTime);
shouldUpdate = true;
} else {
// In a resume, we''ll already have an instance we can reuse.
shouldUpdate = resumeMountClassInstance(
workInProgress,
renderExpirationTime,
);
}
} else {
shouldUpdate = updateClassInstance(
current,
workInProgress,
renderExpirationTime,
);
}
let didCaptureError = false;
const updateQueue = workInProgress.updateQueue;
if (updateQueue !== null && updateQueue.capturedValues !== null) {
shouldUpdate = true;
didCaptureError = true;
}
return finishClassComponent(
current,
workInProgress,
shouldUpdate,
hasContext,
didCaptureError,
renderExpirationTime,
);
}
reconcileChildFibers （virtul dom diff）
finishClassComponent会调用reconcileChildFibers进行dom diff。
function reconcileChildFibers(
returnFiber: Fiber,
currentFirstChild: Fiber | null,
newChild: any,
expirationTime: ExpirationTime,
): Fiber | null {
if (
typeof newChild === ''object'' &&
newChild !== null &&
newChild.type === REACT_FRAGMENT_TYPE &&
newChild.key === null
) {
newChild = newChild.props.children;
}
// Handle object types
const isObject = typeof newChild === ''object'' && newChild !== null;
if (isObject) {
switch (newChild.$$typeof) {
case REACT_ELEMENT_TYPE:
return placeSingleChild(
reconcileSingleElement(
returnFiber,
currentFirstChild,
newChild,
expirationTime,
),
);
case REACT_PORTAL_TYPE:
return placeSingleChild(
reconcileSinglePortal(
returnFiber,
currentFirstChild,
newChild,
expirationTime,
),
);
}
}
if (typeof newChild === ''string'' || typeof newChild === ''number'') {
return placeSingleChild(
reconcileSingleTextNode(
returnFiber,
currentFirstChild,
'''' + newChild,
expirationTime,
),
);
}
if (isArray(newChild)) {
return reconcileChildrenArray(
returnFiber,
currentFirstChild,
newChild,
expirationTime,
);
}
if (getIteratorFn(newChild)) {
return reconcileChildrenIterator(
returnFiber,
currentFirstChild,
newChild,
expirationTime,
);
}
}
reconcileChildrenArray
大部分情况是reconcileChildrenArray，就那这个来说。
function reconcileChildrenArray(
returnFiber: Fiber,
currentFirstChild: Fiber | null,
newChildren: Array<*>,
expirationTime: ExpirationTime,
): Fiber | null {
let resultingFirstChild: Fiber | null = null;
let previousNewFiber: Fiber | null = null;
let oldFiber = currentFirstChild;
let lastPlacedIndex = 0;
let newIdx = 0;
let nextOldFiber = null;
for (; oldFiber !== null && newIdx < newChildren.length; newIdx++) {
// 没有采用两端同时对比，受限于Fiber列表的单向结构
if (oldFiber.index > newIdx) {
nextOldFiber = oldFiber;
oldFiber = null;
} else {
nextOldFiber = oldFiber.sibling;
}
const newFiber = updateSlot( // 生成新的fiber
returnFiber,
oldFiber,
newChildren[newIdx],
expirationTime,
);
//如果在遍历中发现key值不相等的情况，则直接跳出第一轮遍历
if (newFiber === null) {
if (oldFiber === null) {
oldFiber = nextOldFiber;
}
break;
}
if (shouldTrackSideEffects) {
if (oldFiber && newFiber.alternate === null) {
// 我们找到了匹配的节点，但我们并不保留当前的Fiber,所以我们需要删除当前的子节点
// We matched the slot, but we didn''t reuse the existing fiber, so we
// need to delete the existing child.
deleteChild(returnFiber, oldFiber);
}
}
lastPlacedIndex = placeChild(newFiber, lastPlacedIndex, newIdx);
// 记录上一个更新的子节点
if (previousNewFiber === null) {
resultingFirstChild = newFiber;
} else {
previousNewFiber.sibling = newFiber;
}
previousNewFiber = newFiber;
oldFiber = nextOldFiber;
}
if (newIdx === newChildren.length) {
// 我们已经遍历完了所有的新节点，直接删除剩余旧节点
// We''ve reached the end of the new children. We can delete the rest.
deleteRemainingChildren(returnFiber, oldFiber);
return resultingFirstChild;
}
if (oldFiber === null) {
// 如果旧节点先遍历完，则按顺序插入剩余的新节点
// If we don''t have any more existing children we can choose a fast path
// since the rest will all be insertions.
for (; newIdx < newChildren.length; newIdx++) {
const newFiber = createChild(
returnFiber,
newChildren[newIdx],
expirationTime,
);
if (!newFiber) {
continue;
}
lastPlacedIndex = placeChild(newFiber, lastPlacedIndex, newIdx);
if (previousNewFiber === null) {
// TODO: Move out of the loop. This only happens for the first run.
resultingFirstChild = newFiber;
} else {
previousNewFiber.sibling = newFiber;
}
previousNewFiber = newFiber;
}
return resultingFirstChild;
}
// 把子节点都设置快速查找的map映射集
const existingChildren = mapRemainingChildren(returnFiber, oldFiber);
// 使用map查找需要保存或删除的节点
for (; newIdx < newChildren.length; newIdx++) {
const newFiber = updateFromMap(
existingChildren,
returnFiber,
newIdx,
newChildren[newIdx],
expirationTime,
);
if (newFiber) {
if (shouldTrackSideEffects) {
if (newFiber.alternate !== null) {
// 新的Fiber也是一个工作线程，但是如果已有当前的实例，那我们就可以复用这个Fiber,
// 我们要从Map中删除这个新的，避免准备复用的Fiber被删除
existingChildren.delete(
newFiber.key === null ? newIdx : newFiber.key,
);
}
}
lastPlacedIndex = placeChild(newFiber, lastPlacedIndex, newIdx);
if (previousNewFiber === null) {
resultingFirstChild = newFiber;
} else {
previousNewFiber.sibling = newFiber;
}
previousNewFiber = newFiber;
}
}
if (shouldTrackSideEffects) {
// Any existing children that weren''t consumed above were deleted. We need
// to add them to the deletion list.
// 到此所有剩余的Map的节点都将被删除，加入删除队列
existingChildren.forEach(child => deleteChild(returnFiber, child));
}
// 最终返回Fiber子节点列表的第一个节点
return resultingFirstChild;
}
可以看到其实删除节点并不是直接删除而是打个Deletion的tag。生成effect list
function deleteChild(returnFiber: Fiber, childToDelete: Fiber): void {
const last = returnFiber.lastEffect;
if (last !== null) {
last.nextEffect = childToDelete;
returnFiber.lastEffect = childToDelete;
} else {
returnFiber.firstEffect = returnFiber.lastEffect = childToDelete;
}
childToDelete.nextEffect = null;
childToDelete.effectTag = Deletion;
}
completeUnitOfWork
在dom diff之后会有一个收尾工作大概就是effect的各种处理，就是workLoop之后的completeUnitOfWork函数。 同步effect list到 current 的host root 树。 调用completeWork
function completeUnitOfWork(workInProgress: Fiber): Fiber | null {
while (true) {
const current = workInProgress.alternate;
const returnFiber = workInProgress.return;
const siblingFiber = workInProgress.sibling;
if ((workInProgress.effectTag & Incomplete) === NoEffect) {
// This fiber completed.
let next = completeWork(
current,
workInProgress,
nextRenderExpirationTime,
);
stopWorkTimer(workInProgress);
resetExpirationTime(workInProgress, nextRenderExpirationTime);
if (next !== null) {
stopWorkTimer(workInProgress);
if (__DEV__ && ReactFiberInstrumentation.debugTool) {
ReactFiberInstrumentation.debugTool.onCompleteWork(workInProgress);
}
// If completing this work spawned new work, do that next. We''ll come
// back here again.
return next;
}
// 将当前fiber子树上的effect list 插入到当前hostRoot 树的effectlist中
if (
returnFiber !== null &&
// Do not append effects to parents if a sibling failed to complete
(returnFiber.effectTag & Incomplete) === NoEffect
) {
// Append all the effects of the subtree and this fiber onto the effect
// list of the parent. The completion order of the children affects the
// side-effect order.
if (returnFiber.firstEffect === null) {
returnFiber.firstEffect = workInProgress.firstEffect;
}
if (workInProgress.lastEffect !== null) {
if (returnFiber.lastEffect !== null) {
returnFiber.lastEffect.nextEffect = workInProgress.firstEffect;
}
returnFiber.lastEffect = workInProgress.lastEffect;
}
// If this fiber had side-effects, we append it AFTER the children''s
// side-effects. We can perform certain side-effects earlier if
// needed, by doing multiple passes over the effect list. We don''t want
// to schedule our own side-effect on our own list because if end up
// reusing children we''ll schedule this effect onto itself since we''re
// at the end.
const effectTag = workInProgress.effectTag;
// Skip both NoWork and PerformedWork tags when creating the effect list.
// PerformedWork effect is read by React DevTools but shouldn''t be committed.
if (effectTag > PerformedWork) {
if (returnFiber.lastEffect !== null) {
returnFiber.lastEffect.nextEffect = workInProgress;
} else {
returnFiber.firstEffect = workInProgress;
}
returnFiber.lastEffect = workInProgress;
}
}
if (siblingFiber !== null) {
// If there is more work to do in this returnFiber, do that next.
return siblingFiber;
} else if (returnFiber !== null) {
// If there''s no more work in this returnFiber. Complete the returnFiber.
workInProgress = returnFiber;
continue;
} else {
// We''ve reached the root.
isRootReadyForCommit = true;
return null;
}
} else {
// This fiber did not complete because something threw. Pop values off
// the stack without entering the complete phase. If this is a boundary,
// capture values if possible.
const next = unwindWork(workInProgress);
// Because this fiber did not complete, don''t reset its expiration time.
if (workInProgress.effectTag & DidCapture) {
// Restarting an error boundary
stopFailedWorkTimer(workInProgress);
} else {
stopWorkTimer(workInProgress);
}
if (next !== null) {
stopWorkTimer(workInProgress);
if (__DEV__ && ReactFiberInstrumentation.debugTool) {
ReactFiberInstrumentation.debugTool.onCompleteWork(workInProgress);
}
// If completing this work spawned new work, do that next. We''ll come
// back here again.
// Since we''re restarting, remove anything that is not a host effect
// from the effect tag.
next.effectTag &= HostEffectMask;
return next;
}
if (returnFiber !== null) {
// Mark the parent fiber as incomplete and clear its effect list.
returnFiber.firstEffect = returnFiber.lastEffect = null;
returnFiber.effectTag |= Incomplete;
}
if (siblingFiber !== null) {
// If there is more work to do in this returnFiber, do that next.
return siblingFiber;
} else if (returnFiber !== null) {
// If there''s no more work in this returnFiber. Complete the returnFiber.
workInProgress = returnFiber;
continue;
} else {
return null;
}
}
}
return null;
}
completeWork
比较长，不贴代码了。主要做的事情就是根据不同的component类型进行不同的处理。 重点是对HostComponent的props进行diff，并标记更新。 如果是react首次渲染，调用createInstance创建一个HostComponent。 如果已经存在HostComponent，检查节点是否需要更新，调用prepareUpdate，进行diff dom属性。
到此reconciliation阶段结束，主要负责产出effect list。 可以说reconcile的过程相当于是一个纯函数，输入是fiber节点，输出一个effect list。
因为纯函数的可预测性，让我们可以随时中断reconciliation阶段的执行，而不用担心side-effects给让组件状态和实际UI产生不一致
渲染阶段 completeRoot/commitRoot
function commitRoot(finishedWork: Fiber): ExpirationTime {
isWorking = true;
isCommitting = true;
startCommitTimer();
const root: FiberRoot = finishedWork.stateNode;
const committedExpirationTime = root.pendingCommitExpirationTime;
root.pendingCommitExpirationTime = NoWork;
const currentTime = recalculateCurrentTime();
// Reset this to null before calling lifecycles
ReactCurrentOwner.current = null;
let firstEffect;
if (finishedWork.effectTag > PerformedWork) {
// fiber的effect list只包括它子树中的effects，将节点的effect加到effect list链表中
if (finishedWork.lastEffect !== null) {
finishedWork.lastEffect.nextEffect = finishedWork;
firstEffect = finishedWork.firstEffect;
} else {
firstEffect = finishedWork;
}
} else {
// There is no effect on the root.
firstEffect = finishedWork.firstEffect;
}
// 做一些dom事件相关设置
prepareForCommit(root.containerInfo);
// Commit all the side-effects within a tree. We''ll do this in two passes.
// The first pass performs all the host insertions, updates, deletions and
// ref unmounts.
nextEffect = firstEffect;
startCommitHostEffectsTimer();
while (nextEffect !== null) {
let didError = false;
let error;
try {
// 遍历fiber树的effect list，调用相关的生命周期，比如willUnmount。操作dom，完成渲染。
commitAllHostEffects();
} catch (e) {
didError = true;
error = e;
}
}
stopCommitHostEffectsTimer();
resetAfterCommit(root.containerInfo);
root.current = finishedWork;
nextEffect = firstEffect;
startCommitLifeCyclesTimer();
while (nextEffect !== null) {
let didError = false;
let error;
try {
// 再遍历effect list，如果effect发生在classComponent上，加调didMount和didUpdate方法。
// 如果发生在hostComponents上，会调用commitMount方法，主要是为了在render一个节点渲染之后做一些操作。比如input的auto-focus。
commitAllLifeCycles(root, currentTime, committedExpirationTime);
} catch (e) {
didError = true;
error = e;
}
}
isCommitting = false;
isWorking = false;
stopCommitLifeCyclesTimer();
stopCommitTimer();
if (typeof onCommitRoot === ''function'') {
onCommitRoot(finishedWork.stateNode);
}
const remainingTime = root.current.expirationTime;
if (remainingTime === NoWork) {
// If there''s no remaining work, we can clear the set of already failed
// error boundaries.
legacyErrorBoundariesThatAlreadyFailed = null;
}
return remainingTime;
}
create-react-app搭配react16+ts+less
脚手架默认不支持less
create-react-app创建ts类型的react项目
// 全局安装脚手架工具
npm install -g create-react-app
// 使用脚手架创建react项目
npx create-react-app demo --template typescript
项目中，你写less，并引入tsx中，如下
import React from ''react'';
import style from ''./style.less'';
const Login = () => {
return (
<div className={style.Login}>登录</div>
);
}
export default Login;.Login {
color: red;
}
添加less的全局类型声明，编译阶段不报错
你会发现，导入less时如果被提示找不到模块xxx.less,需要在项目的根路径文件react-app-env.d.ts（理论上，只要定义全局类型声明就行，非本文件也行）中，添加一下内容
declare module "*.less" {
const less: any;
export default less;
}如果是tsx，即非ts的react项目，忽略此步骤
安装webpack对应的less支持
安装对应的包
npm install less-loader --save-dev配置webpack对less支持
运行npm run eject暴漏webpack的配置文件config/webpack.config.js
在第50行配置如下：
//添加如下支持less配置代码
const lessRegex = /\.less$/;
const lessModuleRegex = /\.module\.less$/;在第500行添加如下代码：
{
test: lessRegex,
exclude: lessModuleRegex,
use: getStyleLoaders(
{
importLoaders: 2,
// modules: true, 如果仅打开cssModule 那么原类名 将会没有前缀，无法与自己的样式类名关联，所以下边做法可取
modules:{
localIdentName: ''[local]_[hash:base64:5]'',
},
sourceMap: isEnvProduction && shouldUseSourceMap,
},
''less-loader''
),
sideEffects: true,
},
{
test: lessModuleRegex,
use: getStyleLoaders(
{
importLoaders: 2,
sourceMap: isEnvProduction && shouldUseSourceMap,
modules: true,
getLocalIdent: getCSSModuleLocalIdent,
},
''less-loader''
),
},
Egg + React (React Router + Redux) (SSR) 服务端渲染实际
概述
在实现 Egg + React 服务端渲染解决方案 egg-react-webpack-boilerplate 时，因在 React + React Router + Redux 方面没有深入的实践过以及精力问题， 只实现了多页面服务端渲染方案。最近收到社区的一些咨询，想知道 Egg + React Router + Redux 如何实现 SPA 同构实现。如是就开始了 Egg + React Router + Redux 的摸索之路，实践过程中遇到 React-Router 版本问题，Redux 使用问题等问题，折腾了几天，但最终还是把想要的方案实践出来。
摸索阶段
在查阅 react router 和 redux 的相关资料，发现 react router 有 V3 和 V4 版本， V4 新版本又分为 react-router，react-router-dom，react-router-config，react-router-redux 插件， redux 相关的有 redux，react-redux，只能硬着头皮一个一个看看啥含义，看一下简单的Todo例子， 相比 Vue 的 vuex + vue-router 的工程搭建过程，这个要复杂的多，只好采用分阶段完成。先完成了纯前端渲染的 React Router + Redux 结合的例子，把 React Router 和 Redux 的相关 API 撸了一遍，基本掌握 React-Redux actions, reducer, store使用(这里自己先通过简单的例子让整个流程跑通，然后逐渐添砖加瓦，实现自己想要的功能. 比如不考虑异步，不考虑数据请求，直接hack数据，跑通后，再逐渐改造完善）。
依赖说明
react router(v4)
react-router |
React Router 核心 |
|---|---|
react-router-dom |
用于 DOM 绑定的 React Router |
react-router-native |
用于 React Native 的 React Router |
react-router-redux |
React Router 和 Redux 的集成 |
react-router-config |
静态路由配置辅助 |
// 客户端用BrowserRouter， 服务端渲染用 StaticRouter 静态路由组件 import { BrowserRouter, StaticRouter } from ''react-router-dom'';
redux 和 react-redux
这里直接借个图(https://segmentfault.com/a/1190000011473973)：
Redux 介绍
Redux 是 javaScript 状态管理容器
通过 Redux 可以很方便进行数据集中管理和实现组件之间的通信，同时视图和数据逻辑分离，对于大型复杂(业务复杂，交互复杂，数据交互频繁等)的 React 项目， Redux 能够让代码结构(数据查询状态、数据改变状态、数据传播状态)层次更合理。另外，Redux 和 React 之间没有关系。Redux 支持 React、Angular、jQuery 甚至纯 JavaScript。
Redux 的设计思想很简单
Redux是在借鉴Flux思想上产生的，基本思想是保证数据的单向流动，同时便于控制、使用、测试
- Web 应用是一个状态机，视图与状态是一一对应的。
- 所有的状态，保存在一个对象里面,也就是单一数据源
Redux 核心由三部分组成：Store, Action, Reducer。
- Store : 贯穿你整个应用的数据都应该存储在这里。
// component/spa/ssr/actions 创建store，初始化store数据 export function create(initalState){ return createStore(reducers, initalState); }
- Action： 必须包含type这个属性，reducer将根据这个属性值来对store进行相应的处理。除此之外的属性，就是进行这个操作需要的数据。
// component/spa/ssr/actions export function add(item) { return { type: ADD, item } } export function del(id) { return { type: DEL, id } }
- Reducer: 是个函数。接受两个参数：要修改的数据(state) 和 action对象。根据action.type来决定采用的操作，对state进行修改，最后返回新的state。
// component/spa/ssr/reducers export default function update(state, action) { const newState = Object.assign({}, state); if (action.type === ADD) { const list = Array.isArray(action.item) ? action.item : [action.item]; newState.list = [...newState.list, ...list]; } else if (action.type === DEL) { newState.list = newState.list.filter(item => { return item.id !== action.id; }); } else if (action.type === LIST) { newState.list = action.list; } return newState }
redux 使用
// store的创建 var createStore = require(''redux'').createStore; var store = createStore(update); // store 里面的数据发生改变时，触发的回调函数 store.subscribe(function () { console.log(''the state:'', store.getState()); }); // action触发state改变的唯一方法, 改变store里面的方法 store.dispatch(add({id:1, title:''redux''})); store.dispatch(del(1));
react-redux
react-redux 对 redux 流程的一种简化，可以简化手动 dispatch 繁琐过程。 react-redux 重要提供以下两个API，详细介绍请见：http://cn.redux.js.org/docs/react-redux/api.html
- connect(mapStateToProps, mapDispatchToProps, mergeToProps)(App)
- provider
更多信息请参考 http://cn.redux.js.org/
服务端渲染同构实现
页面模板实现
- home.jsx
// component/spa/ssr/components/home.jsx import React, { Component } from ''react'' import { connect } from ''react-redux'' import { add, del } from ''component/spa/ssr/actions''; class Home extends Component { // 服务端渲染调用，这里mock数据，实际请改为服务端数据请求 static fetch() { return Promise.resolve({ list:[{ id: 0, title: `Egg+React 服务端渲染骨架`, summary: ''基于Egg + React + Webpack3/Webpack2 服务端渲染同构工程骨架项目'', hits: 550, url: ''https://github.com/hubcarl/egg-react-webpack-boilerplate'' }, { id: 1, title: ''前端工程化解决方案easywebpack'', summary: ''programming instead of configuration, webpack is so easy'', hits: 550, url: ''https://github.com/hubcarl/easywebpack'' }, { id: 2, title: ''前端工程化解决方案脚手架easywebpack-cli'', summary: ''easywebpack command tool, support init Vue/Reac/Weex boilerplate'', hits: 278, url: ''https://github.com/hubcarl/easywebpack-cli'' }] }).then(data => { return data; }) } render() { const { add, del, list } = this.props; const id = list.length + 1; const item = { id, title: `Egg+React 服务端渲染骨架-${id}`, summary: ''基于Egg + React + Webpack3/Webpack2 服务端渲染骨架项目'', hits: 550 + id, url: ''https://github.com/hubcarl/egg-react-webpack-boilerplate'' }; return <div className="redux-nav-item"> <h3>SPA Server Side</h3> <div className="container"> <div className="row row-offcanvas row-offcanvas-right"> <div className="col-xs-12 col-sm-9"> <ul className="smart-artiles" id="articleList"> {list.map(function(item) { return <li key={item.id}> <div className="point">+{item.hits}</div> <div className="card"> <h2><a href={item.url} target="_blank">{item.title}</a></h2> <div> <ul className="actions"> <li> <time className="timeago">{item.moduleName}</time> </li> <li className="tauthor"> <a href="#" target="_blank" className="get">Sky</a> </li> <li><a>+收藏</a></li> <li> <span className="timeago">{item.summary}</span> </li> <li> <span className="redux-btn-del" onClick={() => del(item.id)}>Delete</span> </li> </ul> </div> </div> </li>; })} </ul> </div> </div> </div> <div className="redux-btn-add" onClick={() => add(item)}>Add</div> </div>; } } function mapStateToProps(state) { return { list: state.list } } export default connect(mapStateToProps, { add, del })(Home)
- about.jsx
// component/spa/ssr/components/about.jsx import React, { Component } from ''react'' export default class About extends Component { render() { return <h3 className="spa-title">React+Redux+React Router SPA Server Side Render Example</h3>; } }
react-router 路由定义
// component/spa/ssr/ssr import { connect } from ''react-redux'' import { BrowserRouter, Route, Link, Switch } from ''react-router-dom'' import Home from ''component/spa/ssr/components/home''; import About from ''component/spa/ssr/components/about''; import { Menu, Icon } from ''antd''; const tabKey = { ''/spa/ssr'': ''home'', ''/spa/ssr/about'': ''about'' }; class App extends Component { constructor(props) { super(props); const { url } = props; this.state = { current: tabKey[url] }; } handleClick(e) { console.log(''click '', e, this.state); this.setState({ current: e.key, }); }; render() { return <div> <Menu onClick={this.handleClick.bind(this)} selectedKeys={[this.state.current]} mode="horizontal"> <Menu.Item key="home"> <Link to="/spa/ssr">SPA-Redux-Server-Side-Render</Link> </Menu.Item> <Menu.Item key="about"> <Link to="/spa/ssr/about">About</Link> </Menu.Item> </Menu> <Switch> <Route path="/spa/ssr/about" component={About}/> <Route path="/spa/ssr" component={Home}/> </Switch> </div>; } } export default App;
SPA前端渲染同构实现
import React, { Component } from ''react'' import ReactDOM from ''react-dom'' import { Provider } from ''react-redux'' import {match, RouterContext} from ''react-router'' import { BrowserRouter, StaticRouter } from ''react-router-dom''; import { matchRoutes, renderRoutes } from ''react-router-config'' import Header from ''component/layout/standard/header/header''; import SSR from ''component/spa/ssr/ssr''; import { create } from ''component/spa/ssr/store''; import routes from ''component/spa/ssr/routes'' const store = create(window.__INITIAL_STATE__); const url = store.getState().url; ReactDOM.render( <div> <Header></Header> <Provider store={ store }> <BrowserRouter> <SSR url={ url }/> </BrowserRouter> </Provider> </div>, document.getElementById(''app'') );
SPA服务端渲染同构实现
在服务端渲染时，这里纠结了一下，遇到两个问题
- 参考一些资料的写法Node服务端都是在路由里面处理的，写起来好别扭, 希望 render时
- ReactDOMServer.renderToString(ReactElement) 参数必须是ReactElement
- 组件异步获取的数据Node render怎么获取到
这里通过函数回调的方式可以解决上面问题，也就是 export 出去的是一个函数，然后 render 判断是否直接renderToString还是调用函数，然后再进行renderToString。目前在 egg-view-react-ssr 做了一层简单判断，代码如下：
app.react.renderElement = (reactElement, locals, options) => { if (reactElement.prototype && reactElement.prototype.isReactComponent) { return Promise.resolve(app.react.renderToString(reactElement, locals)); } const context = { state: locals }; return reactElement(context, options).then(element => { return app.react.renderToString(element, context.state); }); }
这样处理了以后，Node 服务端controller处理时就无需自己处理路由匹配问题和store问题，全部交给底层处理。现在的这种处理方式与Vue服务端渲染render思路一致，把服务端逻辑写到模板文件里面，然后由Webpack构建js文件。
SPA服务端渲染入口文件
Webpack 构建的文件 app/ssr.js 到 app/view 目录
import React, { Component } from ''react'' import ReactDOM from ''react-dom'' import { Provider } from ''react-redux'' import {match, RouterContext} from ''react-router'' import { BrowserRouter, StaticRouter } from ''react-router-dom''; import { matchRoutes, renderRoutes } from ''react-router-config'' import Header from ''component/layout/standard/header/header''; import SSR from ''component/spa/ssr/ssr''; import { create } from ''component/spa/ssr/store''; import routes from ''component/spa/ssr/routes'' // context 为服务端初始化数据 export default function(context, options) { const url = context.state.url; // 根据服务端url地址找到匹配的组件 const branch = matchRoutes(routes, url); // 收集组件数据 const promises = branch.map(({route}) => { const fetch = route.component.fetch; return fetch instanceof Function ? fetch() : Promise.resolve(null) }); // 获取组件数据，然后初始化store， 同时返回ReactElement return Promise.all(promises).then(data => { const initState = {}; data.forEach(item => { Object.assign(initState, item); }); context.state = Object.assign({}, context.state, initState); const store = create(initState); return () =>( <div> <Header></Header> <Provider store={store}> <StaticRouter location={url} context={{}}> <SSR url={url}/> </StaticRouter> </Provider> </div> ) }); };
Node服务端controller调用
- controller 实现
exports.ssr = function* (ctx) { yield ctx.render(''spa/ssr.js'', { url: ctx.url }); };
- 路由配置
app.get(''/spa(/.+)?'', app.controller.spa.spa.ssr);
- 效果演示
服务端实现与普通模板渲染调用无差异，写起来简单明了。如果你对 Egg + React 技术敢兴趣，赶快来玩一玩 egg-react-webpack-boilerplate 项目吧！
Egg + React + React Router ＋ Redux 服务端渲染同构实践
概述
在实现 Egg + React 服务端渲染解决方案 egg-react-webpack-boilerplate 时，因在 React + React Router + Redux 方面没有深入的实践过以及精力问题， 只实现了多页面服务端渲染方案。最近收到社区的一些咨询，想知道 Egg + React Router + Redux 如何实现 SPA 同构实现。如是就开始了 Egg + React Router + Redux 的摸索之路，实践过程中遇到 React-Router 版本问题，Redux 使用问题等问题，折腾了几天，但最终还是把想要的方案实践出来。
摸索阶段
在查阅 react router 和 redux 的相关资料，发现 react router 有 V3 和 V4 版本， V4 新版本又分为 react-router，react-router-dom，react-router-config，react-router-redux 插件， redux 相关的有 redux，react-redux，只能硬着头皮一个一个看看啥含义，看一下简单的Todo例子， 相比 Vue 的 vuex + vue-router 的工程搭建过程，这个要复杂的多，只好采用分阶段完成。先完成了纯前端渲染的 React Router + Redux 结合的例子，把 React Router 和 Redux 的相关 API 撸了一遍，基本掌握 React-Redux actions,reducer,store使用(这里自己先通过简单的例子让整个流程跑通，然后逐渐添砖加瓦，实现自己想要的功能. 比如不考虑异步，不考虑数据请求，直接hack数据，跑通后，再逐渐改造完善）。
依赖说明
react router(v4)
react-router |
React Router 核心 |
|---|---|
react-router-dom |
用于 DOM 绑定的 React Router |
react-router-native |
用于 React Native 的 React Router |
react-router-redux |
React Router 和 Redux 的集成 |
react-router-config |
静态路由配置辅助 |
// 客户端用browserRouter， 服务端渲染用 StaticRouter 静态路由组件
import { browserRouter,StaticRouter } from 'react-router-dom';
redux 和 react-redux
这里直接借个图(http://www.jb51.cc/article/p-duyiwrsw-boa.html)：
Redux 介绍
Redux 是 javaScript 状态管理容器
通过 Redux 可以很方便进行数据集中管理和实现组件之间的通信，同时视图和数据逻辑分离，对于大型复杂(业务复杂，交互复杂，数据交互频繁等)的 React 项目， Redux 能够让代码结构(数据查询状态、数据改变状态、数据传播状态)层次更合理。另外，Redux 和 React 之间没有关系。Redux 支持 React、Angular、jQuery 甚至纯 JavaScript。
Redux 的设计思想很简单
Redux是在借鉴Flux思想上产生的，基本思想是保证数据的单向流动，同时便于控制、使用、测试
- Web 应用是一个状态机，视图与状态是一一对应的。
- 所有的状态，保存在一个对象里面,也就是单一数据源
Redux 核心由三部分组成：Store,Action,Reducer。
- Store : 贯穿你整个应用的数据都应该存储在这里。
// component/spa/ssr/actions 创建store，初始化store数据
export function create(initalState){
return createStore(reducers,initalState);
}
- Action： 必须包含type这个属性，reducer将根据这个属性值来对store进行相应的处理。除此之外的属性，就是进行这个操作需要的数据。
// component/spa/ssr/actions
export function add(item) {
return {
type: ADD,item
}
}
export function del(id) {
return {
type: DEL,id
}
}
- Reducer: 是个函数。接受两个参数：要修改的数据(state) 和 action对象。根据action.type来决定采用的操作，对state进行修改，最后返回新的state。
// component/spa/ssr/reducers
export default function update(state,action) {
const newState = Object.assign({},state);
if (action.type === ADD) {
const list = Array.isArray(action.item) ? action.item : [action.item];
newState.list = [...newState.list,...list];
}
else if (action.type === DEL) {
newState.list = newState.list.filter(item => {
return item.id !== action.id;
});
} else if (action.type === LIST) {
newState.list = action.list;
}
return newState
}
redux 使用
// store的创建
var createStore = require('redux').createStore;
var store = createStore(update);
// store 里面的数据发生改变时，触发的回调函数
store.subscribe(function () {
console.log('the state:',store.getState());
});
// action触发state改变的唯一方法,改变store里面的方法
store.dispatch(add({id:1,title:'redux'}));
store.dispatch(del(1));
react-redux
react-redux 对 redux 流程的一种简化，可以简化手动 dispatch 繁琐过程。 react-redux 重要提供以下两个API，详细介绍请见：http://cn.redux.js.org/docs/react-redux/api.html
- connect(mapStatetoProps,mapdispatchToProps,mergetoProps)(App)
- provider
更多信息请参考 http://cn.redux.js.org/
服务端渲染同构实现
页面模板实现
- home.jsx
// component/spa/ssr/components/home.jsx
import React,{ Component } from 'react'
import { connect } from 'react-redux'
import { add,del } from 'component/spa/ssr/actions';
class Home extends Component {
// 服务端渲染调用，这里mock数据，实际请改为服务端数据请求
static fetch() {
return Promise.resolve({
list:[{
id: 0,title: `Egg+React 服务端渲染骨架`,summary: '基于Egg + React + Webpack3/Webpack2 服务端渲染同构工程骨架项目',hits: 550,url: 'https://github.com/hubcarl/egg-react-webpack-boilerplate'
},{
id: 1,title: '前端工程化解决方案easywebpack',summary: 'programming instead of configuration,webpack is so easy',url: 'https://github.com/hubcarl/easywebpack'
},{
id: 2,title: '前端工程化解决方案脚手架easywebpack-cli',summary: 'easywebpack command tool,support init Vue/Reac/Weex boilerplate',hits: 278,url: 'https://github.com/hubcarl/easywebpack-cli'
}]
}).then(data => {
return data;
})
}
render() {
const { add,del,list } = this.props;
const id = list.length + 1;
const item = {
id,title: `Egg+React 服务端渲染骨架-${id}`,summary: '基于Egg + React + Webpack3/Webpack2 服务端渲染骨架项目',hits: 550 + id,url: 'https://github.com/hubcarl/egg-react-webpack-boilerplate'
};
return <div className="redux-nav-item">
<h3>SPA Server Side</h3>
<div className="container">
<div className="row row-offcanvas row-offcanvas-right">
<div className="col-xs-12 col-sm-9">
<ul className="smart-artiles" id="articleList">
{list.map(function(item) {
return <li key={item.id}>
<div className="point">+{item.hits}</div>
<div className="card">
<h2><a href={item.url} target="_blank">{item.title}</a></h2>
<div>
<ul className="actions">
<li>
<time className="timeago">{item.moduleName}</time>
</li>
<li className="tauthor">
<a href="#" target="_blank" className="get">Sky</a>
</li>
<li><a>+收藏</a></li>
<li>
<span className="timeago">{item.summary}</span>
</li>
<li>
<span className="redux-btn-del" onClick={() => del(item.id)}>Delete</span>
</li>
</ul>
</div>
</div>
</li>;
})}
</ul>
</div>
</div>
</div>
<div className="redux-btn-add" onClick={() => add(item)}>Add</div>
</div>;
}
}
function mapStatetoProps(state) {
return {
list: state.list
}
}
export default connect(mapStatetoProps,{ add,del })(Home)
- about.jsx
// component/spa/ssr/components/about.jsx
import React,{ Component } from 'react'
export default class About extends Component {
render() {
return <h3 className="spa-title">React+Redux+React Router SPA Server Side Render Example</h3>;
}
}
react-router 路由定义
// component/spa/ssr/ssr
import { connect } from 'react-redux'
import { browserRouter,Route,Link,Switch } from 'react-router-dom'
import Home from 'component/spa/ssr/components/home';
import About from 'component/spa/ssr/components/about';
import { Menu,Icon } from 'antd';
const tabKey = { '/spa/ssr': 'home','/spa/ssr/about': 'about' };
class App extends Component {
constructor(props) {
super(props);
const { url } = props;
this.state = { current: tabKey[url] };
}
handleClick(e) {
console.log('click ',e,this.state);
this.setState({
current: e.key,});
};
render() {
return <div>
<Menu onClick={this.handleClick.bind(this)} selectedKeys={[this.state.current]} mode="horizontal">
<Menu.Item key="home">
<Link to="/spa/ssr">SPA-Redux-Server-Side-Render</Link>
</Menu.Item>
<Menu.Item key="about">
<Link to="/spa/ssr/about">About</Link>
</Menu.Item>
</Menu>
<Switch>
<Route path="/spa/ssr/about" component={About}/>
<Route path="/spa/ssr" component={Home}/>
</Switch>
</div>;
}
}
export default App;
SPA前端渲染同构实现
import React,{ Component } from 'react'
import ReactDOM from 'react-dom'
import { Provider } from 'react-redux'
import {match,RouterContext} from 'react-router'
import { browserRouter,StaticRouter } from 'react-router-dom';
import { matchRoutes,renderRoutes } from 'react-router-config'
import Header from 'component/layout/standard/header/header';
import SSR from 'component/spa/ssr/ssr';
import { create } from 'component/spa/ssr/store';
import routes from 'component/spa/ssr/routes'
const store = create(window.__INITIAL_STATE__);
const url = store.getState().url;
ReactDOM.render(
<div>
<Header></Header>
<Provider store={ store }>
<browserRouter>
<SSR url={ url }/>
</browserRouter>
</Provider>
</div>,document.getElementById('app')
);
SPA服务端渲染同构实现
在服务端渲染时，这里纠结了一下，遇到两个问题
- 参考一些资料的写法Node服务端都是在路由里面处理的，写起来好别扭,希望 render时
- ReactDOMServer.renderToString(ReactElement) 参数必须是ReactElement
- 组件异步获取的数据Node render怎么获取到
这里通过函数回调的方式可以解决上面问题，也就是 export 出去的是一个函数，然后 render 判断是否直接renderToString还是调用函数，然后再进行renderToString。目前在 egg-view-react-ssr 做了一层简单判断，代码如下：
app.react.renderElement = (reactElement,locals,options) => {
if (reactElement.prototype && reactElement.prototype.isReactComponent) {
return Promise.resolve(app.react.renderToString(reactElement,locals));
}
const context = { state: locals };
return reactElement(context,options).then(element => {
return app.react.renderToString(element,context.state);
});
}
这样处理了以后，Node 服务端controller处理时就无需自己处理路由匹配问题和store问题，全部交给底层处理。现在的这种处理方式与Vue服务端渲染render思路一致，把服务端逻辑写到模板文件里面，然后由Webpack构建js文件。
SPA服务端渲染入口文件
Webpack 构建的文件 app/ssr.js 到 app/view 目录
import React,renderRoutes } from 'react-router-config'
import Header from 'component/layout/standard/header/header';
import SSR from 'component/spa/ssr/ssr';
import { create } from 'component/spa/ssr/store';
import routes from 'component/spa/ssr/routes'
// context 为服务端初始化数据
export default function(context,options) {
const url = context.state.url;
// 根据服务端URL地址找到匹配的组件
const branch = matchRoutes(routes,url);
// 收集组件数据
const promises = branch.map(({route}) => {
const fetch = route.component.fetch;
return fetch instanceof Function ? fetch() : Promise.resolve(null)
});
// 获取组件数据，然后初始化store， 同时返回ReactElement
return Promise.all(promises).then(data => {
const initState = {};
data.forEach(item => {
Object.assign(initState,item);
});
context.state = Object.assign({},context.state,initState);
const store = create(initState);
return () =>(
<div>
<Header></Header>
<Provider store={store}>
<StaticRouter location={url} context={{}}>
<SSR url={url}/>
</StaticRouter>
</Provider>
</div>
)
});
};
Node服务端controller调用
- controller 实现
exports.ssr = function* (ctx) {
yield ctx.render('spa/ssr.js',{ url: ctx.url });
};
- 路由配置
app.get('/spa(/.+)?',app.controller.spa.spa.ssr);
- 效果演示
服务端实现与普通模板渲染调用无差异，写起来简单明了。如果你对 Egg + React 技术敢兴趣，赶快来玩一玩 egg-react-webpack-boilerplate 项目吧！
GL的学习资料短暂整理-水的渲染整理
下面是关于水的算法。
----------------------水面
1.normal map，根据自己的理解，水波算法自己写，然后加上一张关于水的法线贴图，模拟表面的涟漪效果。
2.FFT 的算法， 傅里叶变换？？？ 具体可以百度
3.Flow Map，待研究。
目前的资源有:
Unity RTP
4.使用水的视频，作为动态文理。
关于2维中的水：
1.模拟流体算法
2.使用物理引擎box2d使用小球来模拟。
今天的关于react 16 渲染整理和react的渲染的分享已经结束，谢谢您的关注，如果想了解更多关于create-react-app搭配react16+ts+less、Egg + React (React Router + Redux) (SSR) 服务端渲染实际、Egg + React + React Router ＋ Redux 服务端渲染同构实践、GL的学习资料短暂整理-水的渲染整理的相关知识，请在本站进行查询。
本文标签：
